STEEL WALL GEARBOX
FULL-DOOR CABINET
Assembly Instructions
ARMARIO DE ACERO PARA HERRAMIENTAS, PARA PARED
- PUERTA COMPLETA
Instrucciones de ensamblaje
ARMOIRE Ă OUTILS MURALE EN ACIER - PORTE PLEINE
Instructions d'assemblage
TABLE OF CONTENTS/ĂNDICE/TABLE DES MATIĂRES
PARTS ...........................................................2
CABINET/LOCKER SAFETY .......................3
ASSEMBLY INSTRUCTIONS.......................3
Cabinet Use Requirements........................3
Unpack Cabinet Parts................................3
Assemble Cabinet Frame ..........................3
Attach Back Panels....................................4
Install Doors ...............................................4
Install Shelves ............................................5
INSTALLATION INSTRUCTIONS................5
Install Cabinet to GearWallÂŽ Panels
or GearTrack
ÂŽChannels ............................5
Standard Wall Mount .................................6
WARRANTY ..................................................6
PIEZAS ..........................................................2
SEGURIDAD DEL ARMARIO .....................7
INSTRUCCIONES DE ENSAMBLAJE ........7
Requisitos de uso del armario................... 7
Desempaque las piezas del armario .........7
Ensamblaje del marco del armario............ 7
Fije los paneles posteriores ....................... 8
InstalaciĂłn de las puertas.......................... 9
InstalaciĂłn de los estantes........................9
INSTRUCCIONES DE INSTALACIĂN.........9
Instale el armario a los paneles GearWall
ÂŽ
o a los canales GearTrack
ÂŽ........................9
Montaje de pared estĂĄndar .....................10
GARANTĂA .................................................. 11
PIĂCES.......................................................... 2
SĂCURITĂ DE LâARMOIRE....................... 12
INSTRUCTIONS DâASSEMBLAGE ........... 12
SpĂŠcifications dâutilisation de lâarmoire .. 12
DĂŠballage des composants de l'armoire 12
Assemblage du châssis de l'armoire ...... 12
Fixation des panneaux arrière................. 13
Installation des portes ............................. 13
Installation des Êtagères.......................... 14
INSTRUCTIONS D'INSTALLATION.......... 14
Installation de lâarmoire sur des panneaux
GearWallÂŽ ou des profilĂŠs GearTrack
ÂŽ..... 14
Montage mural standard......................... 15
GARANTIE .................................................. 15
W10233395C
I T ' S T I M E T O R E T H I N K T H E G A R A G E . ÂŽ
E S T I E M P O D E V O L V E R A P E N S A R E N E L G A R A G E . â˘
L E G A R A G E R E P E N S Ă . â˘
2
PARTS/PIEZAS/PIĂCES
F1
F2
F3c
F7
F8
P1
P2
P3
P1
P4
P5
P6
P6m
P7
P8
P9
3
CABINET/LOCKER SAFETY
ASSEMBLY INSTRUCTIONS
Cabinet Use Requirements
â Intended for use in a garage.
â Maximum weight limit is 40 lbs (18 kg) for each shelf.
â Maximum weight limit is 150 lbs (68 kg) for the cabinet.
Unpack Cabinet Parts
1. Remove and verify the contents. Contents include an hex key
and the parts and fasteners shown in âParts.â
2. Dispose of/recycle all packaging materials.
Assemble Cabinet Frame
Gather the required tools before starting installation.
Tools Needed:
Tools Supplied:
IMPORTANT:
â Two people may be required to complete the assembly.
â The cabinet top (P2) is intentionally designed so that the tabs will
only match with the loops on the sides when it is positioned
correctly. If the tabs on the cabinet top do not match up with the
loops on the side panel (P1), turn the cabinet top around.
1. Place side panel (P1) on a flat, firm surface so that the edge with
the loops is facing up.
2. Align the tabs in the cabinet top (P2) with the loops in the cabinet
side (P1). Slide the cabinet top between the edges of side panel.
NOTE: Make sure each tab is inserted fully behind the loop.
3. Align the two holes in each corner. Using hex-head bolts (F1),
fasten the side panel (P1) to the top (P2) as shown. Do not
tighten completely.
4. Repeat steps 2 and 3 for the other cabinet side (P1).
5. With the smooth side toward the cabinet interior, align the four
tabs in the cabinet bottom (P3) with the loops in the cabinet
sides (P1). Slide the cabinet bottom between the edges of side
panels.
NOTE: Make sure each tab is fully inserted behind the loop.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word âDANGERâ or âWARNING.â
These words mean:
follow instructions.
instructions.
DANGER
WARNING
F1
F1
âľâââ
" Hex-head bolt (16)
â šââ" Wrench â Phillips screwdriver
â Hex key
A. Tab
B. Loop
P2
P1
A B
P2
