STEEL MODULAR GEARBOX
CABINET
Assembly Instructions
ARMARIO MODULAR DE
ACERO PARA
HERRAMIENTAS
Instrucciones de ensamblaje
ARMOIRE À OUTILS
MODULAIRE EN ACIER
Instructions d'assemblage
TABLE OF CONTENTS/ÍNDICE/TABLE DES MATIÈRES
CABINET/LOCKER SAFETY .......................2
PARTS ..........................................................2
ASSEMBLY INSTRUCTIONS.......................3
Cabinet Use Requirements........................3
Unpack Cabinet Parts................................3
Assemble Cabinet......................................3
Attach Lower Back Panel ..........................3
Install Leveling Legs...................................4
Assemble Drawer.......................................4
Attach Upper Back Panel ..........................5
Install Door Latch Bar ................................5
Install Shelf.................................................5
Install Doors ...............................................6
Complete the Assembly.............................6
ACCESSORIES .............................................6
WARRANTY ..................................................7
SEGURIDAD DEL ARMARIO ..................... 8
PIEZAS .........................................................8
INSTRUCCIONES DE ENSAMBLAJE ........9
Requisitos de uso del armario...................9
Desempaque las piezas del armario .........9
Ensamble el armario ..................................9
Sujete el panel posterior inferior................ 9
Instalación de las patas niveladoras .......10
Ensamble el cajón....................................10
Sujete el panel posterior superior............11
Instalación de la barra del pestillo
de la puerta ..............................................11
Instalación del estante.............................11
Instalación de las puertas........................12
Complete el ensamblaje ..........................12
ACCESORIOS............................................. 12
GARANTÍA .................................................. 13
SÉCURITÉ DE L’ARMOIRE....................... 14
PIÈCES ....................................................... 14
INSTRUCTIONS D'ASSEMBLAGE ........... 15
Spécifications d'utilisation de l'armoire .. 15
Déballage des composants de l'armoire 15
Assemblage de l'armoire......................... 15
Fixation du panneau arrière inférieur....... 15
Installation des pieds
de réglage de l'aplomb............................ 16
Assemblage du tiroir................................ 16
Fixation du panneau arrière supérieur .... 17
Installation de la barre
du loquet de porte ................................... 17
Installation de l'étagère ........................... 17
Installation des portes ............................. 18
Fin de l'assemblage................................. 18
ACCESSOIRES........................................... 18
GARANTIE .................................................. 19
2254086C
I T ' S T I M E T O R E T H I N K T H E G A R A G E . ®
E S T I E M P O D E V O L V E R A P E N S A R E N E L G A R A G E . ™
L E G A R A G E R E P E N S É . ™
2
CABINET/LOCKER SAFETY
PARTS
F1 F2 F3b F3s F4
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
P2
P3
P6
P5
P1
P11
P10
P9
P4
P8
D5
D1 D2
D3
P7
P7
D4
3
ASSEMBLY INSTRUCTIONS
Cabinet Use Requirements
■Intended for use in a garage.
■Maximum weight limit is 45 lbs (20 kg) for the shelf.
■Maximum weight limit is 30 lbs (13 kg) for the drawer.
■Maximum weight limit is 300 lbs (136 kg) for the cabinet.
Unpack Cabinet Parts
1. Remove and verify the contents. Contents include an Allen
wrench, a key, and the parts and fasteners shown in “Parts.”
2. Dispose of/recycle all packaging materials.
Assemble Cabinet
Gather the required tools before starting installation.
Tools Needed:
Tools Supplied:
IMPORTANT:
■Two people may be required to complete the assembly.
■As you assemble the cabinet, make sure the edges with the
holes are facing up.
■If you are assembling the cabinet on the floor, fasten the eight
front corner bolts, two at each corner, after you stand the cabinet
upright.
1. Place side panel (P1) on a flat, firm surface so that the edge with
the holes is facing up as shown.
2. Insert the cabinet top (P2) between the edges of side panel (P1).
NOTE: Make sure the edges with the holes are facing up.
3. Align the holes and attach the top (P2) to side panel (P1) using
six Allen-head bolts (F1) and ⁵⁄₁₆"
flange nuts (F2) as shown. Do
not tighten completely.
4. Position side panel (P3) so that the top (P2) is between the edges
of side panel (P3).
5. Align the holes and attach the top (P2) to the side (P3) using
six Allen-head bolts (F1) and ⁵⁄₁₆"
flange nuts (F2) as shown. Do
not tighten completely.
6. Insert cabinet bottom (P4) between the edges of side panels
(P1 and P3).
NOTE: Make sure the edges with the holes are facing up.
7. Align the holes and attach the bottom (P4) to the side panels
(P1 and P3) using six Allen-head bolts (F1) and ⁵⁄₁₆"
flange
nuts (F2) for each side as shown. Do not tighten completely.
Attach Lower Back Panel
1. Using seven Phillips-head screws (F3b), attach the lower back
panel (P6) to the bottom (P4) and sides (P1 and P3) as shown.
Tighten screws completely.
2. Using the Allen wrench (provided), completely tighten all the
cabinet bolts and nuts.
F1 F2
F1
⁵⁄₁₆
" Allen-head bolt (24)
F2
⁵⁄₁₆
" Flange nut (24)
■¹⁄₂" Wrench
■³⁄₈" Wrench
■Phillips screwdriver
■Level
■ ■Allen wrench Key
WARNING
Excessive Weight Hazard
Use two or more people to move, assemble or install
cabinet or locker.
Failure to do so can result in back or other injury.
F3b
F3b Phillips-head screw (7 - black)
P2
P1
P3
P4
P3
P2
P6
P1
P4
P3 P2
