MODULAR ADJUSTABLE
HEIGHT WORKBENCH
Assembly Instructions
MESA DE TRABAJO
MODULAR CON ALTURA
REGULABLE
Instrucciones de ensamblaje
ÉTABLI MODULAIRE À
HAUTEUR RÉGLABLE
Instructions d’assemblage
TABLE OF CONTENTS/ÍNDICE/TABLE DES MATIÈRES
WORKBENCH SAFETY..................................2
ASSEMBLY INSTRUCTIONS.........................2
Tools and Parts............................................2
Workbench Use Requirements....................2
Unpack the Workbench ...............................2
Parts Layout.................................................3
Install Legs and Back Panel.........................4
Complete the Assembly...............................5
Workbench Care ..........................................5
WARRANTY ....................................................6
SEGURIDAD DE LA MESA DE TRABAJO ...7
INSTRUCCIONES DE ENSAMBLAJE ..........7
Piezas y herramientas..................................7
Requisitos para el uso de la mesa
de trabajo..................................................... 7
Desempaque la mesa de trabajo ................7
Piezas........................................................... 8
Instale las patas y el panel posterior ........... 9
Complete el ensamblaje............................ 10
Cuidado de la mesa de trabajo .................10
GARANTÍA .................................................... 11
SÉCURITÉ DE L’ÉTABLI ............................. 12
INSTRUCTIONS D’ASSEMBLAGE ............. 12
Outillage et pièces..................................... 12
Spécifications d’utilisation de l’établi ........12
Déballage de l’établi .................................. 12
Pièces ........................................................ 13
Installation des pieds et du
panneau arrière..........................................14
Fin de l’assemblage................................... 15
Entretien de l'établi.................................... 15
GARANTIE .................................................... 16
W10490067C
I T ' S T I M E T O R E T H I N K T H E G A R A G E . ®
E S T I E M P O D E V O L V E R A P E N S A R E N E L G A R A G E . ™
L E G A R A G E R E P E N S É . ™
2
WORKBENCH SAFETY
ASSEMBLY INSTRUCTIONS
Tools and Parts
Gather the required tools and parts before starting installation.
Tools Needed
Parts Supplied—4 ft (121.9 cm), 6 ft (182.9 cm), and 8 ft
(243.9 cm) Workbench
Workbench Use Requirements
■Intended for use in a garage.
■Maximum weight limit is 3,000 lbs (1,360.8 kg) for the
workbench.
Unpack the Workbench
1. Unpack the legs and hardware from the box. Verify contents. See
“Parts Supplied.”
2. Remove the back panel and set it aside.
NOTE: Leave the workbench top on the cardboard during
assembly.
3. Remove the corners from the workbench top. The bolt holes
should be visible.
4. Dispose of/recycle all packaging materials.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
■⁹⁄₁₆" socket wrench
■⁷⁄₁₆" wrench
■Adjustable wrench
■P1—Workbench outer legs
(2 welded sets)
■P2—Workbench inner legs (4)
■P3—Workbench back panel
■P4—Workbench top
■P6—Leveling legs (4)
■F14—¹⁄₄" – 20 x ³⁄₄" bolts (4)
■F16—³⁄₈" x 1¹⁄₂" screws (11)
■F17—Wingnuts (8)
■F18—⁵⁄₁₆" hex-head bolts (8)
■F19—⁵⁄₁₆" washers (8)
■F20—¹⁄₄" lock washers (4)
3
Parts Layout
P1. Workbench outer legs
P2. Workbench inner legs
P3. Back panel
P4. Workbench top
P6.
³⁄₈
" leveling legs
F14.
¹⁄₄
" - 20 x
³⁄₄
" bolts
F16.
³⁄₈
" x 1
¹⁄₂
" screws
F17.Wing nuts
F18.
⁵⁄₁₆
" hex-head bolts
F19.
⁵⁄₁₆
" washers
F20.
¹⁄₄
" lock washers
F20
F14
P3
F16
P4
F16
P1
F18
F14
F20
P2
F18
F17
P6
F16
P1
F18
F17
F18
P2
P2
P6
F20
P2
F19
F19 F19
F19
F19
F19
F19
F19
F18 F19 F14 F20
