Seite 1/2
Component Checklist
Step 1. Component Checklist
Check you have received all parts against the Component Checklist above.
Hardware
Mounting Fasteners
Step 2. Remove the Wall Bracket Cover
๎๎
[B] Nylon
Anchor (x2)
[C] M4 Washer (x4)
[D] M5 Washer (x4)
[A] Wall Mount
Screw (x2)
[J] M6x8mm / [K] M6x12mm (x4 each)
[F] M4x8mm / [G] M4x12mm (x4 each)
[H] M5x8mm / [I] M5x12mm (x4 each)
[E] M6 Washer (x4)
TOOLS REQUIRED:
๎๎๎๎
๎๎๎๎๎๎๎๎๎
๎๎๎๎๎๎๎๎ps Head Screw Driver
๎๎๎๎๎๎๎3/16โ) Drill Bit
๎๎๎๎๎๎๎5/16โ) Masonry Drill Bit
Remove the two Locking Screws,
on both left and right sides.
Step 3. Remove the Mounting Plate
Step 4. Fix the Wall Bracket to the Wall
Using the Wall Plate as a drilling template, choose from one of the following Mounting options, 7LPEHU๎6WXG๎25๎0DVRQU\๎:DOO.
'ULOO๎WZR๎KROHV๎๎๎PP
GHHS๎ZLWK๎D๎๎PP
GULOO๎ELW๎
Masonry Wall
Nylon Anchor
(x2)
Wall Mount Screw (x2)
Wall Plate
M6 Washer (x2)
Wall Plate
Wall Mount Screw (x2)
M6 Washer (x2)
Timber Stud
'ULOO๎WZR๎KROHV๎๎๎PP
GHHS๎ZLWK๎D๎๎PP
0DVRQU\๎GULOO๎ELW๎
LIFT
TH-2250-VTP
(fully assembled)
IMPORTANT INFORMATION
๎ ๎๎๎,03257$17๎๎ฅ๎,QVWDOO๎:DOO๎0RXQW๎DV๎SHU๎,QVWDOODWLRQ๎,QVWUXFWLRQV๎
! Wall Mount supports Displays weighing up to 30kg (66lbs), with VESA hole configurations:
50x50mm, 75x75mm, 100x100mm, 200x100mm, 200x200mm.
! The Manufacturer accepts no responsibility for incorrect installation.
Cover
Locking
Screw (x2)
PULL
PULL
TH-2250-VTP Flat Screen Wall Mount lTilt
Installation Instructions
Step 6. Fasten the Mounting Plate to your Display
Mounting Screw (x4)
Choose appropriate Mounting Screws
and Washers from the Hardware
supplied to suit your Display.
Washer (x4)
Top of
Display
Mounting Plate
Step 7. Attach the Display to the Wall
Step 8. Tilt Adjustment
Locking
Screw (x2)
Hook the Mounting Plate
onto the Wall Bracket.
Wall Bracket
Mounting Plate
Re-insert the two
Locking Screws
on boths sides.
Display
bb
( required)
Tighten the Lever to lock the
Display in the desired position.
Step 5. Reinstall Wall Bracket Cover
Push the two pieces of
the Cover together.
PUSH
PUSH
TILT
TILT
Installation Complete
No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd.
Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. Published: 1 7.01.11 ยฉ
LOOSEN
Loosen the Lever before adjusting tilt.
TIGHTEN
Lever
LOWER
