and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.
required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications
products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is
of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson
Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage
Product Mounting Disclaimer
Rev. B
INST-941
This instruction sheet is for the Samsung Galaxy Tab Active Pro docking station only. For
instructions on features, set-up, and operation of the computer, please refer to the manual
provided by Samsung with the computer.
This docking station is designed to be used with a variety of Gamber-Johnson mounting
systems. Installation instructions for other Gamber-Johnson products are provided with each
individual product.
1 / 6
INSTALLATION INSTRUCTIONS
Product
Revision
Form
Printing Spec:
PS-001
7160-1418
SAMSUNG TAB ACTIVE PRO DOCKING STATION
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
This instruction sheet is for the following products:
Item No. 7160-1418-00
Bare Wire (Auto)
Item No. 7160-1418-20
Cigarette Adapter
Item No. 7160-1418-30
MP205 Connector
Item No. 7160-1418-90
Non-Powered Cradle
Power Adapters are not needed in most applications as this docking station can handle
10-40V input. Isolated and AC Power Adapters and can be ordered for the MP205 dock
from Gamber-Johnson seperately. These are available as a seperate KIT part number.
17794
- AC (100-264 Vac input) - KIT # 7170-0697-31
18868
- Isolated (12-32 Vdc input) - KIT # 7170-0697-32
18035
- Isolated (20-60 Vdc input) - KIT # 7170-0697-33
18869
- Isolated (70-110 Vdc input) - KIT # 7170-0697-34
IMPORTANT SAFETY INFORMATION FOR INSTALLERS
Safety is dependent on the proper installation and servicing of this docking station. It is
important to read and follow all instructions before installing this product.
To properly install a Gamber-Johnson docking station you must have a good understanding of
automotive electrical procedures and systems, along with proficiency in the installation and
service of aftermarket vehicle equipment.
There are no adjustments required at any time of the electrical components within the docking
station.
Opening the docking station will void the product warranty.
During Installation:
DO NOT
connect this docking station to the vehicle battery until:
All other electrical connections are made
1.
Mounting of all components is complete
2.
Verification that no shorts exist in the entire system
3.
DO NOT
install equipment or route wires or cords in the deployment path of any air bag.
When drilling into the vehicle, DO make sure that both sides of the surface are clear of
anything that could be damaged.
CAUTION:
If wiring is shorted to the frame, high current conductors can cause hazardous
sparks resulting in electrical fires or flying molten metal.
After installation:
Test the docking station to ensure that it is working properly.
File these instructions in a safe place and refer to them when performing maintenance or re-
installing.
WARNING
: Failure to follow all safety precautions and instructions may result in property
damage, serious injury, or death.
PRE-INSTALLATION RECOMMENDATIONS
Conduct a "Bench Test"
Gamber-Johnson strongly advises a "bench test" be conducted to verify all electronic and
software issues are resolved prior to installation:
Make sure the computer is operational by itself.
1.
Insert computer into the docking station and verify that the computer is
2.
operating in the dock.
Interconnect entire assembly and verify start-up of all components, including
3.
other equipment (printers, modems, scanners, etc.)
Gamber-Johnson recommends positioning of all mounts and equipment in the vehicle
prior to the actual install to verify that mounting locations are safe and practical.
2 / 6
Camera Access
(on Tablet)
Slam Latch
Upper Walls
Lower Walls
Barrel Key Lock
Release Button
Docking Connector
GJ Handstrap compatible
Contact Friendly
Edges
Port Identification
(Ports, see page 4)
USB-C Power
Port Blocker
Part#/Serial# Label
Warranty Label
Power Cable, 5.5' length
(see Page 4 for options)
VESA 75mm Hole Pattern
1/4-20 x 0.500" hardware provided
FEATURE IDENTIFICATION
3 / 6
Provides docking guidance
and connector protection,
prevents mis-docking
