PANASONIC CF33 TABLET DOCKING STATION
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
instructions on features, set-up, and operation of the computer, please refer to the
Product
This docking station is designed to be used with a variety of Gamber-Johnson
Revision
mounting systems. Installation instructions for other Gamber-Johnson products are
Printing Spec:
provided with each individual product.
7160-0907
PS-001
Form
manual provided by Panasonic with the computer.
INSTALLATION INSTRUCTIONS
This instruction sheet is for the Panasonic CF33 Tablet docking station only. For
This instruction sheet is for the following products:
Item No. 7160-0907-00 FULL PCB, No RF (External Power Supply sold separately)
Item No. 7160-0907-02 FULL PCB, Dual RF, Right (External Power Supply sold separately)
Item No. 7160-0907-06 LITE PCB, NO RF (External Power Supply sold separately)
Item No. 7160-0907-07 LITE PCB, Dual RF (External Power Supply sold separately)
Panasonic recommends using a Lind Auto Adapter to power the docking station. It can be ordered from
Gamber-Johnson (Item No. 14103 for bare wire leads, Item No. 14650 for mountable case and cigarette
plug lead).
1 / 6
© Copyright 2017 Gamber-Johnson, LLC
IMPORTANT SAFETY INFORMATION FOR INSTALLERS
Safety is dependent on the proper installation and servicing of this docking station. It is
important to read and follow all instructions before installing this product.
To properly install a Gamber-Johnson docking station you must have a good
understanding of automotive electrical procedures and systems, along with proficiency
in the installation and service of aftermarket vehicle equipment.
There are no adjustments required at any time of the electrical components within the
docking station. Opening the docking station will void the product warranty.
During Installation:
DO NOT connect this docking station to the vehicle battery until:
All other electrical connections are made1.
Mounting of all components is complete2.
Verification that no shorts exist in the entire system3.
DO NOT install equipment or route wires or cords in the deployment path of any air bag.
When drilling into the vehicle, DO make sure that both sides of the surface are clear of
anything that could be damaged.
CAUTION: If wiring is shorted to the frame, high current conductors can cause
hazardous sparks resulting in electrical fires or flying molten metal.
After installation:
Test the docking station to ensure that it is working properly.
File these instructions in a safe place and refer to them when performing maintenance
or re-installing.
WARNING: Failure to follow all safety precautions and instructions may result in property
damage, serious injury, or death.
PRE-INSTALLATION RECOMMENDATIONS
Conduct a "Bench Test"
Gamber-Johnson strongly advises a "bench test" be conducted to verify all
electronic and software issues are resolved prior to installation:
Make sure the computer is operational by itself.1.
Insert computer into the docking station and verify that the computer is 2.
operating in the dock.
Interconnect entire assembly and verify start-up of all components, 3.
including other equipment (printers, modems, scanners, etc.)
Gamber-Johnson recommends positioning of all mounts and equipment in the
vehicle prior to the actual install to verify that mounting locations are safe and
practical.
2 / 6
External ANT
Switch
Part# / Serial# Label
PANASONIC CF33 TABLET DOCK FEATURE IDENTIFICATION
3 / 6
Lock
Latch
Connector Guard
(2) USB 2.0
VESA 75MM
Hole Pattern
Power Input
15.6 Vdc
RF - ANT 1
RF - ANT 2
(2) Ethernet (RJ45)
(2) USB 3.0
(2) USB 2.0
Serial (RS232)
VGA
HDMI
Cable Tie Slot
(for power)
Cable Tie Slots NOTE: "LITE" version dock will not have VGA and HDMI ports
Warranty Label
Panasonic Notation: Ch1 (Ext-Ant1)
Panasonic Notation: Ch2 (Ext-Ant2)
