EN
Printed in EU
LCD TV/DVD
LDD-A2006 LDD-B2006 LDD-C2006 LDD-D2006
Owner’s Manual
Table of Contents
Precautions........................................................................................................................................................2
Operating Controls and Functions .....................................................................................................................4
Setting up...........................................................................................................................................................6
Set up for Use....................................................................................................................................................8
Operations .......................................................................................................................................................10
About the Discs................................................................................................................................................13
Playing a Disc ..................................................................................................................................................14
DVD Setup.......................................................................................................................................................23
Language Code ...............................................................................................................................................26
Troubleshooting Guide ....................................................................................................................................27
Maintenance ....................................................................................................................................................29
Specifications...................................................................................................................................................30
Pin Connection ................................................................................................................................................31
Declaration of Conformity ..................................................................................................................Back cover
TV OPERATION
DVD OPERATION
Supplied Accessories
Remote control
Two R6 (AA) batteries
Owners Manual
Quick Setup Guide (Only for LDD-B2006)
Model/Serial Number
This appliance has a serial number located on the rear panel.
Please note down the serial number and retain the
information for your records.
Model number:
Serial number:
Help Phone Number in the UK (only for LDD-B2006): 0870 383 3010
L4670EA(EN).fm Page 1 Tuesday, May 15, 2007 5:36 PM
2EN
Precautions
.
POWER SUPPLY
The main power supply is engaged when the main plug is
plugged in a 220-240V, 50Hz AC outlet. To operate the unit,
press STANDBY-ON to turn on the unit.
WARNING: LIVE PARTS INSIDE.
DO NOT REMOVE ANY SCREWS.
Laser Safety
This player employs a laser. Only a qualified service person
should remove the cover or attempt to service this device, due
to possible eye injury.
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
CAUTION:
VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCK DEFEATED.
DO NOT STARE INTO BEAM.
LOCATION:
PRINTED ON THE BACK
Dew Warning
Moisture condensation may occur inside the unit when it is
moved from a cold place to a warm place, or after heating a
cold room or under conditions of high humidity.
Do not use the unit at least for 2 hours until its inside is dry.
Caution
1) Do not attempt to open the cabinet. There are no parts
you can service inside. Refer all servicing to qualified
service personnel.
2) Slots and openings in the cabinet and the sides or bottom
are provided for ventilation. To ensure reliable operation
and to protect the unit from overheating, these openings
must not be blocked or covered.
Avoid installation in enclosed spaces such as bookcases
unless proper ventilation is provided.
3) Keep the unit away from radiators and other heat sources.
4) Do not push objects of any kind into the unit through the
cabinet slots or openings as they could touch electrically
live parts or short circuit parts resulting in a fire or electric
shock.
5) To prevent fire or shock hazard, do not expose this
apparatus to dripping or splashing, no objects filled with
liquids, such as vases, should be placed on the apparatus.
6) Use this unit in a horizontal (flat) subsoil only.
7) Do not place any combustible objects on the device
(candles, etc.).
8) The LCD panel used in this product is made of glass.
Therefore, it can break when the product is dropped or
applied with impact. Be careful not to be injured by
broken glass pieces in case the LCD panel breaks.
The LCD panel is a very high technology product with
921,600 thin film transistors, giving you fine picture
details. Occasionally, a few non-active pixels may appear
on the screen as a fixed point of blue, green or red. Please
note that this does not affect the performance of your
product.
9) Disconnect the mains plug to shut off when find troubles
or not in use.
10)The mains plug shall remain readily operable.
11)Read both manual instructions to ensure correct and safe
installation and interconnection of the unit in multimedia
systems.
12)Keep the distances 20 cm around apparatus of ventilation
openings.
About Copyright
Unauthorised copying, broadcasting, public performance and
lending of discs are prohibited.
This product incorporates copyright protection technology
that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technology
must be authorised by Macrovision, and is intended for home
and other limited viewing uses only unless otherwise
authorised by Macrovision. Reverse engineering or
disassembly is prohibited.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
KLASS 1 LASER APPARAT
CLASSE 1 PRODUIT LASER
L4670EA(EN).fm Page 2 Tuesday, May 15, 2007 5:36 PM
3EN
Connection to Power (Only for U.K.)
Before Switching on make sure that the voltage of your
electricity supply is the same as that indicated on the rating
plate.
Mains Cord
This appliance may be fitted with a non-rewireable plug. If it
is necessary to change the fuse in a non-rewireable plug the fuse
cover must be refitted. If the fuse cover is lost or damaged, the
plug must not be used until a replacement available from the
appliance manufacturer is obtained.
It is important that the colour of the replacement fuse cover
corresponds with the rating marking on the base of the plug.
If the plug has to be changed because it is not suitable for your
socket, or becomes damaged, it should be cut off and an
appropriate plug fitted following the wiring instructions
below. The plug removed must be disposed of safely as
insertion into a 13A socket is likely to cause an electrical
hazard. For your own safety read the following instructions
carefully before attempting to connect this unit to mains.
The wires in this mains lead are coloured in accordance with
the following code:
BLUE=NEUTRAL, BROWN=LIVE
Important
As the colours of the wires in the mains lead of this appliance
may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:-
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
No connection is to be made to the earth terminal of the plug.
If a 13 Amp (BS 1363) Plug is used, a 5 Amp Fuse must be
fitted, or if any other type of Plug is used a 5 Amp Fuse must
be fitted, either in the Plug or Adaptor, or on the Distribution
Board.
Mains Supply: 220 - 240 V 50 Hz - AC only
Do not make any connection to the larger pin marked with the
letter “E” or by the symbol or coloured green or green and
yellow.
Features
Stereo Sound System
On-Screen Display
Sleep Timer
• Teletext
S-VIDEO Input- allows you to get better picture detail and
clarity for the playback of S-VHS VCR tapes, Video Discs,
Satellite System, Video Game or Video Cameras.
Dolby Digital Sound
This unit can handle Dolby Digital surround sound having
Multi-channels when connected to a Dolby Digital decoder.
Still/Fast/Slow/Step Playback
x1.3 and x0.8 Rapid Play with Voice
Playback in slightly faster/ slower speed while keeping the
sound quality as in the normal playback.
This function is available only on discs recorded in the
Dolby Digital format.
Programmed Playback for Audio CD, MP3 and JPEG
Random Playback for Audio CD, MP3 and JPEG
DVD Menus in a Desired Language
Screen Saver
The screen saver programme starts when there is no input
from the DVD player for 5 minutes in the Stop mode.
Subtitles in a Desired Language
Selecting a Camera Angle
Choices for Audio Language and Sound Mode
Parental Lock
Automatic Detection of Discs
This unit automatically detects if a loaded disc is DVD,
Audio CD, Video CD, MP3, JPEG or DivX® on disc.
Playing MP3/JPEG/DivX ® Files
Direct Search
On-Screen Display
Information about the current operation can be displayed
on a TV screen, allowing you to confirm the currently active
functions (such as programme playback), on the TV screen
using the remote control.
• Search
Chapter search / Title search / Track search / Time search
• Repeat
Chapter / Title / Track / Group / All / A-B
• Zoom
• Marker
An electronic references point designated by user can be
called back.
Resume Play
Virtual Surround
• Scart
Bit Rate Indication
DRC (Dynamic Range Control)
Displaying a JPEG Picture
Adjustment of Picture Size
Symbols Used in This Manual
The following symbols appear below in some headings and
notes in this manual, with the following meanings:
: Description refers to playback of DVD-Video discs.
: Description refers to playback of Audio CDs.
: Description refers to playback of CD-R/RW discs with MP3
files.
: Description refers to viewing of CD-R/RW discs with JPEG
files.
: Description refers to playback of Video CDs.
: Description refers to playback formatted with DivX®.
< LCD TV >
< DVD >
FUSE
BLUE
(Neutral)
BROWN
(Live)
CORD GRIP
OUTER SHEATH OF THE WIRE
DVD-V
CD
MP3
JPEG
VCD
DivX®
L4670EA(EN).fm Page 3 Tuesday, May 15, 2007 5:36 PM
