1EMN21993C
L5820EA/L5920EA/L5821BB/L5921BB/L5823RD/L5923RD/L5824FE/L5924FE/L5926EG/L5827RH/L5927RH/L5850EA/
L5851BB/L5852FC/L5853RD/L5854FE/L5857RH/L5950EA/L5951BB/L5953RD/L5954FE/L5956EG/L5957RH**
EN
Printed in EU
LCD COLOUR TV
LCD-A2706 LCD-B2706 LCD-C2706 LCD-C2707 LCD-D2706 LCD-D2707
LCD-A2726 LCD-B2726 LCD-C2717 LCD-C2726 LCD-D2717 LCD-D2726
LCD-A3206 LCD-A3207 LCD-B3206 LCD-C3206 LCD-C3207 LCD-D3206 LCD-D3207
Owner’s Manual
Table of Contents
DECLARATION OF CONFORMITY ..................................................................................................................2
PRECAUTIONS .................................................................................................................................................3
OPERATING CONTROLS AND FUNCTIONS ..................................................................................................4
PREPARATION FOR USE ................................................................................................................................6
SET UP FOR USE .............................................................................................................................................8
OPERATIONS .................................................................................................................................................11
MAINTENANCE...............................................................................................................................................14
TROUBLESHOOTING GUIDE ........................................................................................................................15
SPECIFICATIONS ...........................................................................................................................................16
Features
•Stereo Sound System
•On-Screen Display
•Sleep Timer
• Teletext
• Screen Mode Selection
•Auto Power Off Function- If there is no signal input from
the antenna terminal and no user operation for 15 minutes,
the TV will turn itself off automatically.
• HDMI Input
• COMPONENT Input
• S-VIDEO Input
Supplied Accessories
• Remote control
• Two R6 (AA) batteries
• Owner’s Manual
Model/Serial Number
To aid reporting in case of loss or theft, please record the TV’s
model and serial numbers in the space provided. The numbers are
located at the rear of the TV.
Model number:
Serial number:
A Note about Recycling
This product’s packaging materials are recyclable
and can be reused. Please dispose of any materials
in accordance with your local recycling
regulations.
This product consists of materials which can be
recycled and reused if disassembled by a
specialised company.
Batteries should never be thrown away or
incinerated but disposed of in accordance with
your local regulations concerning chemical
wastes.
Contact your council for details.
L5950EA(EN).fm Page 1 Friday, March 30, 2007 2:46 PM
2EN
DECLARATION OF CONFORMITY
This product complies with the requirement of the directives
EMC-Directive: 89 / 336 / EEC
Low Voltage Directive: 73 / 23 / EEC
CE Marking: 93 / 68 / EEC
We declare that the following product:
LCD COLOUR TV, Model LCD-A2706, LCD-A2726,
LCD-A3206, LCD-A3207, LCD-B2706, LCD-B2726,
LCD-B3206, LCD-C2706, LCD-C2707, LCD-C2717,
LCD-C2726, LCD-C3206, LCD-C3207, LCD-D2706,
LCD-D2707, LCD-D2717, LCD-D2726, LCD-D3206,
LCD-D3207
Trade Name: Funai
is in compliance with following Regulations.
EN55013: 2001 + A1: 2003
EN55020: 2002 + A1: 2003
EN61000-3-2: 2000, EN61000-3-3: 1995 + A1: 2001
EN60065: 2002
EN60825-1: 1994 + A1: 1996 + A2: 2001
Help Phone Number in the UK (only for LCD-B2706 / LCD-B3206):
0870 383 3010
L5950EA(EN).fm Page 2 Friday, March 30, 2007 2:46 PM
3EN
PRECAUTIONS
.
POWER SUPPLY
The main power supply is engaged when the main plug is
plugged in a 220-240 V, 50 Hz AC outlet. To operate the unit,
press STANDBY-ON to turn on the unit.
WARNING: LIVE PARTS INSIDE.
DO NOT REMOVE ANY SCREWS.
CAUTION
1) Do not attempt to open the cabinet. There are no parts
you can service inside. Refer all servicing to qualified
service personnel.
2) Slots and openings in the cabinet and the sides or bottom
are provided for ventilation. To ensure reliable operation
and to protect the unit from overheating, these openings
must not be blocked or covered.
Avoid installation in enclosed spaces such as bookcases
unless proper ventilation is provided.
3) Keep the unit away from radiators and other heat sources.
4) Do not push objects of any kind into the unit through the
cabinet slots or openings as they could touch electrically
live parts or short circuit parts resulting in a fire or electric
shock.
5) To prevent fire or shock hazard, do not expose this
apparatus to dripping or splashing, no objects filled with
liquids, such as vases, should be placed on the apparatus.
6) Use this unit in a horizontal (flat) subsoil only.
7) Do not place any combustible objects on the device
(candles, etc.).
8) The LCD panel used in this product is made of glass.
Therefore, it can break when the product is dropped or
applied with impact. Be careful not to be injured by
broken glass pieces in case the LCD panel breaks.
The LCD panel is a very high technology product with
921,600 thin film transistors, giving you fine picture
details. Occasionally, a few non-active pixels may appear
on the screen as a fixed point of blue, green or red. Please
note that this does not affect the performance of your
product.
9) Disconnect the mains plug to shut off when find troubles
or not in use.
10)The mains plug shall remain readily operable.
11)Read both manual instructions to ensure correct and safe
installation and interconnection of the unit in multimedia
systems.
12)Keep the distances 20 cm around apparatus of ventilation
openings.
Connection to Power (Only for U.K.)
Before Switching on make sure that the voltage of your
electricity supply is the same as that indicated on the rating
plate.
Mains Cord
This appliance may be fitted with a non-rewireable plug. If it
is necessary to change the fuse in a non-rewireable plug the fuse
cover must be refitted. If the fuse cover is lost or damaged, the
plug must not be used until a replacement available from the
appliance manufacturer is obtained.
It is important that the colour of the replacement fuse cover
corresponds with the rating marking on the base of the plug.
If the plug has to be changed because it is not suitable for your
socket, or becomes damaged, it should be cut off and an
appropriate plug fitted following the wiring instructions
below. The plug removed must be disposed of safely as
insertion into a 13A socket is likely to cause an electrical
hazard. For your own safety read the following instructions
carefully before attempting to connect this unit to mains.
The wires in this mains lead are coloured in accordance with
the following code:
BLUE=NEUTRAL, BROWN=LIVE
Important
As the colours of the wires in the mains lead of this appliance
may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:-
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
No connection is to be made to the earth terminal of the plug.
If a 13 Amp (BS 1363) Plug is used, a 5 Amp Fuse must be
fitted, or if any other type of Plug is used a 5 Amp Fuse must
be fitted, either in the Plug or Adaptor, or on the Distribution
Board.
Mains Supply: 220 - 240 V 50 Hz - AC only
Do not make any connection to the larger pin marked with the
letter “E” or by the symbol or coloured green or green and
yellow.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
FUSE
BLUE
(Neutral)
BROWN
(Live)
CORD GRIP
OUTER SHEATH OF THE WIRE
L5950EA(EN).fm Page 3 Friday, March 30, 2007 2:46 PM
