INSTRUCTION MANUAL
MODE D'EMPLOI
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUCCIONES
INSTRUCTIEHANDLEIDING
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
INSTRUKCJA OBSŁUGI
PLANT SPECTRUM LED
DEL DE HAUTE LUMINOSITÉ POUR EAU DOUCE
LEISTUNGSSTARKES SÜSSWASSER-LED-BELEUCHTUNGSSYSTEMTEM
LED DE ALTO RENDIMIENTO PARA AGUA DULCE
ZOETWATER-LED
СВЕТОДИОДНЫЕ СВЕТИЛЬНИКИ MARINE SPECTRUM
PLANT SPECTRUM LED
EN
IMPORTANT SAFETY INSTRUCTIONS
WARNING – To guard against injury, basic safety precautions should be observed, including the following:
1.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
and all the important notices on the appliance before using. Failure to do so may result in loss of fish life and/
or damage to this appliance.
2. DANGER – To avoid possible electric shock, special care should be taken since water is employed in the
use of aquarium equipment. For each of the following situations, do not attempt repairs yourself; return the
appliance to an authorized service facility for service or discard the appliance.
A. If the appliance shows any sign of abnormal water leakage, immediately unplug it from the power source.
B. Carefully examine the appliance after installation. It should not be plugged in if there is water on parts not
intended to be wet. If the appliance or any part of it falls into the water DO NOT reach for it. First unplug
the unit before retrieving.
C. Do not operate any appliance if it has a damaged cord or plug, or if it is malfunctioning or it is dropped or
damaged in any manner. The power cord of this appliance cannot be replaced; if the cord is damaged, the
appliance should be discarded. Never cut the cord.
D. To avoid the possibility of the appliance
plug or receptacle getting wet, position
the appliance to one side of a wall mounted
receptacle to prevent water from dripping
onto the receptacle or plug. A “drip loop”
(see illustration) should be arranged by the
user for the cord connecting appliance to
a receptacle. “The drip loop” is that part of
the cord below the level of the receptacle or
the connector if an extension cord is used,
to prevent water travelling along the cord
and coming in contact with the receptacle. If
the plug or receptacle does get wet, DO NOT
unplug the cord. Disconnect the fuse or circuit
breaker that supplies power to the appliance.
Then unplug and examine for presence of
water in receptacle.
3. This appliance is not intended for use by persons (including children) with significantly impaired physical
or mental capabilities, unless they have been given supervision or instruction concerning the use of the
appliance by a person responsible for their safety. Children should always be supervised to ensure that they
do not play with the appliance.
4. To avoid injury, do not touch moving parts or hot parts.
5. CAUTION - Always unplug or disconnect all appliances in the aquarium from electricity supply before placing
hands in water, before putting on or taking off parts and while the equipment is being installed, maintained
or handled. Never yank cord to pull plug from outlet. Grasp the plug and pull to disconnect. Always unplug an
appliance from an outlet when not in use.
6. Do not install or store the appliance where it will be exposed to weather or temperatures below freezing. FOR
INDOOR HOUSEHOLD USE ONLY. DO NOT IMMERSE.
7. Make sure the appliance is mounted correctly and securely positioned on the aquarium before operating the
appliance.
8. If an extension cord is necessary, a cord with proper rating should be used. A cord rated for less amperes or
watts than the appliance rating may overheat. Care should be taken to arrange the cord so that it will not be
tripped over or pulled. The connection should be carried out by a qualified electrical installer.
9. Use only with AC adapter supplied with this product.
10. The socket-outlet shall be installed near the equipment and shall be easily accessible.
11. LED power supply shall not be positioned on or into the cover frame.
12. “Z” attachments: The external flexible cable or cord of this luminaire cannot be replaced; if cord is damaged
the luminaire shall be destroyed.
13. This luminaire can be mounted on any aquarium with glass thickness of between 3 mm and 15 mm.
14. ATTENTION: The light source of this luminaire is not replaceable; when the light source reaches its end of life
the whole luminaire shall be replaced.
15. ATTENTION: Do not stare at the operating light source.
SAVE THESE INSTRUCTIONS
For the complete use and understanding of this product it is recommended that this manual is thoroughly
read and understood. Failure to do so may result in damage to this product.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure
condition without restriction.
For full instruction manual and video on set up of Bluetooth ® application, visit:
fluvalaquatics.com/plantbluetooth
Download the Free SmartAPP now:
INSTALLATION:
Please verify that all components of the light fixture are undamaged before putting it into operation.
Before any kind of maintenance, always disconnect electrical supply of the light fixture.
• Make sure the light fixture is mounted correctly and securely positioned on the aquarium before
operating the appliance.
• Always ensure that the brackets are on the outside of the aquarium frame. If needed, the
extendible mounting brackets can be adjusted accordingly to ensure proper fit on aquarium.
• Connect transformer to electrical supply.
DIMMABLE LED WITH ILLUMINATED TOUCH SWITCH CONTROL:
Illuminated Touch Switch: Switch changes color to indicate the different settings:
off (red illumination), all lights on (white illumination), Blue lights only (blue illumination),
Bluetooth mode (green illumination).
Dimming Feature: Lighting intensity can be dimmed on both the white illumination setting (all lights
on)or the blue illumination setting (only blue lights on) by depressing the switch and keeping finger
on it until preferred lighting intensity is reached. Once dimming intensity level is chosen it will NOTE:
remain fixed at that level, even if fixture is turned off. To change the intensity level it is necessary to
manually depress and hold down the switch.
MAINTENANCE:
For maximum LED performance, it is recommended that the fixture and the LED lens be cleaned on a
weekly basis. Unplug transformer prior to cleaning the light fixture and remove from aquarium. Use
both hands when manipulating this appliance. Wipe exposed surfaces carefully with a damp cloth
to remove any dust or mineral deposits that may collect over time. Do not use detergents or harsh
cleaners as it can damage the light fixture. Use Fluval LED Lens Cleaning Non-Aerosol Spray (A3969)
to clean the LED portion of the light fixture. Make sure all surfaces are dry before re-connecting the
transformer to the power source.
BASIC TROUBLE-SHOOTING:
If the fixture does not work, ensure that all plugs and wires are firmly connected, ie: connection from
fixture to transformer, and connection from transformer to electrical outlet.
M :odel 14520 14521 14522 14523
Input Volts: 100-240 V 100-240 V 100-240 V 100-240 V
Operating Volts 24 V 24 V 24 V 24 V
Size
Adjustment :
15- 24"
(38 - 61 cm)
24- 34"
(61 - 85 cm)
36 - 48"
(91 - 122 cm)
48 - 60"
(122 - 153 cm)
No. of LEDs: 99 168 252 336
Wattage: 22 4632 59
Lumens: 1450 2350 3300 4250
Life in Hours 50 000 50 000 50 000 50 000
WARRANTY
3 YEAR LIMITED WARRANTY
Your Fluval Plant Spectrum LED is guaranteed for defective parts and workmanship for a period
of three years from the date of purchase. This guarantee is valid with proof of purchase only. The
guarantee is limited to repair or replacement only and does not cover consequential loss, loss or
damage to livestock and personal property or damage to animate or inanimate objects, irrespective
of the cause thereof. This guarantee is valid only under normal operating conditions for which
the unit is intended. It excludes any damage caused by unreasonable use, negligence, improper
installation, tampering, abuse or commercial use. The warranty does not cover wear and tear or
parts which have not been adequately or correctly maintained. Failure of less than 5% of the total
number of LEDs shall not be considered a defect under the terms of this warranty.
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
FOR AUTHORIZED WARRANTY REPAIR SERVICE:
For Authorized Warranty Service please return (well packaged and by registered post) to the
address below enclosing dated receipt and reason for return. If you have any queries or comments
about the operation of this product, please let us try to help you before you return the product to
your retailer. Most queries can be handled promptly with a phone call. When you call (or write),
please have all relevant information such as model number, age of product, details of aquarium
set-up, as well as the nature of the problem.
CANADA: Consumer Repair, Rolf C. Hagen Inc., 20500 Trans Canada Hwy,
Baie d’Urfé, QC H9X 0A2
U.S.A.: Rolf C. Hagen (U.S.A.) Corp., 305 Forbes Blvd, Mansfield, MA. 02048
UK: Rolf C. Hagen (UK) Ltd, Customer Service Department California Drive, Whitwood Ind Est.,
Castleford West Yorkshire WF10 5QH http://faq.hagencrm.com/?uk
CALL US ON OUR TOLL-FREE NUMBER:
CANADA ONLY: 1-800-554-2436 between 9:00 a.m. and 4:30 p.m. Eastern Standard Time.
Ask for Customer Service.
U.S. ONLY: 1-800-724-2436 between 9:00 a.m. and 4:00 p.m. Eastern Standard Time.
Ask for Customer Service.
U.K. ONLY: Helpline Number 01977 521015. Between 9:00 AM and 5:00 PM, Monday to Thursday and
9:00 AM and 4:00 PM on Friday (excluding Bank Holidays).
RED= OFF
WHITE= ON
BLUE= BLUE ONLY
GREEN= BLUETOOTH MODE
