IMPORTANT! PLEASE READ CAREFULLY AND SAVE.

This user’s manual contains important information about your Smoke

Alarm’s operation. If you are installing this Smoke Alarm for use by others,

you must leave this manual—or a copy of it—with the end user.

User’s ManUal

Printed in Mexico

M08-0194-005 Q 09/14

Fire saFeTY Tips

Follow safety rules and prevent hazardous situations:

1) Use smoking materials properly. Never smoke in bed. 2) Keep matches or

lighters away from children; 3) Store flammable materials in proper containers;

4) Keep electrical appliances in good condition and don’t overload electrical

circuits; 5) Keep stoves, barbecue grills, fireplaces and chimneys grease-

and debris-free; 6) Never leave anything cooking on the stove unattended;

7) Keep portable heaters and open flames, like candles, away from flammable

materials; 8) Don’t let rubbish accumulate.

Keep alarms clean, and test them weekly. Replace alarms immediately if they

are not working properly. Smoke Alarms that do not work cannot alert you to a

fire. Keep at least one working fire extinguisher on every floor, and an additional

one in the kitchen. Have fire escape ladders or other reliable means of escape

from an upper floor in case stairs are blocked.

BeFore YoU insTall This sMoke alarM

Important! Read “Recommended Locations for Smoke Alarms” and

“Locations to Avoid for Smoke Alarms” before beginning. This unit monitors

the air, and when smoke reaches its sensing chamber, it alarms. It can give

you more time to escape before fire spreads. This unit can ONLY give an

early warning of developing fires if it is installed, maintained and located

where smoke can reach it, and where all residents can hear it, as described

in this manual. This unit will not sense gas, heat, or flame. It cannot prevent

or extinguish fires.

Understand The Different Type of Smoke Alarms

Battery powered or electrical? Different Smoke Alarms provide different

types of protection. See “About Smoke Alarms” for details.

Know Where To Install Your Smoke Alarms

Fire Safety Professionals recommend at least one Smoke Alarm on every

level of your home, in every bedroom, and in every bedroom hallway or

separate sleeping area. See “Recommended Locations For Smoke Alarms”

and “Locations To Avoid For Smoke Alarms” for details.

Know What Smoke Alarms Can and Can’t Do

A Smoke Alarm can help alert you to fire, giving you precious time to

escape. It can only sound an alarm once smoke reaches the sensor.

See “Limitations of Smoke Alarms” for details.

Check Your Local Building Codes

This Smoke Alarm is designed to be used in a typical single-family home.

It alone will not meet requirements for boarding houses, apartment buildings,

hotels or motels. See “Special Compliance Considerations” for details.

TaBle oF ConTenTs

Introduction 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Fire Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Before You Install This Smoke Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Step By Step Guide To Programming This Alarm . . . . . . . . . . . . . . . . . . . 2

Adding and Linking Additional WIRELESS INTERCONNECT Alarms . . 2

What You Will See and Hear With This Alarm . . . . . . . . . . . . . . . . . . . . 2

Wireless Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

How To Install This Smoke Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Optional Locking Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Weekly Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Regular Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

If This Smoke Alarm Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

What To Do In Case Of Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Using the Silence Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Silencing the Low Battery Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Latching Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

If You Suspect A Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Recommended Locations For Smoke Alarms . . . . . . . . . . . . . . . . . . . . 5-6

Agency Placement Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . 6

Locations To Avoid For Smoke Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

About Smoke Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Special Compliance Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

Limitations Of Smoke Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

*All First Alert® Smoke Alarms conform to regulatory requirements,

including UL217 and are designed to detect particles of combustion.

Smoke particles of varying number and size are produced in all fires.

Ionization technology is generally more sensitive than photoelectric

technology at detecting small particles, which tend to be produced in

greater amounts by flaming fires, which consume combustible materials

rapidly and spread quickly. Sources of these fires may include paper burning

in a wastebasket, or a grease fire in the kitchen.

Photoelectric technology is generally more sensitive than ionization

technology at detecting large particles, which tend to be produced

in greater amounts by smoldering fires, which may smolder for hours

before bursting into flame. Sources of these fires may include cigarettes

burning in couches or bedding.

For maximum protection, use both types of Smoke Alarms on each

level and in every bedroom of your home.

• Thisunitwillnotalerthearingimpairedresidents.Itisrecommended

that you install special units which use devices like flashing strobe

lights to alert hearing impaired residents.

• Unitwillnotoperatewithoutbatterypower.TheSmokeAlarm

cannot work until you install the batteries in the correct position

(Match “+” to “+” and “-” to “-”).

• ThisSmokeAlarmhasabatterydrawerwhichresistsclosing

unless batteries are installed.

• Donotinstallthisunitoveranelectricaljunctionbox.Aircurrents

aroundjunctionboxescanpreventsmokefromreachingthe

sensing chamber and prevent the unit from alarming. Only AC

poweredunitsareintendedforinstallationoverjunctionboxes.

• Donotstandtooclosetotheunitwhenthealarmissounding.

It is loud to wake you in an emergency. Exposure to the horn at

close range may harm your hearing.

• Donotpaintovertheunit.Paintmayclogtheopeningstothe

sensing chamber and prevent the unit from operating properly.

123

iF This sMoke alarM soUnds

responding To an alarM

During an alarm, you will hear a loud, repeating horn pattern:

3 beeps, pause, 3 beeps, pause. The red LED will flash rapidly.

• Iftheunitalarmsandyouarenottestingtheunit,itiswarningyou

of a potentially dangerous situation that requires your immediate

attention. NEVER ignore any alarm. Ignoring the alarm may result in

injuryordeath.

• NeverremovethebatteriesfromabatteryoperatedSmokeAlarmto

stop an unwanted alarm (caused by cooking smoke, etc.). Removing

batteries disables the alarm so it cannot sense smoke, and removes

your protection. Instead open a window or fan the smoke away from

the unit. The alarm will reset automatically.

• Iftheunitalarmsgeteveryoneoutofthehouseimmediately.

Wireless inTerConneCT

BaTTerY operaTed

sMoke alarM

liMiTed WarranTY

BRK Brands, Inc., (“BRK”) the maker of First Alert

® brand products warrants

that for a period of ten years from the date of purchase, this product will be

free from defects in material and workmanship. BRK, at its option, will repair

or replace this product or any component of the product found to be defective

during the warranty period. Replacement will be made with a new or re-

manufactured product or component. If the product is no longer available,

replacement may be made with a similar product of equal or greater value.

This is your exclusive warranty.

This warranty is valid for the original retail purchaser from the date of initial

retail purchase and is not transferable. Keep the original sales receipt. Proof

of purchase is required to obtain warranty performance. BRK dealers, service

centers, or retail stores selling BRK products do not have the right to alter,

modify or any way change the terms and conditions of this warranty.

This warranty does not cover normal wear of parts or damage resulting from

any of the following: negligent use or misuse of the product, use on improper

voltage or current, use contrary to the operating instructions, disassembly,

repair or alteration by anyone other than BRK or an authorized service center.

Further, the warranty does not cover Acts of God, such as fire, flood,

hurricanes and tornadoes or any batteries that are included with this unit.

BRK shall not be liable for any incidental or consequential damages caused by

the breach of any express or implied warranty. Except to the extent prohibited

by applicable law, any implied warranty of merchantability or fitness for a

particular purpose is limited in duration to the duration of the above warranty.

Some states, provinces or jurisdictions do not allow the exclusion or limitation

of incidental or consequential damages or limitations on how long an implied

warranty lasts, so the above limitations or exclusion may not apply to you.

This warranty gives you specific legal rights, and you may also have other

rights that vary from state to state or province to province.

How to Obtain Warranty Service

Service: If service is required, do not return the product to your retailer.

In order to obtain warranty service, contact the Consumer Affairs Division at

1-800-323-9005, 7:30 AM - 5:00 PM Central Standard Time, Monday through

Friday. To assist us in serving you, please have the model number and date

of purchase available when calling.

For Warranty Service return to:

BRK Brands, Inc., 25 Spur Drive, El Paso, TX 79906

Battery: BRK Brands, Inc. make no warranty, express or implied, written or

oral, including that of merchantability or fitness for any particular purpose

with respect to battery.

loCaTions To aVoid For sMoke alarMs

For best performance, it is recommended you AVOID installing Smoke

Alarms in these areas:

• Where combustion particles are produced. Combustion particles form

when something burns. Areas to avoid include poorly ventilated kitchens,

garages, and furnace rooms. Keep units at least 20 feet (6 meters) from

the sources of combustion particles (stove, furnace, water heater, space

heater) if possible. In areas where a 20-foot (6-meter) distance is not

possible – in modular, mobile, or smaller homes, for example – it is

recommended the Smoke Alarm be placed as far from these fuel-burning

sources as possible. The placement recommendations are intended to

keep these Alarms at a reasonable distance from a fuel-burning source,

and thus reduce “unwanted” alarms. Unwanted alarms can occur if a

Smoke Alarm is placed directly next to a fuel-burning source. Ventilate

these areas as much as possible.

• In air streams near kitchens. Air currents can draw cooking smoke into

the sensing chamber of a Smoke Alarm near the kitchen.

• In very damp, humid or steamy areas, or directly near bathrooms with

showers. Keep units at least 10 feet (3 meters) away from showers,

saunas, dishwashers, etc.

• Where the temperatures are regularly below 40˚ F (4.4˚ C) or above 100˚ F

(37.8˚ C), including unheated buildings, outdoor rooms, porches, or

unfinished attics or basements.

• In very dusty, dirty, or greasy areas. Do not install a Smoke Alarm directly

over the stove or range. Keep laundry room Smoke Alarms free of dust or

lint.

• Near fresh air vents, ceiling fans, or in very drafty areas. Drafts can blow

smoke away from the unit, preventing it from reaching the sensing

chamber.

• In insect infested areas. Insects can clog openings to the sensing

chamber and cause unwanted alarms.

• Less than 12 inches (305mm) away from fluorescent lights.

Electrical “noise” can interfere with the sensor.

• In “dead air” spaces. “Dead air” spaces may prevent smoke from

reaching the Smoke Alarm.

Avoiding Dead Air Spaces

“Dead air” spaces may prevent smoke from reaching the Smoke Alarm.

To avoid dead air spaces, follow the installation recommendations below.

On ceilings, install Smoke Alarms as close to the center of the ceiling as

possible. If this is not possible, install the Smoke Alarm at least 4 inches

(102 mm) from the wall or corner.

For wall mounting (if allowed by building codes), the top edge of Smoke

Alarms should be placed between 4 and 12 inches (102 and 305 mm) from

the wall/ceiling line, below typical “dead air” spaces.

On a peaked, gabled, or cathedral ceiling, install the first Smoke Alarm

within 3 feet (0.9 meters) of the peak of the ceiling, measured horizontally.

Additional Smoke Alarms may be required depending on the length, angle,

etc. of the ceiling’s slope. Refer to NFPA 72 for details on requirements for

sloped or peaked ceilings.

liMiTaTions oF sMoke alarMs

Smoke Alarms have played a key role in reducing deaths resulting from home

fires worldwide. However, like any warning device, Smoke Alarms can only

work if they are properly located, installed, and maintained, and if smoke

reaches them. They are not foolproof.

Smoke alarms may not waken all individuals. Practice the escape plan

at least twice a year, making sure that everyone is involved – from kids to

grandparents. Allow children to master fire escape planning and practice

before holding a fire drill at night when they are sleeping. If children or others

do not readily waken to the sound of the smoke alarm, or if there are infants

or family members with mobility limitations, make sure that someone is

assigned to assist them in fire drill and in the event of an emergency. It is

recommended that you hold a fire drill while family members are sleeping

in order to determine their response to the sound of the smoke alarm while

sleeping and to determine whether they may need assistance in the event

of an emergency.

Smoke Alarms cannot work without power. Battery operated units cannot

work if the batteries are missing, disconnected or dead, if the wrong type of

batteries are used, or if the batteries are not installed correctly. AC units

cannot work if the AC power is cut off for any reason (open fuse or circuit

breaker, failure along a power line or at a power station, electrical fire that

burns the electrical wires, etc.). If you are concerned about the limitations

of battery or AC power, install both types of units.

Smoke Alarms cannot detect fires if the smoke does not reach them.

Smoke from fires in chimneys or walls, on roofs, or on the other side of

closed doors may not reach the sensing chamber and set off the alarm.

That is why one unit should be installed inside each bedroom or sleeping

area—especially if bedroom or sleeping area doors are closed at night—and

in the hallway between them.

Smoke Alarms may not detect fire on another floor or area of the home.

For example, a stand-alone unit on the second floor may not detect smoke

from a basement fire until the fire spreads. This may not give you enough

time to escape safely. That is why recommended minimum protection is at

least one unit in every sleeping area, and every bedroom on every level of

your home. Even with a unit on every floor, stand-alone units may not provide

as much protection as interconnected units, especially if the fire starts in a

remote area. Some safety experts recommend installing interconnected

AC powered units with battery back-up (see “About Smoke Alarms”) or

professional fire detection systems, so if one unit senses smoke, all units

alarm. Interconnected units may provide earlier warning than stand-alone

units since all units alarm when one detects smoke.

Smoke Alarms may not be heard. Though the alarm horn in this unit meets

or exceeds current standards, it may not be heard if: 1) the unit is located

outside

a closed or partially closed door, 2) residents recently consumed

alcohol or drugs, 3) the alarm is drowned out by noise from stereo, TV, traffic,

air conditioner or other appliances, 4) residents are hearing impaired or sound

sleepers. Special purpose units, like those with visual and audible alarms,

should be installed for hearing impaired residents.

Smoke Alarms may not have time to alarm before the fire itself causes

damage,injury,ordeath,sincesmokefromsomefiresmaynotreach

the unit immediately. Examples of this include persons smoking in bed,

children playing with matches, or fires caused by violent explosions

resulting from escaping gas.

Smoke Alarms are not foolproof. Like any electronic device, Smoke Alarms

are made of components that can wear out or fail at any time. You must test

the unit weekly to ensure your continued protection. Smoke Alarms cannot

prevent or extinguish fires. They are not a substitute for property or life

insurance.

Smoke Alarms have a limited life. The unit should be replaced immediately

if it is not operating properly. You should always replace a Smoke Alarm

after 10 years from date of purchase. Write the purchase date on the space

provided on back of unit.

speCial CoMplianCe ConsideraTions

This Smoke Alarm is suitable for use in apartments, condominiums,

townhouses, hospitals, day care facilities, health care facilities, boarding

houses, group homes and dormitories provided a primary fire detection

system already exists to meet fire detection requirements in common areas

lobbies, hallways, or porches. Using this Smoke Alarm in common areas

may not provide sufficient warning to all residents or meet local fire

protection ordinances/regulations.

This Smoke Alarm alone is not a suitable substitute for complete fire

detection systems in places housing many people—like apartment buildings,

condominiums, hotels, motels, dormitories, hospitals, health care facilities,

nursing homes, day care facilities, or group homes of any kind. It is not a

suitable substitute for complete fire detection systems in warehouses,

industrial facilities, commercial buildings, and special-purpose non-residential

buildings which require special fire detection and alarm systems. Depending

on the building codes in your area, this Smoke Alarm may be used to provide

additional protection in these facilities.

In new construction, most building codes require the use of AC or AC/DC

powered Smoke Alarms only. In existing construction, AC, AC/DC, or DC

powered Smoke Alarms can be used as specified by local building codes.

Refer to NFPA 72 (National Fire Alarm and Signaling Code) and NFPA 101

(Life Safety Code), local building codes, or consult your Fire Department for

detailed fire protection requirements in buildings not defined as “households”.

HUD MAP Program

Certain HUD battery powered Smoke Alarm applications, especially those

that fall under HUD 223(f) MAP (Multi-family Accelerated Processing), may

require a 10 Year sealed tamper resistant battery. This alarm does not meet

that requirement. Substitute First Alert SA340B.

Continued...

First Alert® is a registered trademark of the First Alert Trust used under license.

4 5 6 7

aBoUT sMoke alarMs

Battery (DC) operated Smoke Alarms: Provide protection even when

electricity fails, provided the batteries are fresh and correctly installed. Units

are easy to install, and do not require professional installation.

AC powered Smoke Alarms: Can be interconnected so if one unit senses

smoke, all units alarm. They do not operate if electricity fails.

AC with battery (DC) back-up: will operate if electricity fails, provided the

batteries are fresh and correctly installed. AC and AC/DC units must be

installed by a qualified electrician.

WIRELESS INTERCONNECT Smoke Alarms with battery (DC) back-up:

Interconnects with

all WIRELESS INTERCONNECT enabled Smoke and Smoke/CO Alarms

without wires or connectors, so when one alarm sounds, they all sound.

Will operate if electricity fails, provided the batteries are fresh and correctly

installed. Units are easy to install, and do not require professional installation.

Smoke Alarms for Solar or Wind Energy users and battery backup power

systems: AC powered Smoke Alarms should only be operated with true or

pure sine wave inverters. Operating this Smoke Alarm with most battery-

powered UPS (uninterruptible power supply) products or square wave or

“quasi sine wave” inverters . If you are not sure about will damage the Alarm

your inverter or UPS type, please consult with the manufacturer to verify.

Smoke Alarms for the hearing impaired: Special purpose Smoke Alarms

should be installed for the hearing impaired. They include a visual alarm and

an audible alarm horn, and meet the requirements of the Americans With

Disabilities Act. Can be interconnected so if one unit senses smoke, all units

alarm.

Smoke alarms are not to be used with detector guards unless the

combination has been evaluated and found suitable for that purpose.

All these Smoke Alarms are designed to provide early warning of fires if located,

installed and cared for as described in the user’s manual, and if smoke reaches

them. If you are unsure which type of Smoke Alarm to install, refer to Chapter

2 of the National Fire Protection Association (NFPA) Standard 72 (National

Fire Alarm and Signaling Code) and NFPA 101 (Life Safety Code). National

Fire Protection Association, One Batterymarch Park, Quincy, MA 02269-9101.

Local building codes may also require specific units in new construction or in

different areas of the home.

Printed in Mexico M08-0194-005 09/14Q

WhaT To do in Case oF Fire

• Don’t panic; stay calm. Follow your family escape plan.

• Get out of the house as quickly as possible. Don’t stop to get dressed or

collect anything.

• Feel doors with the back of your hand before opening them. If a door

is cool, open it slowly. Don’t open a hot door. Keep doors and windows

closed, unless you must escape through them.

• Cover your nose and mouth with a cloth (preferably damp). Take short,

shallow breaths.

• Meet at your planned meeting place outside your home, and do a head

count to make sure everybody got out safely.

• Call the Fire Department as soon as possible from outside. Give your

address, then your name.

• Never go back inside a burning building for any reason.

• Contact your Fire Department for ideas on making your home safer.

Alarms have various limitations. See “Limitations of Smoke Alarms” for

details.

Using The silenCe FeaTUre

The Silence Feature can temporarily quiet an unwanted alarm for up to

15 minutes. To use this feature, press the “Push to Test/Silence” button on

the cover. If the unit will not silence and no heavy smoke is present, or if

it stays in silence mode continuously, it should be replaced immediately.

The LED will continue to flash rapidly while in silence.

The Silence Feature does not disable the unit—it makes it temporarily

less sensitive to smoke. For your safety, if smoke around the unit is

dense enough to suggest a potentially dangerous situation, the unit will

stay in alarm or may re-alarm quickly. If you do not know the source of

the smoke, do not assume it is an unwanted alarm. Not responding to

analarmcanresultinpropertyloss,injury,ordeath.

silenCing The loW BaTTerY Warning

This silence feature can temporarily quiet the low battery warning “chirp” for

up to 8 hours. You can silence the low battery warning “chirp” by pressing

the Test/Silence button on the alarm cover.

Once the low battery warning “chirp” silence feature is activated, the unit

continues to flash the Green light twice a minute for 8 hours. After 8 hours, the

low battery “chirp” will resume. Replace the batteries as soon as possible;

this unit will not operate without battery power!

To deactivate this feature: Press the Test/Silence button again. The unit will

go into Test Mode and the low battery warning will resume (LED flashes and

unit sounds “chirp” once a minute).

To loCk The BaTTerY CoMparTMenT

Do not lock the battery compartment until you install the batteries and

test the Smoke Alarm.

If the unit does not alarm during testing,

DO NOT lock the battery compartment!

Install new batteries and test again. If the

Smoke Alarm still does not alarm, replace it

immediately.

1. Using needle-nose pliers, detach one

locking pin from the mounting bracket.

2. After batteries are inserted, then push

the locking pin through the hole near

the battery door latch on the back of the

Smoke Alarm.

opTional loCking FeaTUres

To loCk The MoUnTing BraCkeT

1. Using needle-nose pliers, detach one

locking pin from the mounting bracket.

2. Insert the locking pin through the hole on

the back of the Smoke Alarm as shown

in the diagram.

3. When you attach the Smoke Alarm to the

mounting bracket, the locking pin’s head

will fit into a notch on the bracket.

The optional locking features are designed to prevent unauthorized removal of the battery or alarm. It is not necessary to activate the locks in

single-family households where unauthorized battery or alarm removal is not a concern.

These Smoke Alarms have two separate locking features: one to lock the battery compartment, and the other to lock the

Smoke Alarm to the mounting bracket. You can choose to use either feature independently, or use them both.

Toolsyouwillneed:•Needle-nosepliers•Standardflatheadscrewdriver.

Both locking features use locking pins, which are molded into the mounting bracket. Depending on which locking features you

use, remove one or both pins from the mounting bracket using needle-nose pliers.

To permanently remove either locking pin, insert a flathead screwdriver between the locking pin and the lock, and pry

the pin out of the lock.

To UnloCk The BaTTerY CoMparTMenT

1. Remove the Smoke Alarm from the

mounting bracket. If the unit is locked to

the bracket, see the section “To Unlock

the Mounting Bracket.”

2. Insert a flathead screwdriver under the

head of the locking pin, and gently pry

it out of the battery compartment lock.

(If you plan to relock the battery

compartment, save the locking pin.)

3. To relock the battery compartment,

close the battery door and reinsert

locking pin in lock.

4. Reattach the Smoke Alarm to the

mounting bracket.

When replacing the batteries, always test

the Smoke Alarm before relocking the

battery compartment.

To UnloCk The MoUnTing BraCkeT

1. Insert a flathead screwdriver into the

rectangular cut-out on the mounting

bracket nearest to the locking pin.

2. Pry the Smoke Alarm away from

the bracket by pushing up on the

screwdriver and turning the Smoke

Alarm counterclockwise (left) at the

same time.

regUlar MainTenanCe

This unit has been designed to be as maintenance free as possible, but there

are a few simple things you must do to keep it working properly.

• Test it at least once a week.

• Clean the Smoke Alarm at least once a month; gently vacuum off any

dust using your household vacuum’s soft brush attachment, and test the

Smoke Alarm after cleaning. Never use water, cleaners or solvents since

they may damage the unit.

• If the Smoke Alarm becomes contaminated by excessive dirt, dust and/or

grime, and cannot be cleaned to avoid unwanted alarms, replace the unit

immediately.

• Relocate the unit if it sounds frequent unwanted alarms. See “Locations

to Avoid For Smoke Alarms” for details.

• When the battery becomes weak, the Smoke Alarm unit will “chirp”

approximately once a minute (the low battery warning). This low battery

warning should last for up to 7 days, but you should replace the battery

immediately to continue your protection.

Choosing a replacement battery:

Your Smoke Alarm requires 2 “AA” batteries: Energizer E91 or Duracell MN1500.

These batteries are available at many local retail stores.

• AlwaysusetheexactbatteriesspecifiedbythisUser’sManual.

DO NOT use rechargeable batteries. Clean the battery contacts and

also those of the device prior to battery installation. Install batteries

correctly with regard to polarity (+ and -).

• Pleasedisposeoforrecycleusedbatteriesproperly,followingany

local regulations. Consult your local waste management authority

or recycling organization to find an electronics recycling facility in

your area. DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES

MAY EXPLODE OR LEAK.

• Keepbatteryoutofreachofchildren.Intheeventabatteryis

swallowed, immediately contact your poison control center, your

physician, or the National Battery Ingestion hotline at 202-625-3333

asseriousinjurymayoccur.

Actual service life depends on the Smoke Alarm and the environment in

which it is installed. All the batteries specified above are acceptable

replacement batteries for this unit. Regardless of the manufacturer’s

suggested

battery life, you MUST replace the battery immediately once the unit starts

“chirping” (the “low battery warning”).

To replace the batteries (without

removing Alarm from the ceiling

or wall):

1. Open the battery compartment.

2. Press tabs A and B as shown in the

diagram and remove each battery.

3. Insert the new batteries, making sure

they snap completely into the battery

compartment. Match the terminals

on the ends of the batteries with the

terminals on the unit.

4. Close the battery compartment, and

then test the unit by pressing the Test/

Silence button.

adding and linking addiTional Wireless

inTerConneCT alarMs

• NEVERuseanopenflameofanykindtotestthisunit.Youmight

accidentally damage or set fire to the unit or to your home. The

built-in test switch accurately tests the unit’s operation as required

by Underwriters Laboratories, Inc. (UL).

• IftheAlarmeverfailstotestproperly,replaceitimmediately.

Products under warranty may be returned to the manufacturer for

replacement. See “Limited Warranty” for details.

• DONOTstandclosetothealarmwhenthehornissounding.

Exposure at close range may be harmful to your hearing. When

testing, step away when horn starts sounding.

It is important to test this unit every week to make sure it is working

properly. Using the test button is the recommended way to test this Smoke

Alarm. Press and hold the test button on the cover of the unit until the alarm

sounds (the unit may continue to alarm for a few seconds after you release

the button). If it does not alarm, make sure the unit is receiving power (LED

will flash approximately once a minute indicating it has power); and test it

again. If it still does not alarm, replace it immediately. During testing you will

hear a loud, repeating horn pattern: 3 beeps, pause, 3 beeps, pause.

NOTE: Steps 1 through 3 below need to be completed within two

minutes. If more than two minutes pass, the Green power LED will

stop blinking. Simply open the battery drawer of the second Alarm

and repeat steps 1 through 3.

1. Insert the batteries into the battery

drawer of the Alarm. next

DO NOT CLOSE THE DRAWER.

2. Press and hold the test button and

then close the battery drawer.

3. Once you hear the unit chirp, release

the test button. The Green power

LED will start to blink indicating the

WIRELESS INTERCONNECT Alarm is waiting for

program data from one of the other setup WIRELESS INTERCONNECT

Alarms.

4. Press and hold the test button on the first Alarm, until the second Alarm

chirps and its Green power LED stops blinking. Then release the test

button.

5. If you purchased a Talking Smoke Alarm, you will now be prompted to

set the Alarm’s location. Follow the directions given by the Alarm.

6. If you have purchased the hardwired battery back-up WIRELESS

INTERCONNECT Alarm, you can now connect the hardwired Alarm by

installing the three-wire connector on the ceiling to the Alarm.

7. Repeat steps 1-6 for additional WIRELESS INTERCONNECT Alarms.

You have now successfully linked your new WIRELESS INTERCONNECT

Alarms. To add additional Alarms at a later time, follow steps 1 through 6.

Wireless operaTion

First Alert

® WIRELESS INTERCONNECT Technology is the easy, cost-

effective way to provide your family with whole-home safety. All WIRELESS

INTERCONNECT Alarms communicate with each other without wires or

connectors. When one Alarm sounds, they all sound. This provides your family

with an earlier warning of potential danger, and gives you more time to react.

The communication distance (range) between any two WIRELESS

INTERCONNECT Alarms is typically 50 feet (15 meters) inside of a home.

Some features of a home, such as the number of floors, number/size of

rooms, furniture and types of building materials used may reduce the range

of the Alarms. Examples include: suspended ceilings, ductwork, large

metallic appliances (refrigerators) and metal studs. A feature of WIRELESS

INTERCONNECT Alarms is that they operate as a mesh network. All

Alarms will repeat any alarm signal that is received to all other WIRELESS

INTERCONNECT Alarms. Interference from structural conditions can be

overcome by adding additional Alarms to route the wireless signal around

obstructions.

• Therangeandproperoperationofanywirelessdevicewillvary

depending on its surroundings. It is very important that each Alarm is

tested individually before and after installation to make sure that all

Alarms respond properly.

• TheWIRELESS INTERCONNECT Alarms are not to be used outdoors

or to transmit between buildings. The Alarms will not communicate

properly under these conditions.

• Metalobjectsandmetallicwallpapermayinterferewithsignalsfrom

wireless Alarms. Alarms should be tested after changes to your

home such as remodeling, moving furniture, and with metal doors

opened and closed.

Your First Alert® WIRELESS INTERCONNECT Smoke Alarm will automatically

communicate potential fires with all other First Alert® WIRELESS

INTERCONNECT Smoke Alarms.

Changes or modifications not expressly approved by BRK Brands, Inc.

could void the user’s authority to operate the equipment.

Model SA511

iF YoU sUspeCT a proBleM

Smoke Alarms may not operate properly because of dead, missing or weak

batteries, a build-up of dirt, dust or grease on the Smoke Alarm cover, or

installation in an improper location. Clean the Smoke Alarm as described

in “Regular Maintenance,” and install a fresh battery, then test the Smoke

Alarm again. If it fails to test properly when you use the test button, or if

the problem persists, replace the Smoke Alarm immediately.

• Ifyouheara“chirp”aboutonceaminute,replacethebattery.

• Ifyouexperiencefrequentnon-emergencyalarms(likethosecaused

by cooking smoke), try relocating the Smoke Alarm.

• Ifthealarmsoundswhennosmokeisvisible,trycleaningor

relocating the Smoke Alarm. The cover may be dirty.

• Ifthealarmdoesnotsoundduringtesting,tryinstallinganew

battery, and make sure it is snapped in securely.

• Ifthealarmsounds3rapid“chirps”everyminute;LEDflashes

approximately once a minute. MALFUNCTION: the device is not

working properly and needs to be replaced.

Do not try fixing the alarm yourself – this will void your warranty!

If the Smoke Alarm is still not operating properly, and it is still under warranty,

please see “How to Obtain Warranty Service” in the Limited Warranty.

reCoMMended loCaTions For

sMoke alarMs

Installing Smoke Alarms in Single-Family Residences

The National Fire Protection Association (NFPA), recommends one Smoke

Alarm on every floor, in every sleeping area, and in every bedroom. In new

construction, the Smoke Alarms must be AC powered and interconnected.

See “Agency Placement Recommendations” for details. For additional

coverage, it is recommended that you install a Smoke Alarm in all rooms,

halls,

storage areas, finished attics, and basements, where temperatures normally

remain between 40˚ F (4.4˚ C) and 100˚ F (37.8˚ C). Make sure no door or

other obstruction could keep smoke from reaching the Smoke Alarms.

More specifically, install Smoke Alarms:

• On every level of your home, including finished attics and basements.

• Inside every bedroom, especially if people sleep with doors closed.

• In the hall near every sleeping area. If your home has multiple sleeping

areas, install a unit in each. If a hall is over 40 feet (12 meters) long, install

an alarm at each end.

• At the top of the first-to-second floor stairway, and at bottom of basement

stairway.

Specific requirements for Smoke Alarm installation vary from state to state

and from region to region. Check with your local Fire Department for current

requirements in your area. It is recommended AC or AC/DC units be

interconnected for added protection.

WIRELESS

INT ERCONNECT

ALARMS

agenCY plaCeMenT reCoMMendaTions

NFPA 72 Chapter 29

“For your information, the , NFPA 72, National Fire Alarm and Signaling Code

reads as follows:”

29.5.1* Required Detection.

29.5.1.1* Where required by other governing laws, codes, or standards for

a specific type of occupancy, approved single and multiple-station smoke

alarms shall be installed as follows:

(1)*In all sleeping rooms and guest rooms

(2)* Outside of each separate dwelling unit sleeping area, within 21 ft (6.4 m)

of any door to a sleeping room, with the distance measured along a path

of travel

(3) On every level of a dwelling unit, including basements

(4) On every level of a residential board and care occupancy (small facility),

including basements and excluding crawl spaces and unfinished attics

(5)*In the living area(s) of a guest suite

(6) In the living area(s) of a residential board and care occupancy

(small facility)

(Reprinted with permission from NFPA 72®, National Fire Alarm and Signaling

02269. This reprinted material is not the complete and official position of

the National Fire Protection Association, on the referenced subject which

is represented only by the standard in its entirety), (National Fire Alarm and

Signaling Code® and NFPA 72® are registered trademarks of the National Fire

Protection Association, Inc., Quincy, MA 02269).

Features:

WIRELESS INTERCONNECT

Enabled

Voice with Programmable Location

Two Latching Features

Optipath 360 Technology

Two Silence Features

inTrodUCTion

Thank you for choosing First Alert

® for your Smoke Alarm needs. You have

purchased a state-of-the-art Smoke Alarm designed to provide you with

early warning of a fire. Key features include:

WIRELESS INTERCONNECT Enabled. Alarm automatically communicates

with other WIRELESS INTERCONNECT enabled alarms when installed.

Exclusive Voice Warning with Location will tell you the preprogrammed

location of the initiating unit and danger detected. Programmable up to

11 locations (ex. “basement”). When alarms sounds, if programmed for

basement it will say “Warning, evacuate, smoke in basement” along with

all other installed WIRELESS INTERCONNECT Voice alarms.

Spread Spectrum Horn Tone. Lower and varying horn frequency makes it

easier for elderly with normal age related hearing loss to hear horn. Sweeps

through the 2200 – 3400 Hz range.

RF Interconnect. Reliable and secure radio frequency communication

between alarms. 915MHz frequency with 65,000 security codes and 3

channel frequency hopping.

Optipath 360 TechnologyTM provides 360 degrees of direct access to the

smoke sensor.

Single Button Test/Silence eliminates confusion. Depending on what mode

the alarm is in, pushing the button provides different functions such as

testing the alarm, silencing the alarm, re-testing the alarm when in silence and

clearing the Latching features.

Two Silence Features. Temporarily silence low battery chirp for up to eight

hours before replacing low battery or silence an unwanted alarm for several

minutes.

Two Latching Features. Alarm Latch: Easily identifies initiating alarm even

after alarm condition has subsided. Low Battery Latch: Identifies which unit

is in low battery condition.

Perfect Mount System includes a gasketless base for easy installation and

a mounting bracket that keeps the alarm secure over a wide rotation range

to allow for perfect alignment.

Distributed by BRK Brands, Inc.

3901 Liberty Street Road, Aurora, IL 60504-8122

Consumer Affairs: (800) 323-9005 • www.firstalert.com

laTChing FeaTUres

Alarm Latch is activated after an Alarm is exposed to alarm levels of smoke.

After smoke levels drop below alarm levels, the Red LED will begin to “Smoke”

flash On for 2 seconds/Off for 2 seconds. It will continue to flash or “latch” for

about 15 minutes, to give you time to determine which unit initiated the alarm.

Low Battery Latch is activated when the Alarm is in the “low battery condition”.

When this occurs, the LED flashes Green On for 2 seconds/Off for 2 Power

seconds for about 15 minutes. This feature is designed to help you identify

which Alarm needs to have the battery replaced. Although, the Alarm will

sound the low battery chirp approximately once every minute, sometimes

during the initial stages of “low battery”, the Alarm will chirp in greater

intervals than one minute, sometimes up to several hours, until the battery

reaches a steady low battery level. This innovative feature eliminates the

frustration of waiting for and/or identifying which unit is chirping.

sTep BY sTep gUide To prograMMing

This alarM

FOR FIRST TIME AND WHEN CHANGING BATTERIES

Action:

1. Insert batteries (2, AA batteries).

Alarm Will Say:

“Welcome, First Alert Smoke Alarm.”

“No location programmed” if

first time or “[Location, example:

“Basement”] location programmed”

when changing batteries.

“To select location, press and hold

test button now.”

2. Press & Hold Test Button if

you would like to program the

location or change the location of

the Alarm. Release button after

Alarm responds.

“To save location, press and hold

test button after location is heard.”

Alarm will speak list of locations

(see below).

3. After you hear the location of

where you are placing the Alarm,

Press & Hold the Test Button.

“[Location, example: “Basement”]

location saved.”

If no location is chosen:

“No location saved.”

Your Alarm has now been programmed for the location of your choice.

Available locations:

Basement Kitchen Child’s Bedroom

Living Room Dining Room Master Bedroom

Family Room No Location Guest Bedroom

Office Hallway Utility Room

WHAT YOU WILL SEE AND HEAR WITH THIS ALARM

Under Normal Operations

Voice: Silent

Horn: Silent

Power LED: Flashes Green once/minute

When You Test the Alarm

Voice: “Testing.” Horn: 3 beeps, pause, 3 beeps; “Warning, Voice:

evacuate smoke in [Location, example: “Basement”]. Evacuate.”

Smoke LED: Flashes Red in sync with the horn pattern

If Battery Becomes Low

Voice: “Replace battery in [Location, example “Basement”].”

Repeated every 5 hours

Horn: chirps once a minute

Power LED: Flashes Green On for 2 seconds/Off for 2 seconds.

Low Battery Latch is now engaged.

If Alarm is Not Operating Properly (MALFUNCTION SIGNAL)

Voice: “Detector error in [Location, example “Basement”], please see

manual.” Repeated every 5 hours

Horn: Three rapid chirps every minute

Smoke LED: Flashes approximately once a minute

Smoke is Detected

Horn: 3 beeps, pause, repeating 3 times

Voice: “Warning, evacuate smoke in [Location, example: “Basement”].

Evacuate.”

Smoke LED:

During Alarm: Flashes Red in sync with the horn pattern.

After Alarm: Flashes Red On for 2 seconds/Off for 2 seconds.

Smoke Alarm Latch is now engaged.

Smoke Alarm is Silenced

Horn: Off

Smoke LED: Flashes Red

hoW To insTall This sMoke alarM

The parTs oF This sMoke alarM

1. Test/Silence button

2. Battery drawer

3. Power indicator LED

4. Smoke Alarm LED

Tools YoU Will need:

This unit is designed to be mounted

on the ceiling, or on the wall if necessary.

• Pencil

• Drill with 3/16” (5 mm) drill bit

• Phillips screwdriver

• Hammer

• Pliers to activate optional

“tamper-resistant” locking

features

FolloW These siMple sTeps!

1. Hold base firmly and twist the mounting bracket counterclockwise to

separate it from the base.

2. Hold the mounting bracket against the ceiling (or wall) so the vertical

mounting slot is aligned in the 12 o’clock position and trace around the

inside of the mounting slots (vertical and horizontal mounting).

3. Put the unit where it won’t get covered with dust when you drill the

mounting holes.

4. Using a 3/16” (5 mm) drill bit, drill a hole through the center of the oval

outlines you traced.

5. Insert the plastic screw anchors (in the plastic bag with screws) into the

holes. Tap the screw anchors gently with a hammer, if necessary, until

they are flush with the ceiling or wall.

6. Line the mounting bracket up

over the plastic screw anchors.

7. Screw the mounting bracket to

the ceiling or wall through the

mounting slots using the two

screws provided.

8. Attach the Smoke Alarm to the

mounting bracket. Line up the guides on the alarm’s base with the

guides on the mounting bracket. When guides are lined up, turn the

base clockwise (right) until it snaps into place.

NOTE: Once the Smoke Alarm is snapped onto the mounting

bracket,youcanrotatetheSmokeAlarmtoadjustthealignment.

9. Test the Smoke Alarm. See “Weekly Testing.”

If you want to lock the battery drawer, or lock the Smoke Alarm to the

mounting bracket, please read the “Optional Locking Features” section

before you begin installation.

CONFORMS TO

UL STD 217

WeeklY TesTing

FCC Compliance

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that the interference will not occur in a

particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that of

the receiver.

• Consult the dealer or an experienced radio or TV technician for help.

Warning: Changes or modifications to the product, not expressly approved

by First Alert / BRK Brands, Inc., could void the user’s authority to operate

the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

FCC ID: M7U5001L

SPECIAL COMPLIANCE CONSIDERATIONS, Continued

Produktspezifikationen

Marke:	First Alert
Kategorie:	Nicht kategorisiert
Modell:	SA511B

Brauchst du Hilfe?

Wenn Sie Hilfe mit First Alert SA511B benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert First Alert

First Alert PRC700 Bedienungsanleitung

10 September 2024

First Alert SA511B Bedienungsanleitung

26 August 2024

First Alert KFE2S5 Bedienungsanleitung

25 August 2024

First Alert SCO500 Bedienungsanleitung

25 August 2024

First Alert FESA5 Bedienungsanleitung

25 August 2024

First Alert PIR725 Bedienungsanleitung

25 August 2024

First Alert WA100 Bedienungsanleitung

25 August 2024

First Alert SCO403 Bedienungsanleitung

5 August 2024

First Alert SA511CN2 Bedienungsanleitung

4 August 2024

First Alert SC7010BV Bedienungsanleitung

30 Juli 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024

AEG MECK52 Bedienungsanleitung

16 Oktober 2024

Makita UR012G Bedienungsanleitung

16 Oktober 2024

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024

IFM AC901S Bedienungsanleitung

16 Oktober 2024

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
