Seite 1/5

HOW YOUR CO ALARM WORKS - GENERAL INFORMATION

• CO Alarm contains a sealed, non-replaceable battery. Once it reaches the end of its service life, or after 10 years—whichever comes first—you must

install a new CO Alarm.

• High temperatures, low temperatures, high humidity, impact or dropping can adversely affect LCD displays.

A CO Alarm measures the CO levels in the air. It will alarm if CO levels rise quickly (if the heat exchanger on your furnace breaks, for example), or if CO is

consistently present (a slow CO leak on a fuel-burning appliance).

This carbon monoxide alarm features a permanently installed sensor, digital display with blue backlight, and an 85 dB alarm horn. It also has a silence feature to

temporarily quiet the alarm horn. During standby, the temperature is displayed in degrees F.

________________________________________________________________________________________________________________________________________

THE PARTS OF YOUR CO ALARM

1. Test Button

2. Activation + Deactivation tab (back of unit).

3. Silence Button

4. (Behind Cover) Alarm Horn: 85dB audible alarm for test, alarm, and

unit malfunction warning.

5. Peak level Button.

6. Digital Display with blue backlight.

1, 3, 5

________________________________________________________________________________________________________________________________________

UNDERSTANDING YOUR CO ALARM

Display glows and horn chirps when Alarm is first activated.

DIGITAL DISPLAY: All segments are turned on for a short time upon initial power.

Then the temperature is displayed in degrees F.

________________________________________________________________________________________________________________________________________

ALARM RECEIVING BATTERY POWER

Horn is silent. Temperature will be displayed in degrees F.

________________________________________________________________________________________________________________________________________

DURING TESTING

One beep sounds when you press button. It is later followed by a 4 beep pattern that comes twice.

DIGITAL DISPLAY:

Display glows and shows “tst”.

Several ppm CO levels are also displayed and the alarm level is shown increasing.

Continued...

® is registered trademark of The First Alert Trust • 3901 Liberty Street Road, Aurora, IL 60504-8122

Consumer Affairs: (800) 323-9005 • www.firstalert.com • www.brkelectronics.com • Printed in Mexico • M08-0534-001 • 4/15 W

IMPORTANT! PLEASE READ CAREFULLY AND SAVE.

The warnings/limitations card and manual contains important information about your Carbon Monoxide (CO) Alarm’s

operation. If you are installing this CO Alarm for use by others, you must leave this manual—or a copy of it—with the

end user. Reference product card for additional information.

USER’S MANUAL

CARBON MONOXIDE ALARM

10 YEAR SEALED BATTERY OPERATED CARBON

MONOXIDE ALARM WITH DIGITAL

DISPLAY AND SILENCE FEATURE

Model CO710

CONFORMS TO

UL STD 2034

UNDERSTANDING YOUR CO ALARM Continued..

CO ALARM: Sensor has detected enough CO to trigger an alarm. Blue backlight glows and horn sounds

loudly (repeating

4 beeps, pause)

. See “If Your CO AlarmSounds” for details. During an alarm, move

everyone to a source of fresh air. DO NOT move the CO Alarm!

DIGITAL DISPLAY:

“CO” alternating with the ppm number, a full level, and “EVACUATE”.

________________________________________________________________________________________________________________________________________

CO ALARM REQUIRES SERVICE (MALFUNCTION SIGNAL)

The horn sounds 3 “chirps” every minute. CO Alarm needs to be replaced.

DIGITAL DISPLAY: “Err” is displayed.

________________________________________________________________________________________________________________________________________

CO ALARM END OF LIFE

The horn sounds 5 chirps every minute. CO Alarm needs to be replaced.

DIGITAL DISPLAY: “End” is displayed.

________________________________________________________________________________________________________________________________________

USING THE PEAK CO MEMORY

The CO Memory Feature lets you check the highest level of CO recorded during an alarm.

NOTE: These bars will not appear when CO accumulation is low. The bars will be displayed

when unit is exposed for a longer time and CO accumulation is higher.

To check CO Memory:

1. Press and release the Test Button until the peak CO level is displayed.

To clear CO Memory:

1. Automatically resets after 24 hours.

2a. Press and release Test Button until blue backlight glows.

2b. Press and release Test Button to enter “clear mode”.

2c. Press and release Test Button quickly one more time to clear.

NOTE: Must press and release. Press and hold will run into “Test Mode”.

NOTE: The highest CO level will be saved for 24 hours. DO NOT clear the CO Memory reading if you plan to call someone to investigate a CO problem! Clear the CO

Memory reading only after the investigator has checked your home. If the investigator will not arrive within the 24 hour time period before the unit automatically

resets, be sure to write down the peak level.

________________________________________________________________________________________________________________________________________

INSTALLATION - WHERE TO INSTALL CO ALARMS

The National Fire Protection Association (NFPA) recommends that a CO Alarm should be centrally located outside of each separate sleeping area in the immediate

vicinity of the bedrooms. For added protection, install additional CO Alarms in each separate bedroom, and on every level of your home.

If your bedroom hallway is longer than 40 feet (12 meters), install a CO Alarm at BOTH ends of the hallway.

In a Single-level Home:

• Install at least one CO Alarm near or within each separate sleeping area.

• For added protection, install an additional CO Alarm at least 20 feet (6 meters) away from the

furnace or fuel burning heatsource.

In a Multi-level Home:

• Install at least one CO Alarm near or within each separate sleeping area.

• For added protection, install at least one CO Alarm on each level of the home. If you have a

basement, install that CO Alarm at the top of the basement stairs.

• For added protection, install an additional CO Alarm at least 20 feet (6 meters) away from the

furnace or fuel burning heat source.

In a Mobile Home:

• Install CO Alarms on inside walls ONLY. Uninsulated outside walls and roofs of mobile homes often

transfer heat and cold from outdoors.

GARAGE

SUGGESTED AREAS FOR INSTALLING ADDITIONAL CO ALARMS

BEDROOMBEDROOM

HALL

LIVING ROOM

KITCHEN

BASEMENT

BEDROOM

REQUIRED TO MEET NFPA RECOMMENDATIONS

________________________________________________________________________________________________________________________________________

WHERE CO ALARMS SHOULD NOT BE INSTALLED

DO NOT install this CO Alarm:

• In garages, kitchens, furnace rooms, or in any extremely dusty, dirty or greasy areas.

• Closer than 20 feet (6 meters) from a furnace or other fuel burning heat source, or fuel burning appliances like a water heater.

• Within 5 feet (1.5 meters) of any cooking appliance.

•

In extremely humid areas. This alarm should be at least 10 feet (3 meters) from a bath or shower, sauna, humidifier, vaporizer, dishwasher, laundry room, utility

room or other source of high humidity.

• In areas where temperature is colder than 40˚ F (4.4˚ C) or hotter than 100˚ F (37.8˚ C). These areas include unconditioned crawl spaces, unfinished attics,

uninsulated or poorly insulated ceilings, porches, and garages.

• In turbulent air, like near ceiling fans, heat vents, air conditioners, fresh air returns, or open windows. Blowing air may prevent CO from reaching the sensors.

• In direct sunlight.

HOW TO INSTALL YOUR CO ALARM

Read “Where To Install CO Alarms” before starting.

Before you start installation, find the pair of self-adhesive labels included with this CO Alarm. On each label write in the phone number of your emergency

responder (like 911) and a qualified appliance technician. Place one label near the CO Alarm, and the other label in the “fresh air” location you plan to go if the alarm

sounds.

NOTE: Activate alarm prior to mounting.

1. Activating the Battery. Move the activation switch to ON position. Utilize a small tool to help

activate switch if needed. Once unit is activated, it cannot be turned off.

NOTE: Horn chirps, and all segments are turned on for a short time upon activation.

2. Test the CO Alarm. See “Weekly Testing”.

3. To Permanently Deactivate The Alarm. This CO Alarm contains a sealed, non-replaceable battery.

Once it reaches the end of its service life, or after 10 years you must install a new CO Alarm. Deactivate

the CO Alarm by inserting a tool below edge where shown and break tab. Then slide activation switch to

DEACTIVATE mode.

NOTE: Once you deactivate this unit, it will not detect CO or alarm and cannot be reactivated.

4. This CO Alarm can either be wall mounted or placed on a tabletop. If Alarm is placed on a tabletop, be sure the Alarm is no more than 3 feet (0.9 meter) from

the floor to minimize the risk of causing permanent damage to the Alarm in the event that it is accidentally knocked to the ground.

________________________________________________________________________________________________________________________________________

TO MOUNT ON THE WALL

Tools you will need: pencil, drill with 3/16” or 5mm drill bit, flathead screwdriver, hammer, mounting template.

1. Choose a location on the wall. Do not install the Alarm closer than 4” (102 mm) from where the wall meets the ceiling.

2. Hold the mounting guide template against the wall, and make a mark inside each keyhole where you will drill your mounting holes as shown in the diagram

below.

3. Use a 3/16” (5 mm) drill bit to drill through the marks you made for the mounting holes.

4. Insert the plastic screw anchors into the mounting holes until they are flush with the wall. If necessary, tap them gently with a hammer.

5. Insert the screws into the anchors until the screwhead is 1/8 inch (3 mm) away from the wall.

6. Slide the CO Alarm onto the screws until you feel it click into place.

7. Test the CO Alarm as described in “Weekly Testing.”

________________________________________________________________________________________________________________________________________

IF YOUR CO ALARM SOUNDS

Actuation of your CO Alarm indicates the presence of carbon monoxide (CO) which can kill you. In other words, when your CO Alarm sounds, you must

not ignore it!

See “General Limitations of CO Alarms” for details included in the card packaged with alarm.

IF THE ALARM SIGNAL SOUNDS:

1. Operate the Silence button.

2. Call your emergency services, fire department or 911. Write down the number of your local emergency service here:

_________________________________________________________

3. Immediately move to fresh air—outdoors or by an open door or window. Do a head count to check that all persons are accounted for. Do not re-enter the

premises, or move away from the open door or window until the emergency services responder has arrived, the premises have been aired out, and your CO

Alarm remains in its normal condition.

4. After following steps 1-3, if your CO Alarm reactivates within a 24-hour period, repeat steps 1-3 and call a qualified appliance technician to investigate for

sources of CO from fuel-burning equipment and appliances, and inspect for proper operation of this equipment. If problems are identified during this inspection

have the equipment serviced immediately. Note any combustion equipment not inspected by the technician, and consult the manufacturers’ instructions,

or contact the manufacturers directly, for more information about CO safety and this equipment. Make sure that motor vehicles are not, and have not, been
