Solar Inverter
PVS-10/12.5/15-TL
Product Manual
EN
2
ATTENTION – AIMPORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions that must be followed during the installation and maintenance of the equipment.
ATTENTION – ASAVE THESE INSTRUCTIONS
Keep this document in a safe place near the inverter for easy access during installation, operation and maintenance.
The installer must read this document in its entirety and scrupulously follow the instructions given in it before installing this equipment,
since Fimer cannot be held responsible for damage caused to people and/or things, or the equipment, if the conditions described below
are not observed.
The purpose of this document is to support the qualified technician, who has received training and/or has demonstrated skills and
knowledge in construction, to install, operate and maintain the inverter. This manual covers the inverter only, and NO other equipment
(photovoltaic modules, external disconnects, etc) to which it is connected.
Warranty requirements are included in the Terms and Conditions of sale included with the inverter order.
NOTE – DAny changes made to the product or to the installation conditions that hasn’t been approved by Fimer will void the warranty.
NOTE – DAll pictures and illustrations shown in this user manual are indicatives and must be intended as support for installation
instruction only. Actual product may vary due to product enhancement. Specifications subject to change without notice. The latest
version of this document is available on the Fimer website.
The products are designed to be connected and communicate information and data via a network interface. It is the user’s sole
responsibility to provide and continuously ensure a secure connection between the product and the user’s network or any other network
(as the case may be). The user shall establish and maintain any appropriate measures (such as but not limited to the installation of
firewalls, application of authentication measures, encryption of data, installation of anti-virus programs, etc) to protect the product, the
network, its system and the interface against any kind of security breaches, unauthorized access, interference, intrusion, leakage and/
or theft of data or information. Fimer and its affiliates are not liable for damages and/or losses related to such security breaches, any
unauthorized access, interference, intrusion, leakage and/or theft of data or information. The data, examples and diagrams in this manual
are included solely for the concept or product description and are not to be deemed as a statement of guaranteed properties.
All persons responsible for applying the equipment addressed in this manual must satisfy themselves that each intended application is
suitable and acceptable, including that any applicable safety or other operational requirements are complied with. In particular, any risks
in applications where a system failure and/or product failure would create a risk for harm to property or persons (including but not limited
to personal injuries or death) shall be the sole responsibility of the person or entity applying the equipment, and those so responsible are
hereby requested to ensure that all measures are taken to exclude or mitigate such risks. This document has been carefully checked
by Fimer but deviations cannot be completely ruled out. In case any errors are detected, the reader is kindly requested to notify the
manufacturer. Other than under explicit contractual commitments, in no event shall Fimer be responsible or liable for any loss or damage
resulting from the use of this manual or the application of the equipment.
EN
3
Table of Content
1. Safety and accident prevention 7
1.1 Safety information and instructions 7
1.2 Symbols and signs 7
1.3 Installation and maintenance safety 8
1.3.1 General safety information 8
1.3.2 Environmental conditions and risks 8
1.3.3 Electrical and thermal safety 8
1.4 Residual risks 9
2. Introduction and general information 10
2.1 Warranty and supply conditions 10
2.1.1 Not incl uded in the supply c onditions 10
2.2 Scope and target audience 10
2.2.1 Purpose and document structure 10
2.2.2 List of appendix documents 10
2.2.3 Operator and maintenance personnel skills/prerequisites 10
2.3 Application area, general conditions 11
2.3.1 Intended or allowed use 11
2.3.2 Limits in field of use 11
2.3.3 Improper or prohibited use 11
3. Characteristics 12
3.1 General conditions 12
3.2 Identification of equipment and manufacturer 12
3.2.1 Regulatory and identification Label 12
3.2.2 Communication Identification label 13
3.3 Models and range of equipment 13
3.4 Component reference numbers 14
3.4.1 Inverter ex ternal view 15
3.5 Technical data 17
3.5.1 Technical data table 17
3.5.2 Tightening torques 19
3.5.3 Cable gland clamping range 19
3.5.4 Connectors cross section range 19
3.5.5 Overall dimensions of the inverter 20
3.5.6 Overall dimensions of the mounting bracket 20
