FS2CO
User Manual
Smart Carbon Monoxide Sensor
*Please read the user manual carefully before operation.
EN
Product introduction
This product is a smart carbon monoxide sensor, adopts super
low power consumption Zigbee wireless networking
technology, used for detecting carbon monoxide. Sensor
adopts high performance electrochemical sensor, support
sound and flash alarm, It has high stability, super low power
consumption, little sensitivity drift and many other features.
Free installation design, support instant bonding.
LED indicator
Networking Hole
Sensor Installation Base
Technical Data
1. Working Voltage：DC3V(CR123A Lithium Battery)
2.Static Current：≤ 20uA
3.Alarm Current：≤ 60mA
4.Alarm Sound：85dB/1m
5.Alarm Sensitivity：
30ppm 120mins alarm
50ppm 60-90mins alarm
100ppm 10-40mins alarm
300ppm 3mins alarm
6.Networking：ZigBee Ad-Hoc Networking
7.Wireless Networking Distance：≥ 70m（ ）open area
8.Working Temperature：-10oC〜 +50oC；
9.Environment Humidity： 95%RH
10.Dimension：60*60*49.2mm
Porady
1. This product can not be used for detecting natural
gas(methane), propane, butane and other combustible
gas.
2. Clean once a month, users may use household vacuum
cleaner and soft brush when cleaning.
3. Do not use cleanser or solvent wipe sensors, please
avoid spraying air freshener, hair spray, oil paint or other
aerosol near sensors.
4. Effective working life span is 5 years, suggest replace
every 5 years no matter there is fault or not. (Battery life
span is 3 years).
5. Please be attention when alarm happens. Shut-off
valves immediately, opening the window, make sure indoor
airiness. Besides using sensors correctly, users should
strengthen the consciousness of fire protection.
Installation
1.Install the sensor in bedroom and living area or anywhere CO
may leak, make sure each sleeping area can hear sound alarm
when choose installation position.
2.Avoid suppressing or falling down sensors, keep sensors
away from humid, high voltage, strong magnetic and children.
3.Do not suggest install sensors in garage, kitchen, boiler and
places where sensor may false alarm. Do not install in dirty,
dusty or greasy places, oily, dust or household chemicals may
damage internal sensor, and make sensor can not work
normally.
4.Sensors can support wall mounted or placing on the table,
household and travel essential.
Installation Drawing
To increase safety factors in single-layer house, suggest to
install at least a sensor in each bedroom and install a sensor
at 6m from chimney and gas fixture. To increase safety
factors in multi-layer house, suggest to install at least a
sensor in each bedroom, install at least one sensor in
basement. Please install a sensor at 6m from chimney and
gas fixture.
Bedroom Bedroon Bedroom
Livingroom
Kitchen
Basement
Gagrage
Aisle
minimum
opcjonal
Anticlockwise rotating the bracket out from the installation
base, then remove the battery insulating strip to make detector
on power.
Select the Smart Hub from the list of devices to which you want to
add a new device (sensor) or device with factory settings restored.
1.Click add devices on APP, entering networking mode.
Adding device
When the LED in the control
panel blinks blue, we confirm
and go to pairing devices.
2. According to the tips on APP, keep pressing networking
button, green LED flash quickly, tips appear on APP, green
LED keep on for 3 seconds, network success,
Delete device
In the application, click and hold the selected device, the "delete
device" command will be displayed. After removed it, disconnect
the network connection device by pressing and holding the pairing
button. 6-fold LED blink in green means disconnection of the
sensor network from the HUB.
13 14 15
16 17 18
10 11 12
* this device requires Ferguson Smart Hub unit to work, not included.
Screw the sensor into bracket, please remove the double sided
a dhesive membrane on the installation base, and stick on
the wall
CR1 23A
Status and battery replacement
Please replace battery correctly, following the battery positive and negative
electrode
Status LED indicator Alarm
Test
Warm up
Fault
Low power
Super Low Power
Usage Expiration Date
Red LED flash 4 times in 10 seconds
LED flash alternatively in three colors and then go out
Yellow LED flash twice
Yellow LED flash one time
Yellow LED keeps on
Yellow LED flash twice
“Di” four times
“Di”one time when power on
“Di”twice in 10 seconds
“Di” one time every 10 seconds
“Di” one time every 10 seconds
“Di”twice every 10 seconds
Troubleshooting and test
Please take following advices for reference if sensors can not work normally:
1.Replace battery in time, if voltage too low and reach effective life span.
(Check table 1 for status reference)
2.Please clean sensor if the fault resulted from dust or oil stain ( Check table
1 for status reference).
3.Make sure sensors screw into the base correctly.
Press test button on the product for 3 seconds, shows in above picture, till
alarm happens ( check table 1 for status reference).
Suggest test sensor at least once a week. Please pay attention once alarm
happens
Safety
1. Ferguson Sp. z o.o. is not responsible for damages caused by
improper use of the Ferguson Smart Home system.
2. Batteries attached to the device are not an integral part and not
a subject to complaint. The manufacturer is not responsible for
their proper operation.
3. Declared wireless ZigBee network’s range is based on
laboratory tests and applies to open space, keep in mind that the
materials used in the construction of houses and flats, wall
thickness and conditions of electromagnetic fields can cause a
significant reduction in network coverage.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative
consequences for the environmental and human
health.
More info
www.ferguson-digital.eu
and
wiki.ferguson.pl/en
Thanks!
Download app: Ferguson Smart
