Seite 1/19
USM-R-2023-V01
Envertech Corporation Ltd.
Tel: +86 6858 0086 21
Web www.envertec.com :
Email info@envertec.com :
Add: No.138, Xinjunhuan road, Minhang District, Shanghai, China
EVT8 -R00
User Manual
USM-R-2023-V01
Content
1. Important Safety Information ............................... 1
1.1 Read it First ............................................................... 1
1.2 Safety Instructions .................................................... 1
2. Envertech Microinverter System 1 ..........................
2.1 How it Works 2 ............................................................
2.2 Monitoring Device EnverBridge ................................ 2
2.3 Optimal Reliability 3 .....................................................
2.4 Simple Design ............................................................ 3
3. Product Information ............................................. 3
3.1 Overview ................................................................... 3
3.2 Major Characteristics ................................................ 3
3.3 Datasheet .................................................................. 3
4. Preparation .......................................................... 4
4.1 Packing Checklist ....................................................... 4
4.2 Product Description .................................................. 5
4.3 Further Information .................................................. 5
4.4 Symbols on Inverter .................................................. 5
4.5 Accessories ................................................................ 6
5. Microinverter System Installation 6 .........................
6. Debugging and Operating ..................................... 14
6.1 Energize the System .................................................. 14
6.2 Microinverter Operation 14 ...........................................
7. Troubleshooting and Maintenance ....................... 14
7.1 LED Status Indications and Error Reporting .............. 14
7.2 Troubleshoot an Inoperable Microinverter .............. 14
7.3 Disconnect Microinverters from PV Modules .......... 15
8. System Diagram ................................................... 16
9. Recycling and Disposal ......................................... 17
10. Contact ................................................................ 17
1
1. Important Safety Information
1.1 Read it First
This manual contains important instructions for the installation and maintenance
of the EVT800 microinverter.
To reduce the risk of electrical shock, and to ensure safe installation and
operation of the microinverter, the following safety symbols appear throughout
this document to indicate dangerous conditions and important safety
instructions.
1.2 Safety Instructions
Do not use Envertech equipment in a manner not specified by the
manufacturer. Doing so may cause death or injury to persons, or damage to
equipment.
Be aware that only qualified personnel should install or replace the Envertech
microinverters and the cables and accessories.
Do not attempt to repair the Envertech microinverter; it contains no user-
serviceable parts. If it fails, contact Envertech customer service to start the
replacement process. Tampering with or opening the Envertech microinverter
will void the warranty.
If the AC cable on the microinverter is damaged or broken, do not install the
unit.
Before installing or using the Envertech microinverter, read all instructions and
cautionary markings in the technical description and on the Envertech
microinverter system and the PV equipment.
Connect the Envertech microinverter to the utility grid only after you have
completed all installation procedures and received approval from the electric
utility company.
Please be kindly note that the Envertech microinverter itself is a heat sink.
Under normal operating conditions, its temperature is 20°C above ambient, but
under extreme conditions, the microinverter can reach a temperature of 90°C.
Do not disconnect the PV module from the Envertech microinverter without
rusty disconnecting AC power.
2. Envertech Microinverter System
The Envertech microinverter system is an on-grid microinverter system with
world-top-class technology. This manual gives details about the safe installation
and operation of the Envertech microinverter.
The three key elements of an Envertech microinverter system include:
EVT800 microinverter: Converting the DC of the PV module into AC
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which, if not
avoided, can result in death or serious injury or
moderate injury.
NOTICE indicates a situation that can result in property
damage, if not avoided.
