em-trak R300
HIGH PERFORMANCE
MARITIME
PRODUCTS
AIS Receiver
Product manual
www.em-trak.com
High performance marine products
Thank you for buying this AIS receiver.
This product has been engineered to offer you the highest level of
performance and durability and we hope that it will provide many years of
reliable service. We constantly strive to achieve the highest possible
quality standards. Should you encounter any problems with this product
please contact your dealer who will be pleased to offer whatever
assistance you require.
1 Notices .............................................................................. 1
1.1 Safety warnings.................................................................. 1
1.2 General notices .................................................................. 1
2 About your AIS receiver ..................... ..................... ........ 4
2.1 About AIS ........................................................................... 4
2.2 What's in the box?.............................................................. 5
3 Installation ........................................................................ 8
3.1 Preparing for installation..................................................... 8
3.2 Installation procedures ....................................................... 9
4 Operation ........................................................................ 17
4.1 Using the AIS receiver...................................................... 17
4.2 Indicator functions ............................................................ 17
5 Troubleshooting ............................................................. 18
6 Specifications ................................................................. 19
Figure 1 Items included with the product............................ 5
Figure 2 AIS receiver overview........................................... 6
Figure 3 Electrical connections to the AIS receiver............ 7
Figure 4 Typical installation................................................ 8
Figure 5 AIS receiver dimensions..................................... 10
Figure 6 AIS receiver mounting........................................ 11
Figure 7 Position of the VHF antenna connector.............. 12
Figure 8 Colour coding of wires in the
accessory cable.................................................. 13
Figure 9 Connecting to the NMEA0183 data port.............14
Figure 10 Connecting the power supply............................. 16
Figure 11 Indicator location on the AIS receiver unit..........17
Table of contents Table of figures
