Seite 1/7
MANUAL
FREQ
CONTROL
LINK
FREQ SOFT
HARD
FILTER 1 - MAIN
FILTER 1 - MAIN
FILTER 2
FILTER 2
NOISE
IN1 IN2and -this is an audio input of the filter. To operate in stereo or dual mono mode plug in stereo of 2 mono signals
here. If you plug just the and two filters are conneccted in series. If you plug input 1 and 2 and outputs 1 andIN1 OUT 2
2 two filters work in stereo (parallel mode). - switches on/off the unit. - use 12VDCPOWER ON POWER SUPPLY
adapter 0,5 - 1 A (center positive)
CV -you can control/automate filter cutoff
via CV using CV in. Led indicator mirrors the amount
of voltage in the input jack.
CV potentiometer attenuates CV applied to the filter
cutoff frequency.
CUTOFF - manual filter cutoff frequency
RESONANCE - Filter resonance (boost the
frequency near cutoff point)
MODE- Filter mode switch
LP - low pass
BP - band pass
HP - high pass
N- notch filter
LEVEL - controls the output level of filtered signal to
balance the volume.
DRY/WET - blends dry and filtered signals
CV in - connect control voltage standart mono minijack from
eurorack system
LINK CV - when switched on links CV on filter 1 to control
both filters 1 and 2
LINK FREQ - when switched on links FREQ CONTROL on
filter 1 to control both filters 1 and 2
There is a noise generator built in the filter. It can blend
noise to the audio signal
PINK/WHITE - switch two types of noise
LEVEL - controls the level of noise generator.
BALANCE - adjusts amount of noise signal going to filter 1
and 2
FREQ
CONTROL
NOISE
CONTROLS
Low Pass Band Pass Hi Pass Notch
FILTER MODES
POLYVOX PF3 double-stereo filter utilizes the classic Soviet filter chip for a unique and iconic filter tone.
This filter will make your sound dirty and angry. With the resonance turned up, you won't lose bass frequencies.
Two independent 12dB multi-mode filters that can be controlled by a single cutoff knob. Turning the filter into a
24dB filter, when connected in series. When connected in stereo, you can achieve interesting effects by using
different modes to each channel. A noise generator is on board pre-filter and can be used separately as a source
of white and pink noise. There are two types of noise - white and pink. You can choose the type of noise via
WHITE/PINK LEVEL BALANCEswitch. Adjust the volume and balance of the noise using the and pots in the
noise section. Volume as well as clean and processed signal balance per channel. Can be used as two independent
filters or stereo mode. - Lowpass, Bandpass, Hi-pass, Notch.FILTER modes HARD/SOFT switch lets you
choosse the character of the filter. The more resonance, more difference you can hear between hard and soft
mode. HARD POLYVOX SOFTmode is a classic filter mode, mode takes the dirt and impertinence out of the
sound. This mode used in MAESTRO synthesizer. The mode shifts the filter slope slightly, it sortNote: SOFT
of opens up. This is normal. You can use filter in three modes. When audio signal passes through the filter,
it is partially cuts some frequency content. There are four modes in this filter.
Low pass - removes frequency content above the cutoff frequency
High pass - removes frequency content below the cutoff frequency
Band pass - removes frequency content above and below the cutoff frequency
Notch - removes frequency content at the cutoff frequency
DESCRIPTION
To adjust cutoff frequency, use the control. To boost the volume near the cutoff frequensy turn theFREQ
RESONANCE LEVEL WET/DRYcontrol clockwise. control adjust the level of the filtered signal. control blends
direct and filtered signals in any proportion. For remote control of the cutof frequency, use the input jackCV
and the potentiometer to control amount of to cutoff. Led indicator near the jack mirrors theCV CV CV
control voltage applied to input. Polivoks PF-3 has two separate filters onboard. To control cutoff of bothCV
filters with the filter 1 cutoff pot and CV, switch on the link switch in the middle of the control panel.
WARNING
Before using the device, turn it on for 5-7 minutes and let it stand. The control
transistor should warm up. So that in SOFT mode there is no feedback when the FREQ
knobs are in zero position. If you overdo it.
The UD1208 chips used in the filter are very sensitive and are never the same.
Therefore you will not mathematically get two identical filters. Which is an advantage
when using the unit in stereo.
