042117DR www.elitescreens.com0
YardMaster Series | Model: OMS150/180H | User’sGuide
What’s in the Box
A. Screen material x 1
B. OMS150H / OMS180H
Steel tube x 16
C.CurvedStakex 4
D. Ring-Stake x 4
E.Guy-Ropex 4
F. M6*40 hex nutx 2
G. M6*40 hexagonal screwx 2
H.Carrying case x 1
I. Lock Pins (Spare parts) x 5
Frame Assembly
1.Start the assembly by matching the letters on the ends of the tubes and connect them
together as show on diagram above. For example, A to A, B to B etc.
2.E and Gare to be attached and securedwith the provided hexagonal screws.
Note: This step is done near the endof the assembly.
OMS150H/OMS180H
Produktspezifikationen
| Marke: | Elite Screens |
| Kategorie: | Projektionsfläche |
| Modell: | Yard Master 150" OMS150H |
| Breite: | 3600 mm |
| Tiefe: | 1000 mm |
| Gewicht: | 33700 g |
| Produktfarbe: | Weiß |
| Höhe: | 3078 mm |
| Befestigungstyp: | Flur |
| Fernbedienung enthalten: | Nein |
| Natives Seitenverhältnis: | 16:9 |
| Gehäusefarbe: | Schwarz |
| Einsehbare Bildschirmhöhe (H): | 1868 mm |
| Einsehbare Bildschirmbreite (B): | 3320 mm |
| Diagonal: | 150 " |
| Gesamte Bildschirmgröße (Höhe x Breite): | 186 x 331 cm |
| Leuchtdichtefaktor: | 1.1 |
