Owner’s Manual
ECD Series
Cast Iron
Sump Pumps
General Safety . . . . . . . . . . . . . . . . . . . . 2
Specications. . . . . . . . . . . . . . . . . . . . . 3
Installation. . . . . . . . . . . . . . . . . . . . 4 & 5
Troubleshooting . . . . . . . . . . . . . . . . . . . 6
Warranty . . . . . . . . . . . . . . . . . . . . . . . . 7
TABLE OF CONTENTS
ECD33 with
Wide Angle
Switch
ECD75
with Vertical
Switch
A sump pump is an electrical device designed to
operate in inherently wet environments.
ALWAYS USE EXTREME CAUTION
when installing or maintaining this product!
Need Help: Call 1-877-326-3561 for assistance;
Do Not Return to Store
Important Safety Instructions
Carefully read and follow all safety
instructions in this manual and on pump.
SAVE THESE INSTRUCTIONS – This manual
contains important instructions that should be
followed during installation, operation, and
maintenance of the product.
Save this manual for future reference.
Safety Labels
This is the safety alert symbol. When you
see this symbol on your pump or in this manual,
look for one of the following signal words and be
alert to the potential for personal injury!
Indicates a hazard which, if
not avoided, will result in death or serious injury.
Indicates a hazard which,
if not avoided, could result in death or serious
injury.
Indicates a hazard which, if
not avoided, could result in minor or moderate
injury.
NOTICE indicates practices not related to
personal injury.
Keep safety labels in good condition. Replace
missing or damaged safety labels.
General Safety
Risk of burns. Do not
touch an operating motor. Motors are de-
signed to operate at high temperatures. To
avoid burns when servicing pump, allow it to
cool for 20 minutes after shut-down before
handling.
Do not allow pump or any system compo-
nent to freeze. To do so will void warranty.
Pump water only with this pump.
Periodically inspect pump and system com-
ponents.
Wear safety glasses at all times when work-
ing on pumps.
Risk of explosion. Pump
body may explode if used as a booster
pump.
2
GENERAL SAFETY
STOP Before you start
For parts or assistance, call ECO-FLO Customer Service at 1-877 326-3561
3
For parts or assistance, call ECO-FLO Customer Service at 1-877 326-3561
APPLICATIONS
Ideal for High-Volume Water Removal from Basement Sump Pits and Window Wells
SPECIFICATIONS & PERFORMANCE
Capacity Cord Solids
Model HP Volt Ph Amps (GPH at 0’) Max Head Construction Impeller Length Pumped
ECD30W 1/4 115 1 3.5 2700 23’ Cast Iron Thermoplastic 8’ 1/2”
ECD30V 1/4 115 1 3.5 2700 23’ Cast Iron Thermoplastic 8’ 1/2”
ECD33W 1/3 115 1 5.0 3300 31’ Cast Iron Thermoplastic 8’ 1/2”
ECD33V 1/3 115 1 5.0 3300 31’ Cast Iron Thermoplastic 8’ 1/2”
ECD50W 1/2 115 1 8.0 4000 27’ Cast Iron Thermoplastic 8’ 1/2”
ECD50V 1/2 115 1 8.0 4400 27’ Cast Iron Thermoplastic 8’ 1/2”
ECD75W* 3/4 115 1 8.0 6000 34’ Cast Iron Thermoplsatic 8’ 3/4”
ECD75W* 3/4 115 1 8.0 6000 34’ Cast Iron Thermoplsatic 8’ 3/4”
* 2” MNPT x 1-1/2” FNPT Adapter included
ECD30/33/50 ECD75
327.8 [12.92]
221.8[8.73] SWITCH OFF
401.8[15.82] SWITCH ON
357.8 [14.10]
251.8[9.91] SWITCH OFF
431.8[17.0] SWITCH ON
327.8 [12.92]
