EFLH3080
E-fliteĀ® products are distributed exclusively by
Horizon Hobby, Inc.
4105 Fieldstone Road
Champaign, IL 61822
USA
Ā© 2009 Horizon Hobby, Inc.
US patent D578,146
Multiple patents pending
Horizon Hobby UK
Units 1-4 Ployters Rd
Staple Tye
Harlow, Essex
CM18 7NS
United Kingdom
Horizon Hobby Deutschland GmbH
Hamburger Strasse 10
25335 Elmshorn
Germany
DSM and DSM2 are trademarks or registered trademarks of Horizon Hobby, Inc.
The Spektrum trademark is used with permission of Bachmann Industries, Inc.
Spektrum radios and accessories are exclusively available from Horizon Hobby, Inc.
E-fliteRC.com
15761
Printed 6/09
Specifications
Length . . . . . . . . . . . . . . . . . . . . 7.5 in (190mm)
Height . . . . . . . . . . . . . . . . . . . . 3.5 in (90mm)
Main Rotor Diameter . . . . . . . . . 7.0 in (180mm)
Weight with Battery . . . . . . . . . . 1.0 oz (28 g)
Main Motor . . . . . . . . . . . . . . . . Coreless (1 installed)
Tail Motor . . . . . . . . . . . . . . . . . Micro coreless (1 installed)
Battery . . . . . . . . . . . . . . . . . . . 120mAh 1-Cell 3.7V 14C Battery Li-Po (2 included)
Charger . . . . . . . . . . . . . . . . . . . Celectra 4-Port 1-Cell 3.7V 0.3A DC Li-Po Charger
(included)
Power Supply . . . . . . . . . . . . . . . 6V, 1.5-Amp AC/DC Power Supply (included)
Onboard Electronics . . . . . . . . . . 5-in-1 receiver/servos/mixer/ESCs/gyro (installed)
BNF Instruction Manual
Note: Attempting to fly the helicopter without completely reading the manual
may cause injury to yourself and people in the vicinity, as well as damage to
the helicopter.
2
3
Introduction
Weighing in at under an ounce, the BladeĀ® mSR BNF takes ultra-micro helicopter
performance to the next level. Its unique Bell-Hiller rotor head design provides
the kind of speed and agility you would expect of a single-rotor heli but maintains
a measure of positive stability similar to a co-axial heli. This blend of agility and
stability makes it the ideal ānext stepā for someone moving up from a Blade CX3 or
Blade mCX.
Your Blade mSR BNF comes from the factory completely assembled and flight
tested. It includes 2 Li-Po flight batteries, a convenient 4-port DC Li-Po charger with
an AC adapter and 4 AA batteries for the transmitter. The mSRās onboard 5-in-
1 control unit combines the functions of a Spektrumā¢ 2.4GHz DSM2-compatible
receiver, mixer, gyro, motor ESCs and servos. This eliminates the need for difficult
electronic installation and setup while providing heading lock-like gyro performance
and precise proportional motor and servo response. All thatās left for you to do is
bind the 5-in-1 unit to the DSM2ā¢ transmitter of your choice.
While your mSR is essentially ready-to-fly right from the box, please take the time to
read through this manual for tips on battery safety and charging, control checks
and more before making your first flight. We also suggest viewing the
instructional video by clicking the link located on the product page for the Blade mSR
at www.e-fliterc.com.
Warning
An RC helicopter is not a toy! If misused, it can cause serious bodily harm and
damage to property. Fly only indoors, in open areas following all instructions and as
recommended in this manual. Keep loose items that can get entangled in the rotor
blades away from the main and tail blades, including loose clothing, or other objects
such as pencils and screwdrivers. Especially keep your hands away from the rotor
blades.
Note on Lithium Polymer Batteries
Lithium Polymer batteries are significantly more volatile than alkaline
or Ni-Cd/Ni-MH batteries used in RC applications. All manufacturerās
instructions and warnings must be followed closely. Mishandling of
Li-Po batteries can result in fire. Always follow the manufacturerās
instructions when disposing of Lithium Polymer batteries.
Table of Contents
Speciļ¬cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Introduction .....................................................3
Warning ........................................................3
Note on Lithium Polymer Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Additional Safety Precautions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Blade mSR BNF Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Additional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Preparing for First Flight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Flying Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Battery Warnings and Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Celectra 4-Port 1-Cell 3.7V 0.3A DC Li-Po Charger Instructions . . . . . . . . . . . . . . . .9
Celectra 4-Port Li-Po Charger Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Usage Guidelines, Warnings and Safety Precautions . . . . . . . . . . . . . . . . . . . . . . .12
Transmitter Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Additional Binding Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Installing the Flight Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Transmitter and Receiver Binding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Transmitter-Speciļ¬c Binding Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Transmitter Control Identiļ¬cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Control Test ....................................................20
Important Channel 5 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5-in-1 Control Unit Description, Arming and Motor Control Test . . . . . . . . . . . . . . . .24
Understanding the Primary Flight Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Choosing a Flying Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Optional Training Gear Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Flying the Blade mSR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Advanced Swashplate Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Precision Swashplate Calibration Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Exploded View Parts Listing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Optional Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Replacements and Optional Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
FCC Information .................................................47
CE Compliance Information for the European Union . . . . . . . . . . . . . . . . . . . . . . . .48
4
5
Additional Safety Precautions and Warnings
As the user of this product, you are solely responsible for operating it in a manner
that does not endanger yourself and others or result in damage to the product or
the property of others. Age Recommendation: 14 years or over. This is not
a toy. This product is not intended for use by children without direct adult
supervision.
This model is controlled by a radio signal that is subject to interference from many
sources outside your control. This interference can cause momentary loss of control
so it is advisable to always keep a safe distance in all directions around your model, as
this margin will help to avoid collisions or injury.
ā¢īNeverīoperateīyourīmodelīwithīlowītransmitterībatteries.
ā¢īAlwaysīoperateīyourīmodelīinīanīopenīareaīawayīfromīcars,ī
traffic, or people.
ā¢īAvoidīoperatingīyourīmodelīinītheīstreetīwhereīinjuryīorīdamageī
can occur.
ā¢īNeverīoperateītheīmodelīoutīintoītheīstreetīorīpopulatedīareasī
for any reason.
ā¢īCarefullyīfollowītheīdirectionsīandīwarningsīforīthisīandīanyīoptional
support equipment (chargers, rechargeable battery packs, etc.) that
you use.
ā¢īKeepīallīchemicals,īsmallīpartsīandīanythingīelectricalīoutīofītheī
reach of children.
ā¢īMoistureīcausesīdamageītoīelectronics.īAvoidīwaterīexposureītoīallī
equipment not specifically designed and protected for this purpose.
ā¢īNeverīlickīorīplaceīanyīportionīofīyourīmodelīinīyourīmouthīasīitī
could cause serious injury or even death.
Blade mSR BNF Contents
Item Description
Not Available Separately . . . . . . . . . . . . . Blade mSR BNF Airframe
EFLB1201S . . . . . . . . . . . . . . . . . . . . . . 120mAh 1-Cell 3.7V 14C Li-Po
EFLC1004 . . . . . . . . . . . . . . . . . . . . . . . Celectra 4-port 1-Cell 3.7V 0.3A DC
Li-Po Charger
EFLC1005 . . . . . . . . . . . . . . . . . . . . . . . 6V, 1.5-Amp AC/DC Power Supply
EFLH1209 . . . . . . . . . . . . . . . . . . . . . . . Screwdriver
Additional Equipment
No additional equipment other than your favorite DSM2 Compatible Aircraft
Transmitter is required to complete your Blade mSR BNF. If you choose to make
your EFLC1004 Celectra 4-port charger portable, you may install (4) optional D-size
Alkaline Batteries (FUG7100).
