Specifications
Length .................................................7.9 in (200mm)
Height .................................................4.7 in (120mm)
Main Rotor Diameter .............................7.5 in (190mm)
Weight with Battery ...............................1.0 oz (28 g)
Main Motor ..........................................Micro coreless (2 installed)
Battery .................................................1S 3.7V 110mAh LiPo (included)
Charger ................................................1S 3.7V DC LiPo (included)
Transmitter ..........................................MLP4DSM 2.4GHz DSM2 4-channel (included)
On-Board Electronics .............................5-in-1 receiver/servos/mixer/ESCs/gyro (installed)
RTF Instruction Manual
Introduction
As an ultra micro-sized version of the Blade Ā® CX/CX2, the Blade mCX offers
first-time pilots the ability to learn how to fly with ease and experienced
heli pilots the ability to fly anywhere, anytime. The Blade mCX offers
unsurpassed stability and incredible control through the coaxial, counter-
rotating head design and Spektrumā¢ 2.4GHz DSM2ā¢ technology. And,
thanks to its rotor span of just 7.5 inches and one ounce flying weight, the
Blade mCX can be flown indoors almost anywhereāfrom an office to a
small bedroom or living room.
The Blade mCX comes 100% factory-assembled, flight-tested and ready
to fly right out of the boxāno assembly or setup required. Included in the
box is the LiPo flight battery and convenient AA battery-powered DC LiPo
charger, 4-channel transmitter equipped with Spektrum 2.4GHz DSM2
technology, and 8 AA batteries (4 for the transmitter, 4 for the charger). The
DSM2 technology offers freedom from frequency restrictions and allows the
Blade mCX to be flown anywhere, anytime with full 4-channel control.
And although the Blade mCX is ready-to-fly right from the box, please take
the time to read through this manual for tips on battery safety and charging,
control checks and more before making your first flight. We also suggest
viewing the Instructional Video located on the product page for the Blade
mCX on www.e-fliterc.com.
Warning
An RC helicopter is not a toy! If misused, it can cause serious bodily harm
and damage to property. Fly only indoors, in open areas following all
instructions and as recommended in this manual. Keep loose items that
can get entangled in the rotor blades away from the main and tail blades,
including loose clothing, or other objects such as pencils and screwdrivers.
Especially keep your hands away from the rotor blades.
Table of Contents
Speciļ¬cations ......................................................................................... 1
Introduction ............................................................................................ 3
Warning .................................................................................................. 3
Note on Lithium Polymer Batteries ............................................................ 4
Instructions for Disposal of WEEE by Users in the European Union ............ 4
Additional Safety Precautions and Warnings ............................................... 4
FCC Information ...................................................................................... 5
Blade MCX RTF Contents ......................................................................... 6
Additional Equipment ............................................................................... 6
Preparing for the First Flight Checklist ....................................................... 6
Flying Checklist ....................................................................................... 7
Battery Warnings and Guidelines ............................................................... 7
Battery Charging ................................................................................... 10
Installing the Transmitter Batteries .......................................................... 11
Installing the Flight Battery ..................................................................... 11
Transmitter Control Identiļ¬cation ............................................................ 12
Control Test .......................................................................................... 13
5-in-1 Control Unit Description, Arming and Motor Control Test .................. 16
Understanding the Primary Flight Controls ............................................... 19
Dual Rates ............................................................................................ 22
Choosing a Flying Area .......................................................................... 23
Flying the Blade MCX ............................................................................. 24
Transmitter and Receiver Binding ............................................................ 26
Exploded View Parts Listing ................................................................... 27
Exploded View....................................................................................... 29
Replacement Parts List .......................................................................... 30
Optional Parts List ................................................................................. 31
Warranty Period .................................................................................... 31
Limited Warranty ................................................................................... 31
Damage Limits ...................................................................................... 32
Safety Precautions ................................................................................ 32
Questions, Assistance and Repairs ......................................................... 33
Inspections or Repairs ........................................................................... 33
Warranty Inspection and Repairs ............................................................. 34
Non-Warranty Repairs ............................................................................ 34
Product Registration .............................................................................. 35
2 3
ā¢īNeverīoperateītheīmodelīoutīintoītheīstreetīorīpopulatedīareasī
for any reason.
ā¢īCarefullyīfollowītheīdirectionsīandīwarningsīforīthisīandīanyīoptional
support equipment (chargers, rechargeable battery packs, etc.) that
you use.
ā¢īKeepīallīchemicals,īsmallīpartsīandīanythingīelectricalīoutīofītheī
reach of children.
ā¢īMoistureīcausesīdamageītoīelectronics.īAvoidīwaterīexposureītoīallī
equipment not specifically designed and protected for this purpose.
ā¢īNeverīlickīorīplaceīanyīportionīofīyourīmodelīinīyourīmouthīasīitī
could cause serious injury or even death.
FCC Information
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the party
responsible for compliance could void the userās authority to operate the
equipment.
This product contains a radio transmitter with wireless technology which
has been tested and found to be compliant with the applicable regulations
governing a radio transmitter in the 2.400 GHz to 2.4835 GHz frequency
range.
The associated regulatory agencies of the following countries recognize the
noted certifications for this product as authorized for sale and use:
Note on Lithium Polymer Batteries
Lithium Polymer batteries are significantly more volatile than
alkaline or Ni Cd/Ni MH batteries used in RC applications. All
manufacturerās instructions and warnings must be followed
closely. Mishandling of Li-Po batteries can result in fire. Always
follow the manufacturerās instructions when disposing of
Lithium Polymer batteries.
Instructions for Disposal of WEEE by Users
in the European Union
This product must not be disposed of with other waste. Instead, it is the
userās responsibility to dispose of their waste equipment by handing it over
to a designated collections point for the recycling of waste electrical and
electronic equipment. The separate collection and recycling
of your waste equipment at the time of disposal will help to
conserve natural resources and ensure that it is recycled in
a manner that protects human health and the environment.
For more information about where you can drop off your
waste equipment for recycling, please contact your local city
office, your household waste disposal service or where you
purchased the product.
Additional Safety Precautions and Warnings
As the user of this product, you are solely responsible for operating it in a
manner that does not endanger yourself and others or result in damage to
the product or the property of others.
This model is controlled by a radio signal that is subject to interference from
many sources outside your control. This interference can cause momentary
loss of control so it is advisable to always keep a safe distance in all
directions around your model, as this margin will help to avoid collisions or
injury.
ā¢īNeverīoperateīyourīmodelīwithīlowītransmitterībatteries.
ā¢īAlwaysīoperateīyourīmodelīinīanīopenīareaīawayīfromīcars,ī
traffic, or people.
ā¢īAvoidīoperatingīyourīmodelīinītheīstreetīwhereīinjuryīorīdamageī
can occur.
4 5
