EV-DW4975 Vanishing Door/Window Contact
Installation Manual
Introduction
The EV-DW4975 is the industries thinnest supervised
door/window contact allowing a multitude of applications
while hiding the transmitter on a door or window frame. The
EV-DW4975 uses a replaceable lithium battery and should
last 5 years under normal usage.
Install or Replacing the Battery
The EV-DW4975 uses a Panasonic CR2032 Lithium Battery
and is shipped not installed to save battery life.
Follow the steps below to install or replace the battery.
1) Using a coin (Figure 1) or a flat head screw driver (Figure 2)
insert into the notch located on the case and gently twist to
open. Lift up and pull the case outward to open (Figure 3).
2) Insert Battery (figure 4) + side facing UP.
Use care when installing the battery and observe the correct
polarity when the battery is inserted. Use only Panasonic
Lithium CR2032 batteries for replacement.
WARNING!: Battery may explode if mistreated.
Do not recharge, disassemble or dispose of in fire.
Mount Transmitter and Magnet
1) Mount the EV-DW4975 on any window or door frame using the supplied
double strick tape or screws (Figure 5).
2) Find the notch on the outside of the EV-DW4975 enclosure. Align the
magnet with the notches and ensure that the distance is no greater than
5/8 of an inch (Figure 6).
Enrolling
Refer to your installation manual for enrolling wireless devices into a
DSC control panel.
Specifications
• Frequency 433.92
• Transmission: ASK
• Operating Temperature: -10C-+50C
• Nominal Battery Life: 5 Years. Varies with Usage and Temperature
• Battery Type: Panasonic CR2032
FCC COMPLIANCE STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
IC: The term ‘IC:’ before the radio certification number only signifies that Industry Canada technical specifications were met.
Figure 3 Figure 4
Figure 1 Figure 2
Figure 5
Figure 6
Technical Support:
(866) 908-TECH (8324)
©2006 Secure Wireless
EV-DW4975 Vanishing Door/Window Contact
Installation Manual
Introduction
The EV-DW4975 is the industries thinnest supervised
door/window contact allowing a multitude of applications
while hiding the transmitter on a door or window frame. The
EV-DW4975 uses a replaceable lithium battery and should
last 5 years under normal usage.
Install or Replacing the Battery
The EV-DW4975 uses a Panasonic CR2032 Lithium Battery
and is shipped not installed to save battery life.
Follow the steps below to install or replace the battery.
1) Using a coin (Figure 1) or a flat head screw driver (Figure 2)
insert into the notch located on the case and gently twist to
open. Lift up and pull the case outward to open (Figure 3).
2) Insert Battery (figure 4) + side facing UP.
Use care when installing the battery and observe the correct
polarity when the battery is inserted. Use only Panasonic
Lithium CR2032 batteries for replacement.
WARNING!: Battery may explode if mistreated.
Do not recharge, disassemble or dispose of in fire.
Mount Transmitter and Magnet
1) Mount the EV-DW4975 on any window or door frame using the supplied
double strick tape or screws (Figure 5).
2) Find the notch on the outside of the EV-DW4975 enclosure. Align the
magnet with the notches and ensure that the distance is no greater than
5/8 of an inch (Figure 6).
Enrolling
Refer to your installation manual for enrolling wireless devices into a
DSC control panel.
Specifications
• Frequency 433.92
• Transmission: ASK
• Operating Temperature: -10C-+50C
• Nominal Battery Life: 5 Years. Varies with Usage and Temperature
• Battery Type: Panasonic CR2032
FCC COMPLIANCE STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
IC: The term ‘IC:’ before the radio certification number only signifies that Industry Canada technical specifications were met.
Figure 3 Figure 4
Figure 1 Figure 2
Figure 5
Figure 6
Technical Support:
(866) 908-TECH (8324)
©2006 Secure Wireless
