Seite 1/15
SINGLE CHANNEL
Single Channel
Timeswitch
06490197001 ISSD
Lifestyle
INSTALLATION INSTRUCTIONS
PLEASE NOTE: INSTALLATION MUST ONLY BE
CARRIED OUT BY A QUALIFIED ELECTRICIAN OR
HEATING ENGINEER.
MAKE SURE MAINS INPUT HAS A 3 AMP FUSE.
2
Schneider Electric
35 Rue Joseph Monier
France- 92500 Rueil Malmaison
se.com/contact
Schneider Electric
401 Southway Drive
Plymouth
PL6 6QT
United Kingdom
The Lifestyle Programmer conforms to the essential
requirements of these Directives:
2014/30/EU- Electromagnetic Compatibility Directive
2014/35/EU- Low Voltage Directive
2012/19/EU WEE Directive
2003/66/EC Battery Directive
Technical Helpline Tel: 0333 6000 622
customer.care@draytoncontrols.co.uk
Website: www.draytoncontrols.co.uk
Quick Commissioning Guide
06490197001 IssD
3
BEFORE INSTALLATION
First, make sure the mains supply is switched off!
USING AN EXISTING WALL-PLATE
Loosen the securing screws on the old timeswitch and unplug it.
Check that there’s 70mm clearance to the right of the wall-plate,
and 25mm above it. Now plug the Lifestyle unit into the wall-
plate and tighten the securing screws. Check the 3A fuse, and
switch on the mains.
FITTING A NEW WALL-PLATE
The ideal location is 1.4m above floor level, with reasonable
lighting, good access, no condensation, no extremes of
temperature, and a supporting surface that fully covers the back
of the unit.
Position with 70mm clearance to the right, 25mm above, and
sufficient room to access the securing screws underneath.
Fix, with terminals at the top, either direct to a flat wall using wall
plugs and no. 6 x 1" woodscrews, or on a flush mounting single
conduit box type UA1 (BS4662) using M3.5 x 14 bolts. DO NOT
USE A SURFACE MOUNTING BOX.
WIRING THE TIMESWITCH WALL PLATE
For surface wiring, snap out the cable entry strip on the bottom
edge of the wall-plate. Lifestyle units are double-insulated and
need no earth connection, but an earthing continuity (loop)
terminal is provided for convenience.
