Seite 1/4
Receiving and Shipping ............................................................................ 2
Operation ................................................................................................ 3-4
Cleaning / Maintenance ............................................................................ 5
Parts Identification ..................................................................................... 6
Warranty ..................................................................................................... 8
CONTENTS
16”x20” / 15”x15” Air Automatic Heat Transfer Machines
For Customer Service, Call (620) 231-8568
or Visit www.doughxpress.com
OWNER’S MANUAL
TXM-15-CP
“Little Chick”
1201 E. 27th Terrace • Pittsburg, KS 66762 • U.S.A.
(620) 231-8568 • Fax: (620) 231-1598
E-Mail: mail@hixcorp.com • Website: www.doughxpress.com
WARRANTY
NOTICE
Our system will automatically register the equipment on the date it was shipped. If the
equipment was not purchased directly from HIX, but through a distributor (either domestic
or foreign), please keep a copy of their sales invoice showing the serial number and date
it was sold/shipped to you with this warranty. In this case, we will use the distributor’s
invoice date as the beginning warranty date. STAPLE A COPY OF YOUR RECEIPT TO
THIS WARRANTY and keep in a safe place to provide verification of your warranty
should a problem occur. Thank you.
Please fill in the following information and attach a copy of your receipt for your records.
Date Purchased: _______________________ From:_____________________________
Model #: ______________________________ Serial #:___________________________
This warranty applies to equipment manufactured by the HIX Corporation (HIX),
Pittsburg, Kansas, U.S.A. HIX warrants to the original purchaser its Dough, Tortilla and
Poultry Presses against defects in workmanship and material, except for wear and tear
for a period of “One Year” from the date of purchase. All dough press carts, compres-
sors, and accessories are warranted for 90 days from the date of purchase.
In the event of a defect, HIX, at its option, will repair, replace or substitute the defective
item at no cost during this period subject to the limitations of insurance and shipping costs
stated below.
This warranty does not cover normal wear and tear, damages due to accident, misuse/
abuse, alterations or damage due to neglect or lack of proper lubrication or maintenance.
HIX shall not be responsible for repairs or alterations made by any person without the
prior written authorization by HIX. This warranty is the sole and exclusive warranty of
HIX and no person, agent, distributor, or dealer of HIX is authorized to change, amend or
modify the terms set forth herein, in whole or in part.
In the case of a problem with the equipment identified herein, HIX Corporation should be
contacted during regular business hours to discuss the problem and verify an existing
warranty. HIX personnel will assist the customer to correct any problems which can be
corrected through operation or maintenance instructions, simple mechanical adjustments,
or replacement of parts. In the event the problem cannot be corrected by phone, and
upon the issuance of a return authorization by HIX, the equipment shall be returned to HIX
or an authorized service representative. All insurance and shipment/freight costs are
solely the responsibility of the customer, and not that of HIX, and HIX shall not be
responsible for improper handling or damage in transit. HIX customer service personnel
may be contacted for complete return authorization and reconditioning information.
This expressed warranty is given in lieu of any and all other warranties, whether
expressed or implied, including but not limited to those of merchantability and fitness for a
particular purpose, and constitutes the only warranty made by HIX Corporation.
In no event shall HIX’s liability for breach of warranty extend beyond the obligation to
repair or replace the nonconforming goods. HIX shall not be liable for any other damages,
either incidental or consequential, or the action as brought in contract, negligence or
otherwise.
This warranty gives you specific legal rights and you may also have other rights which
vary from state to state.
BEFORE warranty repair you MUST get
Prior Authorization: Call 1-800-835-0606
Warranty will be voided otherwise.
©2007 HIX Corp. 4TXM15CP082807
Food Equipment
72
RECEIVING AND SHIPPING
UNPACKING
Remember to save all packing materials - including box, liner
and board. You may need these for shipping your machine or
if a repair is necessary in the future.
INSPECTION
Inspect your machine for hidden shipping damage. Contact
the delivery company immediately, should you find damage.
SHIPPING OR RETURNS
NOTE: Save all of your shipping/packing materials.
DO NOT RISK COSTLY SHIPPING DAMAGE!
SHIP ONLY IN ORIGINAL BOX.
1. Fasten machine to plywood shipping base with bolts provided.
2. Make sure handle is pressed down so that the heat platen will
not swing around during shipment.
3. Place in original box, and put side liner and top liner in place.
Fold in flaps and seal the box.
(Additional bottom boards, box and liners may be obtained
from your supplier for a nominal cost.)
Left Blank
3
OPERATIONPARTS IDENTIFICATION
INSTALLATION
1. Lift press from box and place on cart, if you purchased one
with the press. Align legs with holes in top of cart and bolts
(supplied) fasten to cart. you will need a 9/16 wrench.
2. If press is to be placed on counter top stick black plastic foot
pad on the bottom of the legs.
PRESSURE
1. The pressure control knob, located at the top / rear of the
machine, should be set so that the head will lock down firmly
with your product in place.
2. Pressure is reduced by turning knob (with machine open)
counter-clockwise and increased by turning it clockwise.
NOTE: Adjustments may be required from one product to
another and will vary to achieve the desired result.
CAUTION: Excessive pressure can cause structural
damage, voiding the machine warranty!
Parts List
ITEM QTY PART NUMBER DESCRIPTION
2 1 9142000 PIVOT ARM WELDMENT
3 1 9141009 BOLT, ANTI-ROTATION
4 1 9141000-FRAME
WELDMENT
FRAME WELDMENT
6 1 62898 KNOB
12 1 35181 TOGGLE CLAMP
SWINGMAN METRIC
15.7 1 9160002 PLATEN, 15x15
15.8 1 9161001 TOP COVER
16 1 59883 LOWER PLATEN
17 1 68446 BULB SEAL
4
12
6
16
2
15.8
15.7
3
17
6
