Operating manual
WBGT index
HD32.2
www.deltaohm.com
English
Keep for future reference.
Companies / Brands of GHM
HD32.2 - 2 - V1.4
TABLE OF CONTENTS
1. GENERAL FEATURES ...................................................................................................................................... 3๎
2. WORKING PRINCIPLE ..................................................................................................................................... 6๎
3. USER INTERFACES ........................................................................................................................................... 8๎
3.1 THE DISPLAY ...................................................................................................................................................... 8๎
3.2 T HE KEYBOARD ................................................................................................................................................. 9๎
4. WORKING ..........................................................................................................................................................11๎
4.1.1 The measurement โUnitโ .........................................................................................................................12๎
4.1.2 The immediate printing of the data ...........................................................................................................12๎
4.1.3 The maximum, minimum and medium values of the detected sizes .............................................................12๎
4.1.4 Instrument setting ....................................................................................................................................13๎
4.1.5 Start a memorization section (Logging) ....................................................................................................13๎
5. THE MAIN MENU .............................................................................................................................................14๎
5.1 I NFO ABOUT MENU ..........................................................................................................................................14๎
5.2 L M OGGING ENU ..............................................................................................................................................16๎
5.2.1 Log Interval .............................................................................................................................................16๎
5.2.2 Self Shut-off mode โ The automatic switching off ......................................................................................17๎
5.2.3 Start/stop time โ The automatic start ........................................................................................................18๎
5.2.4 Cancel auto start .....................................................................................................................................19๎
5.2.5 Log File Manager ....................................................................................................................................21๎
5.3 S ( ERIAL MENU SERIAL COMMUNICATION)..........................................................................................................24๎
5.3.1 Baud Rate ...............................................................................................................................................25๎
5.3.2 Print Interval ...........................................................................................................................................25๎
5.4 R ESET..............................................................................................................................................................26๎
5.5 C ONTRAST .......................................................................................................................................................26๎
6. PROBES AND MEASUREMENTS ....................................................................................................................27๎
6.1 Instruction, accuracy and maintenance of the probes ..................................................................................31๎
7. SERIAL AND USB INTERFACES ....................................................................................................................32๎
7.1 T HE DATA MEMORIZATION AND THE DATA TRANSFER TO A PC ...........................................................................34๎
7.1.1 Logging function......................................................................................................................................34๎
7.1.2 Erase function: cancellation of the memorized data ..................................................................................34๎
7.1.3 Print function ..........................................................................................................................................34๎
9. INSTRUMENT SIGNALS AND FAULTS .........................................................................................................35๎
10. BATTERY SYMBOL AND BATTERY REPLACEMENT โ MAIN POWER SUPPLY ................................36๎
10.1 WARNING ABOUT THE BATTERIES USE .............................................................................................................36๎
11. INSTRUMENT STORAGE ..............................................................................................................................37๎
12. PRINTING OF THE MEASUREMENT REPORT .........................................................................................38๎
13. NOTES ON WORKING AND OPERATING SAFETY...................................................................................44๎
14. TECHNICAL CHARACTERISTICS ...............................................................................................................45๎
15. ORDERING CODES .........................................................................................................................................48๎
15.1 PROBES FOR HD32.2 WBGT INDEX.............................................................................................................48๎
HD32.2 - 3 - V1.4
1. GENERAL FEATURES
HD32.2 is designed for WBGT (Wet Bulb Globe thermometer temperature) index analysis in pres-
ence or absence of solar radiation. The instrument is provided with three inputs for probes with SI-
CRAM module: the probes have an electric circuit that communicates with the instrument; the sen-
sor calibration data are saved in its permanent memory.
All the SICRAM probes can be inserted in one of the inputs: they are automatically recognized
when you switch the instrument on.
The main features of the instrument are:
โข Logging: acquisition and memorization of data inside the instrument. Memory capacity: 64
different logging sections, with the possibility to set the acquisition interval of the samples.
You can set the duration of the memorization and, with auto-start function; itโs possible
to set the starting and finishing date and the hour of data memorization.
โข The measurement unit of the temperature visualized sizes: ยฐC, ยฐF, ยฐK.
โข The system date and hour.
โข The visualization of the maximum, minimum and medium statistic parameters and their
cancellation.
โข The transfer speed of the data through the serial port RS232.
NOTE: The set acquisition interval is the same for all the probes connected to the instrument.
HD32.2 instrument can contemporarily detect the following sizes:
โข Globe thermometer temperature Tg.
โข Wet bulb with natural ventilation temperature Tn.
โข Ambient temperature T.
On the basis of the detected measurements, HD32.2 can calculate:
โข WBGT(in) index (Wet Bulb Glob Temperature: wet bulb and globe thermometer tempera-
ture) in presence or absence of solar irradiation.
โข WBGT(out) index (Wet Bulb Glob Temperature: wet bulb and globe thermometer tempera-
ture) in presence of solar irradiation.
