1 Unpack the Shipping Box
Caution: Make sure you Protect sensitive hardware.
use an electrostatic wrist strap or similar form of protection
when handling hardware.
Make sure the shipping box contains the following items:
๏‚Ÿ Setup poster (this document)
๏‚Ÿ Rail kit (if ordered)
๏‚Ÿ Power cables
๏‚Ÿ Electrostatic wrist strap
๏‚Ÿ Documentation
๏‚Ÿ PS Series Storage Array
2 Install the Array in a Rack
Warning! The array is heavy. Do not attempt to lift the
array without assistance.
Mount the array in a four-post, 19-inch rack. See the rack
instructions that came with the rail kit in your shipping box
(if ordered).
Setting Up a PS Series Storage Array
3 Install the Front Bezel
1. Hold the bezel with the array model number and Dell logo upright.
2. Hook the right end of the bezel onto the right side of the chassis.
3. Swing the left end of the bezel towards the left side of the chassis.
4. Press the bezel into place until the release latch closes.
5. Using the provided key, lock the front bezel. Store the key in a safe place.
4 Connect the Power Cables
Caution: Make sure the power switch is set to off (O) before connecting the power cables.
1. Use the power cables shipped with the array to connect each power supply module to a power source.
Note: Use separate sources of power, if possible.
2. Use the strain relief fastener to secure the power cables to the power supply modules so they cannot be pulled out accidentally.
If the array was not shipped with power cables, see your PS Series support provider or reseller for power cable information.
See the for more information.Installation Guide
PS4110 Installation
Before You Begin
This is a condensed reference. Read the (provided in the box) for complete installation information. Installation Guide
Register for an EqualLogic Customer Support Account.
If you do not have a customer service support account, go to and create one.support.dell.com
Download and Read the Release Notes from the Support Site.
The PS Series Release Notes contain the latest product information.
Review Safety Guidelines.
Be sure to review the safety instructions in your Safety, Environmental, and Regulatory Information booklet.
Prepare For Installation:
๏‚Ÿ Environmental Requirements
Make sure the installation location meets the power, cooling, and ventilation requirements described in the
Installation Guide, located in the shipping box.
๏‚Ÿ๎˜ƒNetworking Requirements
๎˜ƒ ๎˜ƒ ห—๎˜ƒ Standard๎˜ƒEthernet๎˜ƒand๎˜ƒTCP/IP๎˜ƒnetworking๎˜ƒrules๎˜ƒapply๎˜ƒto๎˜ƒa๎˜ƒPS๎˜ƒSeries๎˜ƒSAN.๎˜ƒ๎˜ƒ
๎˜ƒ ๎˜ƒ ห—๎˜ƒ 10๎˜ƒGigabit๎˜ƒEthernet๎˜ƒis๎˜ƒrequired.
๎˜ƒ๏‚Ÿ๎˜ƒHardware requirements (not supplied)
- Standard 19-inch, four-post rack.
๎˜ƒ๎˜ƒ๎˜ƒ ๎˜ƒ -๎˜ƒFor๎˜ƒEthernet๎˜ƒconnections๎˜ƒ(use๎˜ƒonly๎˜ƒone๎˜ƒof๎˜ƒthe๎˜ƒtwo๎˜ƒ10GE๎˜ƒports):๎˜ƒ
๏‚Ÿ๎˜ƒWith๎˜ƒthe๎˜ƒ10GBASE-T๎˜ƒport,๎˜ƒCAT6๎˜ƒ(or๎˜ƒbetter)๎˜ƒcable๎˜ƒfor๎˜ƒ37๎˜ƒto๎˜ƒ55๎˜ƒmeters,๎˜ƒCAT6A๎˜ƒor๎˜ƒCAT7๎˜ƒfor๎˜ƒup๎˜ƒto๎˜ƒ100๎˜ƒmeters.
With the SFP+ port, optical cable or copper SFP+ cable.๏‚Ÿ
๎˜ƒ๎˜ƒ๎˜ƒ ๎˜ƒ -๎˜ƒFor๎˜ƒManagement๎˜ƒconnections๎˜ƒ(optional):๎˜ƒCAT5๎˜ƒcable๎˜ƒwith๎˜ƒRJ45๎˜ƒconnector.
PS SERIES S TORAG E ARRAYS
Installation & Setup Manual
Step 4: Start Using the SAN
Step 3: Run the Remote Setup W izard
Software Configu ration Methods
PS Series St orag e Arrays
Sof tware Conf iguration
PS Series Groups
Step 1: Install the Host Integration Tools
Step 2: Collect Configuration Information
To configure the PS Series software, you need the information
in the following tables.
CHAP password
Group name
Group IP address
Membership
password
Administration password
CHAP user name
Group Configuration
Array Configuration
Member name
Default gateway
Subnet mask
Array IP address
RAID policy
Whe re to Go Next
Multi- Member PS Series Group
Group1
Setting Up a PS Series Storage Array
Setting Up a PS Series Storage Array (continued)
5 Connect the Array to the Network
Recommended Configuration: For high performance and availability distribute the connections across multiple network switches. The
switches must be connected with interswitch links that have sufficient bandwidth. See the for more information.Installation Guide
Hardware Installation is Complete!
Your array hardware should now be up and running. If it is not, make sure that you have successfully completed all of the steps described
in this poster.
If you are still experiencing problems, see the for additional installation information. Installation Guide
The Installation Guide also provides technical support and customer service information.
For๎˜ƒlive๎˜ƒtechnical๎˜ƒsupport,๎˜ƒcall๎˜ƒ1-800-945-3355.
What to do Next
Next, configure the array software. See the for array configuration information.Installation Guide
6 Turn on Power to the Array
Note: Before turning on power, allow enough time for the array to adjust to ambient temperature and humidity (for example, overnight).
Turn on power to both power supply modules (in any order) by pressing ( ) on the power switch.|
The power switch on each power supply module is located below the power plug.
Note: Batteries will start to charge and some hardware components may start to synchronize when power is turned on. Array LEDs will
indicate this normal activity.
Notes, Cautions, and Warnings
A NOTE indicates important information that helps you make better use
of your system.
A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
A WARNING indicates a potential for property damage, personal
injury, or death.
Printed in U.S.A.
Printed on recycled paper.
DNG36๎˜ƒrev.A00
Information in this document is subject to change without notice.
Reproduction in any manner whatsoever without the written
permission of Dell EqualLogic is strictly forbidden.
Dell and EqualLogic are trademarks of Dell Inc.
Copyright๎˜ƒ2011๎˜ƒDell๎˜ƒInc.๎˜ƒAll๎˜ƒrights๎˜ƒreserved.
Switch 0 Switch 1
CM0
CM1
Switch 0 Switch 1
CM0
CM1
10GBASE-T
Optical (SFP+)
DNG36A00
