Seite 1/20
Operating manual
ROTEX Heat pumps
For the operator
Types
ROTEX HPSU compact Ultra 4-8 kW
ROTEX HPSU compact 4-8 kW
ROTEX HPSU compact 11-16 kW
ROTEX HPSU Bi-Bloc 4-8 kW
ROTEX HPSU Bi-Bloc 11-16 kW
ROTEX HPSU monobloc compact 5-7 kW
ROTEX HPSU monobloc compact 11-16 kW
ROTEX HPSU hitemp 11-16 kW
EN
Edition 10/2018
Operating manual
2
ROTEX HPSU
ROTEX Heat pumps
008.1401244_09 – 10/2018 – EN
1 x General instructions
1 General instructions
1.1 Warranty conditions
The legal guarantee conditions fundamentally apply. Our war-
ranty conditions beyond that can be found online on your sales
presentative's webpage.
1.2 Legal provisions
According to the F-Gas Regulation (EC) No. 842/2006 Article 3,
replaced on 01/01/2015 by (EC) no. 517/2014 Articles 3 and 4,
operators (or owners) must regularly maintain their fixed refriger-
ation systems, check for leakages and have any leakages rec-
tified immediately.
All installation, maintenance and repair work on the refrigerant
circuit must be documented, e.g. in the operating manual.
The operators of ROTEX heat pump systems are subject to
the following obligations:
The European legal inspection period applies to heat
pumps with a total filling quantity of the system with re-
frigerant of at least 3 kg or from 01/01/2017 with a total
filling quantity of 5 t CO2 equivalent (with R410A, from
2.4 kg, with R32, from 7.4 kg).
However, ROTEX recommends concluding a mainte-
nance contract including documentation of the work
carried out in the operating manual to safeguard war-
ranty claims, even for systems for which there is no
legal obligation to check for leakages.
●With a total filling quantity of the system with refrigerant of
3 kg – 30 kg or from 6 kg in hermetic systems and from
01/01/2017 with a total filling quantity of refrigerant of
5-50 t CO2 equivalent or from 10 t CO2 equivalent in hermetic
systems:
Inspections by certified personnel at intervals of no more
than 12 months and documentation of the work carried
out in accordance with the valid regulation. This docu-
mentation must be kept for at least 5 years.
Persons who hold a certificate of qualification for work
on stationary refrigeration systems (heat pumps) and
air conditioning systems for the European area in
accordance with the F-Gas Certification Regulation
(EU) 2015/2067 are certified.
– Up to 3 kg or 5 t CO
2 equivalent Total refrigerant
charge: Category II certificate of competence
– Up to 3 kg or 5 t CO
2 equivalent Total refrigerant
charge: Category I certificate of competence
RISK OF ENVIRONMENTAL DAMAGE!
The overall heat pump system contains refrigerants
with fluorinated greenhouse gases that are harmful to
the environment when released.
Coolant type: R410A
GWP* value: 2087.5
Coolant type: R134a
GWP* value: 1430
Refrigerant type: R32
GWP* value: 675
* GWP = Global Warming Potential
●Never allow refrigerant to escape into the atmos-
phere - always extract and recycle with a suitable
recycling device.
Have the inspection and maintenance carried out by
authorised and trained HVAC engineers once a year,
ideally before the heating period. Malfunctions during
the heating period can therefore be prevented.
ROTEX recommends an inspection and maintenance
contract to ensure regular inspection and maintenance.
2 x System data
ROTEX HPSU
ROTEX Heat pumps
008.1401244_09 – 10/2018 – EN
Operating manual
3
2 System data
2.1 Operator
Name:
Company:
Street & house number:
Postal code & town:
Phone:
2.2 System
1.
2.
3.
4.
5.
Outdoor unit
1 - Manufacturer ROTEX Heating Systems GmbH
2 - Type
3 - Serial number (mfg. no.)
4 - Production date (mfg. date)
5 - Type of coolant + fill weight of device R_____ kg
Fig. 2-1 Type plate for external unit
Total fill weight
1 - Factory filling of the outdoor module (see fig. kg2-1, item 5):
2 - Quantity of additional coolant added on site: kg
3 - Total amount of coolant in the system: kg
Fig. 2-2 Sticker showing coolant fill
weight in entire system
(external unit)
1.
2.
3.
4.
5.*
Indoor unit
1 - Manufacturer ROTEX Heating Systems GmbH
2 - Type
3 - Serial number (mfg. no.)
4 - Production date (mfg. date)
5* - Type of coolant + fill weight of device R_____ kg
Fig. 2-3 Type plate for indoor unit
HPSU Bi-Bloc / HPSU hitemp * forHPSU hitemp only
Fig. 2-4 Type plate for indoor unit
HPSU compact
Langwiesenstrasse 10, D-74363 Gueglingen
SER.NO.
= kg = kg
Fig. 2-5 Type plate for indoor unit
HPSU monobloc compact
Fig. 2-6 Type plate for indoor unit
HPSU compact Ultra
2.3 Leakage checking
Test interval in accordance with F-gas regulations:
every 6 months
every 12 months
No legal requirement for leakage checking
All maintenance, leakage checks and work
performed on the coolant system must be
recorded below. An unbroken record of
compliance with the maintenance and in-
spection work stipulated by ROTEX is a prereq-
uisite for any guarantee claim within the guarantee
period and any possible ex-gratia payment by the
manufacturer.
