MODELS
Wall-mounted type
FXAQ20PVE
FXAQ25PVE
FXAQ32PVE
FXAQ40PVE
FXAQ50PVE
FXAQ63PVE
SYSTEM Air Conditioners
INSTALLATION MANUAL
CAREFULLY READ THESE INSTRUCTIONS BEFORE INSTALLATION.
KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE.
VEUILLEZ LIRE ATTENTIVEMENT CES INSTRUCTIONS AVANT L'INSTALLATION.
CONSERVEZ CE MANUEL EN LIEU SÛR POUR POUVOIR VOUS Y REPORTER
ULTÉRIEUREMENT.
LEA DETENIDAMENTE ESTAS INSTRUCCIONES ANTES DE LA INSTALACIÓN.
CONSERVE ESTE MANUAL PARA POSIBLES CONSULTAS FUTURAS.
PRIMA DELL'INSTALLAZIONE, LEGGERE ATTENTAMENTE LE PRESENTI ISTRUZIONI.
CONSERVARE IL PRESENTE MANUALE IN UN LUOGO FACILMENTE ACCESSIBILE PER
RIFERIMENTO FUTURO.
LEES DEZE INSTRUCTIES ZOGVULDIG DOOR VOORDAT MET DE INSTALLATIE WORDT
BEGONNEN.
BEWAAR DEZE HANDLEIDING VOOR TOEKOMSTIG GEBRUIK OP EEN GESCHIKTE
PLAATS ONDER HANDBEREIK.
LEIA ATENTAMENTE ESTAS INSTRUÇÕES ANTES DA INSTALAÇÃO.
MANTENHA ESTE MANUAL NUM LOCAL DE FÁCIL ACESSO PARA CONSULTA.
English 1
FXAQ20PVE
FXAQ25PVE
FXAQ32PVE
FXAQ40PVE
FXAQ50PVE
FXAQ63PVE
VRV SYSTEM
Air Conditioners
Installation manual
CONTENTS
1. SAFETY PRECAUTIONS...............................................................................................1
2. BEFORE INSTALLATION ..............................................................................................3
3. SELECTING INSTALLATION SITE................................................................................5
4. INDOOR UNIT INSTALLATION .....................................................................................6
5. REFRIGERANT PIPING WORK ....................................................................................9
6. DRAIN PIPING WORK .................................................................................................12
7. ELECTRIC WIRING WORK .........................................................................................13
8. HOW TO CONNECT WIRINGS AND WIRING EXAMPLE ..........................................14
9. FIELD SETTINGS ........................................................................................................20
10. TEST RUN....................................................................................................................21
The original instructions are written in English. All other languages are translations of the original instructions.
1. SAFETY PRECAUTIONS
Be sure to follow this “SAFETY PRECAUTIONS”.
This product comes under the term “appliances not accessible to the general public”.
This is a class A product. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.
This manual classifies the precautions into WARNINGS and CAUTIONS.
Be sure to follow all the precautions below: They are all important for ensuring safety.
WARNING .........Indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION ..........Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
It may also be used to alert against unsafe practices.
•After the installation is completed, test the air conditioner and check if the air conditioner operates properly.
Give the user adequate instructions concerning the use and cleaning of the indoor unit according to the
Operation Manual. Ask the user to keep this manual and the Operation Manual together in a handy place
for future reference.
WARNING
•Ask your local dealer or qualified personnel to carry out installation work.
Improper installation may result in water leakage, electric shocks or a fire.
•Perform installation work in accordance with this installation manual.
Improper installation may result in water leakage, electric shocks or a fire.
•Consult your local dealer regarding what to do in case of refrigerant leakage.
When the air conditioner is installed in a small room, it is necessary to take proper measures so that the
amount of any leaked refrigerant does not exceed the concentration limit in the event of a leakage.
Otherwise, this may lead to an accident due to oxygen deficiency.
•Be sure to use only the specified parts and accessories for installation work.
Failure to use the specified parts may result in the air conditioner falling down, water leakage, electric
shocks, a fire, etc.
2 English
•Install the air conditioner on a foundation that can withstand its mass.
Insufficient strength may result in the air conditioner falling down and causing injury.
In addition, it may lead to vibration of indoor units and cause unpleasant chattering noise.
•Carry out the specified installation work in consideration of strong winds, typhoons, or earthquakes.
Improper installation may result in an accident such as air conditioner falling.
•Make certain that all electrical work is carried out by qualified personnel according to the applicable legis-
lation (note 1) and this installation manual, using a separate circuit.
In addition, even if the wiring is short, make sure to use a wiring that has sufficient length and never connect
additional wiring to make the length sufficient.
Insufficient capacity of the power supply circuit or improper electrical construction may lead to electric
shocks or a fire.
(note 1) applicable legislation means “All international, national and local directives, laws, regulations and/
or codes which are relevant and applicable for a certain product or domain”.
•Earth the air conditioner.
Do not connect the earth wiring to gas or water piping, lightning conductor or telephone earth wiring.
Incomplete earthing may cause electric shocks or a fire.
A high surge current from lightning or other sources may cause damage to the air conditioner.
•Be sure to install an earth leakage circuit breaker.
Failure to do so may cause electric shocks and a fire.
•Disconnect the power supply before touching the electric components.
If you touch the live part, you may get an electric shocks.
•Make sure that all wiring is secure, using the specified wiring and ensuring that external forces do not act
on the terminal connections or wiring.
Incomplete connection or fixing may cause an overheat or a fire.
•When wiring between the indoor and outdoor units, and wiring the power supply, form the wiring orderly so
that the control box lid can be securely fastened.
If the control box lid is not in place, overheat of the terminals, electric shocks or a fire may be caused.
•If refrigerant gas leaks during installation work, ventilate the area immediately.
Toxic gas may be produced if refrigerant gas comes into contact with a fire.
•After completing the installation work, check to make sure that there is no leakage of refrigerant gas.
Toxic gas may be produced if refrigerant gas leaks into the room and comes into contact with a source of
a fire, such as a fan heater, stove or cooker.
•Never directly touch any accidental leaking refrigerant. This could result in severe wounds caused by frost-
bite.
CAUTION
•Install drain piping according to this installation manual to ensure good drainage, and insulate the piping to
prevent condensation.
Improper drain piping may cause water leakage, make the furniture get wet.
•Install the air conditioner, power supply wiring, remote controller wiring and transmission wiring at least
1 meter away from televisions or radios to prevent image interference or noise.
(Depending on the radio waves, a distance of 1 meter may not be sufficient to eliminate the noise.)
•Install the indoor unit as far as possible from fluorescent lamps.
If a wireless remote controller kit is installed, the transmission distance may be shorter in a room where an
electronic lighting type (inverter or rapid start type) fluorescent lamp is installed.
•Do not install the air conditioner in places such as the following:
1. Where there is mist of oil, oil spray or vapour for example a kitchen.
Resin parts may deteriorate, and cause them to fall out or water to leak.
2. Where corrosive gas, such as sulfurous acid gas, is produced.
Corrosion of copper pipings or brazed parts may cause the refrigerant to leak.
3. Where there is machinery which emits electromagnetic waves.
Electromagnetic waves may disturb the control system, and cause malfunction of the equipment.
4. Where flammable gases may leak, where carbon fibre or ignitable dust is suspended in the air or where
volatile flammables, such as thinner or gasoline, are handled.
If the gas should leak and remained around the air conditioner, it may cause ignition.
•The air conditioner is not intended for use in a potentially explosive atmosphere.
