Seite 1/12
Operation manual
Split system air conditioners English
Operation manual
Split system air conditioners
FBA35A2VEB
FBA50A2VEB
FBA60A2VEB
FBA71A2VEB
FBA100A2VEB
FBA125A2VEB
FBA140A2VEB
FBA35A2VEB9
FBA50A2VEB9
FBA60A2VEB9
FBA71A2VEB9
Table of Contents
Operation manual
2
FBA35~140A2VEB+FBA35~71A2VEB9
Split system air conditioners
4P456964-1C – 2018.08
Table of Contents
1 About this document 2
2 About the system 2
2.1 Components .............................................................................. 2
3 Operation 3
3.1 Operation range ........................................................................ 3
3.2 Operation procedure ................................................................. 4
4 Energy saving and optimum operation 4
5 Maintenance and service 4
5.1 Overview: Maintenance and service ......................................... 4
5.2 To clean the drain pan............................................................... 5
5.3 To handle the drain pipe plug .................................................... 5
5.4 Cleaning the air filter, suction grille, air outlet and outside
panels ....................................................................................... 5
5.4.1 To clean the air outlet and outside panels .................. 5
5.4.2 To clean the air filter ................................................... 5
5.5 Maintenance before a long stop period ..................................... 6
5.6 Maintenance after a long stop period ........................................ 6
6 Troubleshooting 6
6.1 Symptoms that are NOT system malfunctions .......................... 7
6.1.1 Symptom: The system does not operate .................... 7
6.1.2 Symptom: White mist comes out of a unit (Indoor
unit) ............................................................................. 7
6.1.3 Symptom: Dust comes out of the unit......................... 7
6.1.4 Symptom: The units can give off odours..................... 7
6.1.5 Symptom: The operation stopped suddenly
(Operation lamp is on) ................................................ 7
6.1.6 Symptom: The outdoor fan rotates while the air
conditioner is not in operation ..................................... 7
6.1.7 Symptom: The heating operation stops suddenly and
a flowing sound is heard ............................................. 7
7 Disposal 8
1 About this document
Thank you for purchasing this product. Please:
â–ª Read the documentation carefully before operating the user
interface to ensure the best possible performance.
â–ª Keep the documentation for future reference.
Target audience
Endusers
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
â–ªGeneral safety precautions:
â–ª Safety instructions that you must read before operating your
system
â–ª Format: Paper (in the box of the indoor unit)
â–ªOperation manual:
â–ª Quick guide for basic usage
â–ª Format: Paper (in the box of the indoor unit)
â–ªUser reference guide:
â–ª Detailed step-by-step instructions and background information
for basic and advanced usage
â–ª Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original documentation is written in English. All other languages
are translations.
2 About the system
INFORMATION
The sound pressure level is less than 70dBA.
WARNING: FLAMMABLE MATERIAL
The R32 refrigerant (if applicable) in this unit is mildly
flammable. Refer to the outdoor unit specifications for the
type of refrigerant to be used.
WARNING
â–ª Do NOT modify, disassemble, remove, reinstall or
repair the unit yourself as incorrect dismantling or
installation may cause an electric shock or fire. Contact
your dealer.
â–ª In case of accidental refrigerant leaks, make sure there
are no naked flames. The refrigerant itself is entirely
safe and non-toxic. R410A is a non-combustible
refrigerant, and R32 is a mildly flammable refrigerant,
but they will generate a toxic gas when they
accidentally leak into a room where combustible air
from fan heaters, gas cookers, etc. is present. Always
have qualified service personnel confirm that the point
of leakage has been repaired or corrected before
resuming operation.
NOTICE
Improper installation or attachment of equipment or
accessories could result in electric shock, short-circuit,
leaks, fire or other damage to the equipment. Only use
accessories, optional equipment and spare parts made or
approved by Daikin.
2.1 Components
INFORMATION
The following illustration is an example and might NOT
match your system layout.
b
f
a
h
c
d
e
g
aIndoor unit
3 Operation
Operation manual
3
FBA35~140A2VEB+FBA35~71A2VEB9
Split system air conditioners
4P456964-1C – 2018.08
bOutdoor unit
cUser interface
dAir inlet
eAir outlet
fRefrigerant piping and electric wiring
gDrain pipe
hEarth wire to ground outdoor unit to prevent electric
shocks.
CAUTION
Do NOT insert fingers, rods or other objects into the air
inlet or outlet. Do NOT remove the fan guard. When the
fan is rotating at high speed, it will cause injury.
CAUTION
â–ª NEVER touch the internal parts of the controller.
â–ª Do NOT remove the front panel. Some parts inside are
dangerous to touch and appliance problems may
happen. For checking and adjusting the internal parts,
contact your dealer.
NOTICE
Do NOT wipe the controller operation panel with benzine,
thinner, chemical dust cloth, etc. The panel may get
discoloured or the coating peeled off. If it is heavily dirty,
soak a cloth in water-diluted neutral detergent, squeeze it
well and wipe the panel clean. Wipe it with another dry
cloth.
NOTICE
NEVER press the button of the user interface with a hard,
pointed object. The user interface may be damaged.
NOTICE
NEVER pull or twist the electric wire of the user interface. It
may cause the unit to malfunction.
3 Operation
3.1 Operation range
Use the system in the following temperature and humidity ranges for
safe and effective operation.
For combination with R410A outdoor unit, refer to the following table:
Outdoor units Cooling Heating
RR71~125 –15~46°CDB —
18~37°CDB
12~28°CWB
—
RQ71~125 –5~46°CDB –9~21°CDB
–10~15°CWB
18~37°CDB
12~28°CWB
10~27°CDB
RXS35~60 –10~46°CDB –15~24°CDB
–16~18°CWB
18~32°CDB 10~30°CDB
3MXS40~68
4MXS68~80
5MXS90
–10~46°CDB –15~24°CDB
–16~18°CWB
18~32°CDB 10~30°CDB
Outdoor units Cooling Heating
RZQG71~140 –15~50°CDB –19~21°CDB
–20~15.5°CWB
18~37°CDB
12~28°CWB
10~27°CDB
RZQSG71~140 –15~46°CDB –14~21°CDB
–15~15.5°CWB
20~37°CDB
14~28°CWB
10~27°CDB
RZQ200~250 –5~46°CDB –14~21°CDB
–15~15°CWB
20~37°CDB
14~28°CWB
10~27°CDB
Indoor humidity ≤80%(a)
For combination with R32 outdoor unit, refer to the following table:
Outdoor units Cooling Heating
RXM35~60 –10~46°CDB –15~24°CDB
–16~18°CWB
18~32°CDB 10~30°CDB
3MXM40~68
4MXM68~80
5MXM90
–10~46°CDB –15~24°CDB
–16~18°CWB
18~32°CDB 10~30°CDB
RZAG35~60 –20~52°CDB –20~24°CDB
–21~18°CWB
18~32°CDB 10~30°CDB
RZAG71~140 –20~52°CDB –19.5~21°CDB
–20~15.5°CWB
18~37°CDB
12~28°CWB
10~27°CDB
RZASG71~140 –15~46°CDB –14~21°CDB
–15~15.5°CWB
20~37°CDB
14~28°CWB
10~27°CDB
AZAS71~140 –15~46°CDB –14~21°CDB
–15~15.5°CWB
20~37°CDB
14~28°CWB
10~27°CDB
Indoor humidity ≤80%(a)
Symbol Explanation
Outdoor temperature
Indoor temperature
(a) To avoid condensation and water dripping out of the unit. If
the temperature or the humidity is beyond these conditions,
safety devices may be put in action and the air conditioner
may not operate.
Setting temperature range of the user interface:
Cooling Heating
17~32°C 16~31°C
