Before You Begin

1. If you purchased this VoIP Terminal Adapter to share your high-speed Internet

connection with other computers, you must have an established Internet account from

an Internet Service Provider (ISP).

This product can be set up using

any current web browser, i.e.,

Internet Explorer 6 or Netscape

Navigator 6.2.3.

DVG-2001S

oIP Terminal Adapte

2. It’s best to use the same computer that is connected to your router for configuring the

DVG-2001S VoIP Terminal Adapter. The DVG-2001S acts as a DHCP server and will

assign all the necessary IP address information on your network. See the Quick

Installation Guide or the Manual on the CD-ROM for setting each network adapter to

automatically obtain an IP address.

their respective holders. Software and specifications subject to change without notice. DVG-2001S VoIP

Terminal Adapter

Check Your Package Contents

• DVG-2001S

• Ethernet Cable

(CAT5 UTP Straight-Through)

• CD-ROM

containing Manual and Warranty

Using a power adapter with

a different voltage rating will

damage and void the

warranty for this product.

• 12V, 1.2A

Power Adapter

If any of the above items is missing, please contact your reseller.

Connecting the VoIP Terminal Adapter to

your Computer

A. First, connect the power adapter to the power input at the back

panel of the DVG-2001S and then plug the other end of the

power adapter to a wall outlet or power strip. On the front of the

device, the Power LED will turn ON to indicate proper operation.

Power Input

Connect to AC

Adapter

LAN Ports

Connect to the

LAN and other

computers

Phone Connections

Connect to your phone

using standard phone

cabling

Factory

Reset

button

B. Insert one end of the Ethernet cable into the Ethernet (LAN) port

on the back panel of the DVG-2001S and the other end of the

cable to an Ethernet Adapter or available Ethernet port on your

computer.

C. Insert a telephone cable into the Phone port, then connect the

cable to your telephone line.

D. Check the LED display on the front of the Router to confirm that

the connections have been made.

Congure IP Settings

To connect to the network, make sure the network adapter in

your computer is configured properly. Here’s how to assign a

static IP address to your PC.

For Microsoft Windows XP

Go to Start > click

Control Panel >

click on the Network

and Internet

Connections icon

Click on Network and

Internet Connections

Click on the Network

Connections icon

Click on Network

Connections

Right-click the

Local Area

Connection icon,

and then select

Properties.

Select Properties

Produktspezifikationen

Marke:	D-Link
Kategorie:	Nicht kategorisiert
Modell:	DVG-2001S
Betriebstemperatur:	0 - 40 °C
Temperaturbereich bei Lagerung:	-10 - 55 °C
Energiebedarf:	12V AC, 1.2A
Management-Protokolle:	SIP, PPPoE
Abmessungen (BxTxH):	90 x 82.46 x 31 mm
Unterstützte Protokolle:	IP \nTCP \nUDP \nARP \nHTTP\n
Kompatible Produkte:	G.711, G.723.1, G.726, G.729A, G.168, G.711, RFC2833
Verkabelungstechnologie:	10/100Base-T(X)
Weitere Anschlüsse:	RJ-11, FXS Port \nRJ-45 Ethernet Port\n
Managementfunktionen:	TFTP Client\nHTTP Web Interface\nDHCP \nTELNET \nTFTP Client\n
Sicherheit Eigenschaften:	SIP Authentication, Password Encryption \nHTTP Digest Authentication \nConfiguration Download HTTPS, SSL/TLS Clients Certification Encryption & Authentication \nConfiguration File Encryption\nVoIP NAT Traversal (SIP/STUN)
