Crown P.I.P.-FTE Bedienungsanleitung


Lesen Sie kostenlos die đź“– deutsche Bedienungsanleitung fĂĽr Crown P.I.P.-FTE (12 Seiten) in der Kategorie Nicht kategorisiert. Dieser Bedienungsanleitung war fĂĽr 13 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Seite 1/12
125512-1
11/97
Printed on
recycled paper.
© 1997 by Crown International, Inc., P.O. Box 1000, Elkhart, IN 46515-1000
U.S.A. Telephone: 219-294-8000. Fax: 219-294-8329.
P.I.P.
modules are
produced by the Professional Audio Division of Crown International, Inc.
Trademark Notice:
Crown
®,
Macro-Tech
®,
Com-Tech
®,
IOC
® and
P.I.P.
® are
registered trademarks of Crown International, Inc. Other trademarks are the
property of their respective owners.
P. I.P.–FTE
P.I.P.- FTE
CH 2 CH 1
+ –
BALANCED INPUTS
+ = NON-INVERTING
– = INVERTING
+ –
—CAUTION—
DO NOT USE AMPLIFIER PHONE JACKS
WITH THIS MODULE PLUGGED IN.
P.I.P.–FTE
Page 2
P.I.P.–FTE
Page 3
1 Welcome
Thank you for purchasing the
Crown P.I.P.-FTE accessory.
P.I.P.
® modules are designed to
quickly install in the rear panel of
many Crown ampliî‹Šers.
P.I.P.
stands for “Programmable Input
Processor.” Their versatile fea-
tures expand the capabilities of
your amplifier and enable you to
customize it for your particular
needs.
The P.I.P-FTE employs balanced
transformers to isolate the inputs
of
Com-Tech
® or
Macro-Tech
®
series ampliî‹Šers. This adds valu-
able isolation from shorted input
cables, faulty wiring and com-
mon mode noise.
In addition to transformer isola-
tion, this
P.I.P.
provides two im-
portant filters to attenuate un-
wanted ultrasonic and subsonic
frequencies.
A horn equalization circuit is also
available to compensate for the
high-frequency roll-off of con-
stant-directivity horns.
You should find these items when
you unpack:
• P.I.P.-FTE module
• Two 8-32 Phillips Machine
Screws
• Two Lock Washers
• Two Quick-Connect Barrier
Blocks
• This Owner’s Manual
Features
❏Balanced inputs with 1:1 iso-
lation transformers to help
keep the input noise-free.
❏RFI filter which attenuates un-
wanted ultrasonic frequencies
that would otherwise waste am-
plifier power. The RFI filter is a 12
dB/octave (2nd order), Bessel-
tuned low-pass filter with a 3 dB
roll-off point at 33 kHz.
❏Switchable subsonic/bass l-
ter with 50-, 100- or 300-Hz
roll-o frequencies.
❏Constant-directivity horn
equalization network which
can be switched on or off.
❏Quick-connect barrier block
connectors provide greater
wiring î‹‹exibility and make in-
stallation easier.
P.I.P.- FTE
CH 2 CH 1
+ –
BALANCED INPUTS
+ = NON-INVERTING
– = INVERTING
+ –
—CAUTION—
DO NOT USE AMPLIFIER PHONE JACKS
WITH THIS MODULE PLUGGED IN.
Fig. 1.1 P.I.P.-FTE
