DO GUIDE

Once the TSD-2220 is aligned with the mounting bracket, use a screwdriver and the appropriate

number of M4 mounting screws to attach the TSD-2220 to the bracket.

DO Connect the Device

1. Locate the cable cover on the rear of the TSD-2220. Remove the cover by gently pushing in

the two tabs that secure the cover to the touch screen until the cover is disengaged.

2. Make any necessary connections to the TSD-2220 as shown in the following illustration.

NOTE: Power should be supplied to the touch screen using only the included 12 Vdc

power pack. Apply power after all connections have been made.

NOTE: The HDMI® input requires an appropriate adapter or an interface cable to

accommodate a DVI signal. Crestron CBL-HD-DVI cables are sold separately.

HDMI:

From HDMI output

on digital graphics engine

or computer console

USB:

From USB port

on digital graphics engine

or computer console

12 Vdc:

From power

supply

The Crestron® TSD-2220 is a 21.5" (546 mm) HD touch screen display that can be used with the

Crestron DGE-100 or DM-DGE-200-C digital graphic engine (each sold separately) to provide

a powerful touch screen control solution. The TSD-2220 also can be used as a high-denition

display for a television or a computer.

NOTE: For more information about installing and conguring the DGE-100 or DM-DGE-200-C,

refer to the DGE-100/DM-DGE-200-C DO Guide (Doc. 7695) and DGE-100/DM-DGE-200-C

Supplemental Guide (Doc. 7696) at www.crestron.com/manuals.

DO Install the TSD-2220

The TSD-2220 can be installed using a variety of VESA compliant mounting accessories,

including wall-mount brackets, desk stands, and articulating arms. The TSD-2220 is compatible

with VESA 100 x 100 mm and VESA 200 x 100 mm brackets (not included).

CAUTION: Ensure that the chosen VESA mount is rated for the size and weight of the

TSD-2220. Refer to the table of specications on the product webpage for more information.

To install the TSD-2220 using a VESA mount, align the threaded holes in the rear of the

TSD-2220 with the appropriate holes in the mounting bracket. (Refer to the illustration below.)

The TSD-2220 supports 100 x 100 mm center mounting, 100 x 100 mm edge mounting, and

200 x 100 mm mounting.

• For 100 x 100 mm center mounting, use the four center threaded holes.

• For 100 x 100 mm edge mounting, use the four rightmost threaded holes.

• For 200 x 100 mm mounting, use all six threaded holes.

TSD-2220

21.5" HD Touch Screen Display

DO Check the Box

QTY PRODUCT COLOR PART NUM.

1 Cable, USB 2.0, A - B, 6' (1.83 m) 2048150

1 Power Cord, 6' 7" (2 m) 2025416

1 Power Pack, 12 Vdc 4.16 A, 100-240 Vac 2048149

1 Screw, M3 x 6 mm, Pan Head, Phillips 2013272

Threaded holes

for VESA mounting

DO GUIDE DOC. 7965B (2048028) 02.17

Specications subject t o change without not ice.

3. Reattach the cable cover by aligning the tabs on the cover with their respective slots on the

rear of the TSD-2220, and then gently push the cover upward until the tabs snap into place.

Route all cables through the gap in the top of the cable cover.

4. To secure the cable cover to the TSD-2220, use a Phillips screwdriver to attach the

included M3 x 6 mm screw to the TSD-2220 as shown in the following illustration.

DO Learn More

Visit the website for additional information and the latest rmware updates. To learn

more about this product, use a QR reader application on your mobile device to scan

the QR image.

Crestron Electronics

15 Volvo Drive, Rockleigh, NJ 07647

888.CRESTRON | www.crestron.com

As of the date of manufacture, the product has been tested and found to comply with specications for CE marking.

Federal Communications Commission (FCC) Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference

that may cause undesired operation.

CAUTION: Changes or modications not expressly approved by the manufacturer responsible for compliance could void the

user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Industry Canada (IC) Compliance Statement

CAN ICES-3(B)/NMB-3(B)

Electrical Connection:

“This product must be connected to an earthed mains socket-outlet.”

• Finland: “Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan.”

• Norway: “Apparatet må tilkoples jordet stikkontakt.”

• Sweden: “Apparaten skall anslutas till jordat uttag.”

The specic patents that cover Crestron products are listed at . The product warranty can be found at .http://w ww.crestron.com/legal/patents www.crestron.com/warranty

Certain Crestron products cont ain open source soft ware. For specic information, please visit . www.crestron.com/opensource
