DO GUIDE

3. Install the included thumb screws on the rear of the sound bar.

4. Connect the sound bar as described in “DO Connect the Device.”

5. Place the sound bar against the wall, above the mounting bracket, and lower the sound bar until

the thumb screws rest in the mounting bracket.

DO Connect the Device

Make the necessary connections as called out in the diagram below. Connect power last.

NOTE: Connect only one input.

NOTE: If using the included RCA® cable for connecting the UNBALANCED port, use the right-

angled connectors to allow the cable to t between the wall and the sound bar.

DO Use the Device

Move the switch located above the 100–240V~ 50/60Hz 50W port to turn on the sound bar. The PWR

LED lights, and sound from the connected source is produced.

If an audio signal is not present for approximately 20 minutes, the sound bar switches to a low power

idle state. The sound bar resumes normal operation when an audio signal is detected.

SAROS SB-200-P

Saros® Sound Bar 200, Powered

DO Install the Device

The Saros® Sound Bar can be installed as part of a Crestron RL

® 2 Group Collaboration system or

on a wall as part of any integrated audio system. With the balanced and unbalanced inputs, the

sound bar can work with any audio system.

In a Crestron RL System

Use the included thumb screws to attach the sound bar to the sound bar bracket. Refer to the

quickstart included with the Crestron RL Group Collaboration system for details.

On a Wall

1. Place the mounting bracket on the wall.

NOTE: Use a laser level or snap a chalk line to mark the location of the bracket.

2. Secure the bracket to the wall with hardware that is appropriate for the mounting surface.

NOTE: If a stud cannot be located, use the screwholes located adjacent to each keyhole slot.

DO Check the Box

QTY PRODUCT COLOR PART NUM.

1 Bracket, Mounting 2048193

1 Cable, RCA®, Right-Angle, 6' (1.83 m) Black 2047013

1 Connector, 5-Pin 2047025

1 Power Cord, 6' (1.83 m) Black 2047024

2 Screw, 6-32, Thumb 2047009

DIMENSION INCHES MILLIMETERS

A 26.8 680

B 23.3 592

C 21.3 540

D 18.6 472

E 42016.5

F 13.9 352

G 11.8 300

H 9.1 232

I 7.1 180

J 4.4 112

K 2.4 60

L 80.3

BCDEFGHIJKL

BALANCED AUDIO INPUT:

From balanced audio source

UNBALANCED AUDIO INPUT:

From unbalanced audio source

100–240V~ 50/60Hz 50W:

From ac power outlet

DO GUIDE DOC. 7508D (2045962) 08.17

Specicat ions subject to change without not ice.

DO Learn More

Visit the website for additional information and the latest rmware updates. To learn

more about this product, use a QR reader application on your mobile device to scan

the QR image.

Crestron Electronics

15 Volvo Drive, Rockleigh, NJ 07647

888.CRESTRON | www.crestron.com

As of the date of manufacture, the product has been tested and found to comply with specications for CE marking.

Federal Communications Commission (FCC) Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference

that may cause undesired operation.

CAUTION: Changes or modications not expressly approved by the manufacturer responsible for compliance could void the

user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Industry Canada (IC) Compliance Statement

CAN ICES-3(B)/NMB-3(B)

Electrical Connection

“This product must be connected to an earthed mains socket-outlet.”

• Finland: “Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan.”

• : “Apparatet må tilkoples jordet stikkontakt.”Norway

• : “Apparaten skall anslutas till jordat uttag.”Sweden

The s pecic patents t hat cover Crestron products are listed at . The product warranty can be found at .www.crestron.com/legal/patents www.crestron.com/warranty

Certain Crestron products cont ain open source sof t ware. For specic information, please visit . www.crestron.com/opensource

Crest ron, t he Crestron logo, Crestron RL, and Saros are either trademarks or registered t rademarks of Crestron Electronics, Inc. in t he United St ates and/or other count ries. RCA is either a

trademark or registered trademark of VOXX International Corporation in the United Stat es and/or other countries. Other trademarks, registered t rademarks, and trade names may be used

in this document t o ref er to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary int erest in the marks and names of ot hers. Crest ron is not

responsible for errors in t ypography or phot ography.
