Figures and illustrations in this Simple User Guide are provided for reference only and may
differ from actual product appearance
You can access the User guide on Samsung’s on-line customer support
center by scanning the QR code on the left.
To see the manual on your PC or mobile device, download the manual in
document format from Samsung’s website.
(http://www.samsung.com/support)
Simple User Guide
HW-Q935D / HW-Q810D
ENG - 2
SAFETY INFORMATION
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols
which may be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK. DO
NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any
kind of contact with any internal part of
this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates
that a safety connection to electrical earth
(ground) is not required.
If this symbol is not present on a product
with a power cord, the product MUST have
a reliable connection to protective earth
(ground).
AC voltage : Rated voltage marked with
this symbol is AC voltage.
DC voltage : Rated voltage marked with
this symbol is DC voltage.
Caution. Consult Instructions for use :
This symbol instructs the user to consult
the user manual for further safety related
information.
WARNING
• To reduce the risk of re or electric shock, do not
expose this appliance to rain or moisture.
• Do not use liquid fumigators containing chemicals,
such as mosquito repellent or air freshener, around
the product. If steam comes in contact with the
product surface or enters the product, it may cause
stains or malfunction.
CAUTION
• TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
• This apparatus shall always be connected to a AC
outlet with a protective grounding connection.
• To disconnect the apparatus from the mains, the plug
must be pulled out from the mains socket, therefore
the mains plug shall be readily operable.
• Do not expose this apparatus to dripping or
splashing. Do not put objects î©£lled with liquids, such
as vases, on the apparatus.
• To turn this apparatus off completely, you must pull
the power plug out of the wall socket. Consequently,
the power plug must be easily and readily accessible
at all times
PRECAUTIONS
1. Ensure that the AC power supply in your house
complies with the power requirements listed on
the identiî©£cation sticker located on the bottom of
your product. Install your product horizontally, on a
suitable base (furniture), with enough space around
it for ventilation (7~10 cm). Make sure the ventilation
slots are not covered. Do not place the unit on
ampliî©£ers or other equipment which may become
hot. This unit is designed for continuous use.
To fully turn off the unit, disconnect the AC plug from
the wall outlet. Unplug the unit if you intend to leave
it unused for a long period of time.
2. During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the unit.
3. Do not expose the unit to direct sunlight or other
heat sources. This could lead to overheating and
cause the unit to malfunction.
4. Protect the product from moisture (i.e. vases),
and excess heat (e.g. a î©£replace) or equipment
creating strong magnetic or electric î©£elds. Unplug
the power cable from the AC wall socket if the
unit malfunctions. Your product is not intended
for industrial use. It is for personal use only.
Condensation may occur if your product has been
stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until
the unit has reached room temperature before using.
5. The battery used with this product contains
chemicals that are harmful to the environment. Do
not dispose of the battery in the general household
trash. Do not expose the battery to excess heat, direct
sunlight, or î©£re. Do not short circuit, disassemble, or
overheat the battery.
CAUTION : Danger of explosion if the battery is
replaced incorrectly. Replace only with the same or
equivalent type.
English
ENG - 3
01 CHECKING THE
COMPONENTS
• Soundbar Main Unit
• Soundbar Remote
Control
• Batteries
• Subwoofer
• Surround Speaker p3-x2
(Left/Right, HW-Q935D
model only)
• HW-Q935D : Power
Cord X 4 (Subwoofer,
Surround Speaker,
Soundbar)
• HW-Q810D : Power
Cord X 2 (Subwoofer,
Soundbar)
• HDMI Cable
• Wall Mount Guide
• Holder-Screw X 2
• Screw (M4 x L10) X 2
• Bracket-Wall Mount
X 2
• Rubber-Foot X 4
NOTE
• To purchase additional components or optional
cables, contact a Samsung Service Center or Samsung
Customer Care.
• The number of power cables may differ with the
model.
02 PRODUCT OVERVIEW
Top Panel of the Soundbar
Volume
1 2
Display
1 (Multi Function) Button
In standby mode, press the (Multi Function)
button to turn on the Soundbar.
Press the (Multi Function) button to change
the input source.
2 (Mic On/Off) Button
Press the button to turn the microphone on or
off.
When the microphone is off, the LED indicator
will glow red.
To switch to BT PAIRING mode in BT mode, press
and hold the button on the top of (Mic On/Off)
the Soundbar for more than 5 seconds.
Bottom Panel of the Soundbar
SERVICE
DIGITAL AUDIO IN
(OPTICAL)
HDMI TO TV
(eARC/ARC)
HDMI
SERVICE
DIGITAL AUDIO IN
(OPTICAL)
HDMI TO TV
(eARC/ARC)
HDMI
2
1
3
5
4
1POWER
Connect the Soundbar’s AC power cable.
2SERVICE
Connect a USB storage device to upgrade the
product’s software.
3DIGITAL AUDIO IN (OPTICAL)
Connect to the digital (optical) output of an
external device.
4HDMI
Inputs digital video and audio signals
simultaneously using an HDMI cable.
Connect to the HDMI output of an external
device.
5HDMI TO TV (eARC/ARC)
Connect to the HDMI jack on a TV.
03 CONNECTING THE
SOUNDBAR
Connecting the power and units
Blue Blinks
(HW-Q935D only)
Rear of
Subwoofer
Bottoms of the Left and
Right Surround Speakers
Bottom of the
Soundbar Main Unit
• The LINK LED indicator stops blinking and glows a
solid blue when a connection is established between
the Soundbar, Subwoofer, and Surround speakers.
