Seite 1/11
Quick Installation Guide
EMR CK 7GI 0
Schnellinstallationsanleitung
Guide d'Installation Rapide
Guía de Instalación Rápida
Guida di Installazione Rapida
Gyors Telepítési Útmutató
Szybka Instrukcja Instalacji
Guia de Instalação Rápida
SPECIFICATIONS
Bus Interface
PCI Express-
Power input interface
15 pin SATA connector-
Port Configuration
2 x USB-C 3.2 Gen 2
System Requirements
7/8/ 10/11 Windows Vista/ 8.1/ , Linux
Available PCI Express x4 or x16 slot
( Express p2-x1 slot) NOT supported PCI
Operating Temperature
C ~ 60°C
Dimensions
80 20 x 58 x mm
Weight
32g
Features
-lane (x2). PCI Express Base Specification Revision 2.0 dual
Compliant with xHCI (eXtensible Host Controller Interface) specifications Revision 1.1
Management Specication Revision . Compliant with PCI Bus Power Interface 1.2
. Compliant with USB Attached SCSI protocol Revision 1.1
VDC / 9 . Each USB port supplies maximum +5.0 0. A power output to USB device
- . Built in over current protection on each USB port
-swapping feature allows connecting/disconnecting the Hot device without powering down
the system.
Package Contents
EMRICK07G
Driver CD
L ow profile bracket
Quick Installation Guide
English
Congratulations on the purchase of your Conceptronic EMRICK07G.
When problems occur, we advise you to visit our support site (go to www.conceptronic.net
and click on 'Support'). If you have other questions about your product and cannot find it on
our website, please contact us at support@conceptronic.net.
For more information about Conceptronic products, please visit the Conceptronic website:
www.conceptronic.net.
Installation & usage
Turn Off the power to your computer.
s cover. Unplug the power cord and remove your computer
Remove the slot bracket from an available PCIe slot.
s bus connector with the selected PCIe slot on To install the card, carefully align the card
the motherboard. Push the board down firmly.
* SATA power The PCI Express Card must be connected to the SATA power cable to the
jack.
s holding screw to secure the card. Replace the slot bracket
Replace the computer cover and reconnect the power cord.
Your computer will show the “New Hardware Wizard” on your screen. You can ignore this
“New Hardware Wizard” by clicking “Cancel”.
Windows Vista/7/8/ (32/64 bit): 8.1
-ROM in the optical drive of your computer. The AutoPlay option will be Insert the CD
shown automatically. Click on “Run Autorun.exe” to start the autorun menu.
Select “Install Drivers” and follow the onscreen instructions to install the required drivers
for the serial PCIe card.
When the driver installation is complete, restart your computer to ensure the drivers are
correctly loaded.
Windows (32/64 10/11 bit):
The computer will automatically recognize and install the new hardware. No driver
installation is required.
Safety & Warnings instructions
Keep the device away from water, humidity, fire or hot environments.
Keep your device and all its parts and accessories out of the reach of small children.
Do not leave the packaging material lying around carelessly. This may become
dangerous playing material for children.
Avoid dropping, throwing or crushing the device.
Do not open, change or damage the device.
Disconnect the product from the mains before cleaning.
e-free cloth. Clean the product with a dry, fibr
Disposal of waste electrical equipment: the product at a Dispose of
recycling point. Do not dispose together with household waste. Incorrect of
storage/disposal can harm the environment and/or cause injury.
CE marking:/ UKCA Conceptronic declares that this product
complies with the directives listed in the section 'Declaration of
Conformity'.
