CHE-HD200
HDMI 4K Extender with one-way IR up to 230ft
VER 1.0
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this manual
for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Table of Contents
1. Introduction............................................................................................
2. Features..................................................................................................
3. Package Contents................................................................................
4. Specications........................................................................................
5. Operation Controls and Functions......................................................
5.1 Transmitter Panel.............................................................................
5.2 Receiver Panel................................................................................
5.3 IR Pin Denition................................................................................
6. Application Example............................................................................
1
1
2
2
3
3
4
5
7
1. Introduction
2. Features
☆HDMI 2.0, HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
☆Supports 18Gbps bandwidth
☆Supports input and ou tput video resolution up to 4k2k@60H 4:4:4, extendsz
distance up to 164ft / 50 meters
☆Supports one HDMI loop output
☆Supports one-way IR pass-through
☆Supports HDR function
☆Supports PoC (Power over Cable) function, it means that either transmitter
or receiver is powe 1A pored supply by 12V/ wer adapter, the other doesn’t
need power supply.)
☆Supports automatic copy EDID function
☆Compact design for easy and exible installation.
1/7
The HDMI 18Gbps Extender can extend high denition video / audio signal
and one-way IR, and the distance is up to 164ft / 50 meters between trans-
mitter and receiver over a single Cat5e/6 cable. It supports resolution up to
4K2K@60Hz 4:4:4, 18Gbps and HDCP 2.2. In addition, the extender is equi-
pped with one-way IR pass-through which allows for source control and one
HDMI loop output.
The extender includ nd receiver unit. The trans-es two units: transmitter unit a
mitter unit is r ponsible for capturing HDMI input signal es and carries the signal
via one cost eective Cat6 cable, and emitting IR control signals. The receiver
unit is responsible for HDMI signal and transmitting IR control receiving the
signal.
The extender oers the most convenient soluti tenson for HDMI ex ion over a
single Cat5e/6 with long distance capability, and is the perfect solution for
any application.
