Seite 1/2
Connect Frame to Tent
–Insert one end of Main Tent Pole end
onto pin of pin & ring system at tent
corner on tent (illus. 4)
–Go to opposite end of pole and
gradually apply pressure to the pole
forming an arch until you are able to
insert the opposite pole end onto
pin & ring system
–Repeat for second pole (illus. 5)
SUNDOME™12’x10’ 2-ROOM
1Layout & Positioning
of Tent, Pole
Assembly
–Layout and position tent with door
facing desired direction. (illus. 1)
–Unzip door
–Stake down tent using the rings of the
pin & ring system at the corners of the
tent. Keep the floor taut. (illus. 2)
–Assemble Frame Poles by
interlocking shock-corded poles.
This will make two long poles.
–Insert the poles diagonally into Pole
Sleeves.The center of the poles should
cross forming an “X” in the middle of
tent. (illus. 1)
–Fasten Frame Tie on top of tent over
both poles. (illus. 1), (illus. 3)
2
When You Are Ready To Set Up Your
Tent
–Select a level campsite clear of rocks,
branches and other hard or sharp
objects.
–Do not set up your tent under trees.
–For best results in windy conditions,
position the end of tent into the wind.
–See owners manual for more tips.
Rainfly
Poles
Rainfly Part No. 9260C131
Main Tent
Poles
POLE ASSEMBLY PARTS
Assembled
poles
inserted
through
pole
sleeves
Frame Tie
Instructions apply to Part Number 9260D121
illus. 1
illus. 2 Tent stake
through ring
illus.4
Insert pole end onto
pin & ring
illus. 5 Tent
frame set-up
illus. 3
Frame Tie
Part No. 9260-128
Part No. 9260-130
Part No. 9260-129
3Attach Tent to Frame
Using Frame Clips
–Attach Frame Clips along
the edges of tent to frame poles
(illus. 6), (illus. 7)
–Make any adjustments to the tent
corner stakes that are needed.
–Stake down tent loops in front of
“D” style door.
4Attach Rainfly
–Assemble Rainfly Poles by
interlocking shock-corded poles
–Insert Rainfly Poles into reinforced
pockets located at the center
edges of the underside of Rainfly
(illus. 8), (illus. 9)
–Tie underside of Rainfly to the Rainfly
Poles with Frame Ties (illus. 9)
–Drape Rainfly over tent frame, pole
side down. The longer Rainfly Pole
should point out over front door and
rear window and the short rainfly
pole points over the side windows.
–Connect the four elastic loops with
“S” hooks, (found at the Rainfly
corners) to the four rings of the
pin & ring system located at the
corners of the tent.
–Secure Rainfly with Frame Ties
located on underside of fly (illus. 10)
–Stake out tent with (4) corner
guylines (illus.10)
illus. 7
Assembled tent without
Rainfly. Note the Frame Clips
located on edge of tent.
illus. 6
Frame Clips
Tent loops by door
illus. 8 Insert
Rainfly Pole piece into
pocket on underside
of Rainfly
illus. 10 Completed tent with Rainfly. Note where Rainfly Pole
pockets , pin & rings, and frame ties are located
THE COLEMAN CO., INC.
3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
MADE IN KOREA, ASSEMBLED IN THAILAND
PRINTED IN THAILAND REV. 6/01
illus. 9
Rainfly
Underside of
Rainfly
attaches to
frame poles
Corner
guylines “S” Hooks attach to rings at
the corners
Rainfly pockets
Rainfly Pocket
Frame
Ties
Things You Should Know
• Under certain conditions (cold weather, high humidity, etc.)
condensation will form on the inside surfaces of your tent. Condensation is
caused by water vapor from your breath, perspiration, or any wet clothing
inside your tent. It is NOT LEAKAGE through the tent fabric. It can be mini-
mized by removing wet clothing from your tent and by providing good ventila-
tion through the tent.
• Never store tent, even for a short period of time, without drying it thorough-
ly and brushing off caked dirt. Do not pack stakes or poles inside your tent.
Use separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF.
NEVER PULL ON THE TENT FABRIC OR TENT STAKE LOOP TO
REMOVE STAKE.
• TENT POLES SHOULD NOT BE LEFT TELESCOPED
TOGETHER DURING STORAGE.
• Seam sealer has not been provided with your tent. It is necessary
and we recommend seam sealing your tent prior to camping. Seam sealer
may be purchased through your local retailer or at your local sporting goods
store.
• Do not leave your tent set-up for weeks at a time, be aware that expo-
sure to the ultraviolet rays of the sun can seriously damage nylon material
and/or cause it to become discolored.
• See owners manual for more tips.
WARNING: KEEP ALL FLAME AND HEAT SOURCES
AWAY FROM THIS TENT FABRIC. This tent meets the flammability
requirements of CPAI-84. The fabric may burn left in continuous contact
with any flame source. The application of any foreign substance to the
tent fabric may render the flame-resistant properties ineffective.
