Please read this manual before connection and use.

•

Widescreen Kichen LCD ATSC/NTSC TV with

DVD Player and AM/TM Tuner

KTF-DVD 1093

KTF-DVD 7093

CAUTION: Use of controls or adjustments or performance of procedures other than those speciﬁed

herein may result in hazardous radiation exposure.

Please carefully study this manual and always keep it available. There are, however, some installation and

operation precautions which you should be aware of .

Important Safety Instruction

(1) Read these instructions-All the safety and operating instructions should be read before the product is

operated.

(2) Keep these instructions-The safety and operating instructions should be retained for future reference.

(3) Heed all warnings-All warnings on the product and in the operating instructions should be adhered to.

(4) Follow all instructions-All operating and use instructions should be followed.

(5) Do not use this apparatus near water-The apparatus shall not be exposed to dripping or splashing and

that no objects ﬁlled with liquids, such as vases, shall be placed on the apparatus.

(6) Clean only with dry cloth-Unplug this product from the wall outlet before cleaning. Do not use liquid or

aerosol cleaners. Clean only with dry cloth.

Exception: A product that is meant for uninterrupted service and that for some speciﬁc reason, such as

the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged

by the user for cleaning or any other purpose, may exclude the reference to unplugging the product in the

cleaning description otherwise required in 131.8(5)

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instruction-Slots

and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and

to protect it from overheating, and these openings must not be blocked or covered. The openings should

never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should

not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or

the manufacturer's instructions have been adhered to .

(11) Only use attachments/'accessories speciﬁed by the manufacturer. Do not use attachments not

recommended by the product manufacturer as they may cause hazards.

(8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

(9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two

blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.

The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet,

consult an electrician for replacement of the obsolete outlet.

(10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus. Power-supply cords should be routed so that they are not

likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords

at plugs, convenience receptacles, and the point where they exit from the product.

(12) Use only the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the appa-

ratus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from

tip-over.

Customer Service Hours

Hours: 800AM-11:00 PM EST, seven days a week.

E-Mail : techsupport@cobyusa.com

Phone: 718-416-3197, 800-681-2629, or 800-727-3592

Web: www.cobyusa.com

Important Safety Instruction

(13) Unplug this apparatus during lightning storms or when unused for long periods of time. Unplug it from

the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to

lightning and power-line surges.

(14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate

normally, or has been dropped.

(15) Power Sources- This product should be operated only from the type of power source indicated on the

marking label. If you are not sure of the type of power supply to your home, consult your product dealer or

local power company. For products intended to operate from battery power, or other sources, refer to the

operating instructions.

(16) Protective Attachment Plug-The product is equipped with an attachment plug having overload

protection. This is a safety feature. See instruction manual for replacement or resetting of protective device.

If replacement of the plug is required, be sure the service technician has used a replacement plug specified

by the manufacturer that has the same overload protection as the original plug.

(17) Outdoor Antenna Grounding- If an outside antenna or cable system is connected to the product, be

sure the antenna or cable system is grounded so as to provide some protection against voltage surges and

built-up static charges. Article 810 of the National Electrical Code, ANS/NFPA 70, provides information with

regard to proper grounding conductors, location or antenna- discharge unit, connection to grounding

electrodes, and requirements for the grounding electrode.

(18) Power lines- An outside antenna system should not be located in the vicinity of overhead power lines

or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing

an outside antenna system, extreme care should be taken to keep from touching such power lines or

circuits as contact with them might be fatal.

(19) Overloading- Do not overload wall outlets, extension cords, or integral convenience receptacles as

this can result in a risk of ﬁre or electric shock.

(20) Object and Liquid Entry- Never push objects of any kind into this product through openings as they

may touch dangerous voltage points or short-out parts that could result in a ﬁre or electric shock. Never

spill liquid of any kind on the product.

(21) Servicing -Do no attempt to service this product yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

(22) Replacement Parts-When replacement parts are required, be sure the service technician has used

replacement parts speciﬁed by the manufacturer or have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric, or other hazards.

(23) Safety Check- Upon completion of any service or repairs to this product, ask the service technician

to perform safety checks to determine that the product is in proper operating condition.

Continued

. The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert

the user to the presence of uninsulated "dangerous voltage" within the product's enclosure

that may be of suﬃcient magnitude to constitute risk of electric shock to persons.

. The exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in the literature

accompanying the product.

WARNING: To reduce the risk of ﬁre or electric shock, do not expose this appliance to rain or moisture.

Dangerous high voltage is present inside the enclosure. Do not open the cabinet.

CAUTION: To prevent electric shock, match wide blade plug to wide slot, and fully insert.

CAUTION: This Digital Video Disc Player employs a laser System. To prevent direct exposure to the

laser beam, do not try to open the enclosure. When open and the interlocks are defeated,

visible laser radiation is present.

Use of controls or adjustments or performance of procedures other than those speciﬁed

herein may result in hazardous radiation exposure. DO NOT STARE INTO BEAM.

FCC NOTICE: This equipment has been tested and found to comply with the limits for a digital device. Pursuant with Class B

the These limits are designed to provide reasonable protection against harmful interferenceFCC Rules,Part 15.

in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and if not installed and used in

accordance with the instruction may cause harmful interference to radio communication.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: SHOCK HAZARD-DO NOT OPEN

AVIS: RISOUE DE CHOC ELECTRIQUE-NE PAS OUVRIR

Safety Precautions

NOTICE: This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual

property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended

for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering

or disassembly is prohibited.

Note: 1. The batteries should not be exposed to excessive heat such as

sunshine, fire or the like.

2. The mains plug or an appliance coupler was used as the disconect device,

the disconnect device shall remain readily operable and should not be

obstructed during intended use.

Table of Contents

IMPORTANT SAFETY INSTRUCTIONS Page

SAFETY INFORMATION

TABLE OF CONTENTS

.1.

Unpacking

Please make sure the following items are included with your DVD player. If any items are

missing, contact your dealer.

Main Unit Remote Control

Adapter

RCA Cable

UNPACKING...................................................................................................................... ........................................1

NOTE ON DISC................................................................................................................... ......................................2

IDENTIFICATION OF CONTROLS.........................................................................................................................3-5

BUTTONS ON THE MAIN UNIT.................................................................................................................................3

REMOTE......................................................................................................................... ...........................................5

CABLE CONNECTIONS.............................................................................................................. ..............................6

MOUNTING....................................................................................................................... .........................................7

BASIC OPERATION................................................................................................................ ................................8-9

TIME...........................................................................................................................................................................8

RADIO.......................................................................................................................... ..............................................8

DVD............................................................................................................................ ................................................8

TV...............................................................................................................................................................................9

AV............................................................................................................................. ..................................................9

FUNCTION BUTTONS (BUTTONS ON THE REMOTE)....................................................................................10- 13

DVD SETUP........................................................................................................................................................14-15

TV FUNCTION....................................................................................................................................................16-17

TROUBLE SHOOTING............................................................................................................................................18

SPECIFICATION.................................................................................................................. ...............................19-20
