Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Cobra Marine HH600 (33 Seiten) in der Kategorie Walkie-talkies. Dieser Bedienungsanleitung war für 18 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/33
DISTRESS
VHF MARINE RADIO
MR HH600 FLT GPS BT
Printed in China Part No. 480-1093-P Version C
Owner’s Manual
Nothing Comes Close to a Cobra
® English A1 English
Our Thanks to You and
Customer Assistance
Introduction
Our Thanks to You •
Thank you for purchasing a CobraMarine
® VHF radio.
Properly used, this Cobra® product will give you
many years of reliable service.
How Your CobraMarine VHF Radio Works
This radio is a battery-powered portable transceiver for use afloat. It gives you
two-way vessel-to-vessel and vessel-to-shore station communications, primarily
for safety and secondarily for navigation and operational purposes. With it, you
can call for help, get information from other boaters, talk to lock or bridge tenders,
and make radiotelephone calls to anywhere in the world through a marine operator.
Besides two-way communications, the radio can provide quick access to receive
all the NOAA (National Oceanographic and Atmospheric Administration) weather channels
and alert you to weather emergencies with a tone on a weather channel you can tune in
for your area.
Global Positioning Sytem (GPS)
Your Cobra Marine radio includes a built-in GPS receiver. Your position will be continuously
indicated on the LCD and, most importantly, it will be included automatically with any DSC
Distress message you may need to send. That will take the “search” out of “search and
rescue”.
Customer Assistance •
Should you encounter any problems with this product, or not understand
its many features, please refer to this owner’s manual. If you require further
assistance after reading this manual, Cobra Electronics offers the following
customer assistance services:
For Assistance in the U.S.A.
Automated Help Desk English only.
24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Assistance Operators . English and Spanish
8:00 a.m. to 5:30 p.m. Central Time Mon. through Fri. (except holidays)
773-889-3087 (phone).
Questions . English and Spanish
Faxes can be received at 773-622-2269.
Technical Assistance English only.
www.cobra.com/support/faqs/marine-radios ©2018 Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
Customer Assistance
A2 English
Radio Controls
and Indicators
Introduction
Instant
Channel
16+ Button
Channel
Up Button
ON/OFF/
Volume Control
Speaker/
Microphone
External Cover
Antenna
Backlit
LCD
Screen
Battery
Backlight/
Key Lock
Button
Push
to Talk
Button
Channel
Down
Button
Speaker
Belt Clip
Battery
Door
Screw
VHF Microphone
Rewind-Say-Again®
Button
Man Overboard
(MOB) Button
Distress
Key
LED Flashlight/
S.O.S.
Squelch
Button
Distress
Key
Battery
Door
Screw
Bluetooth® Calling
Microphone
Soft Key Functions
MRHH600_ENG_CVR.indd 1-3 4/27/18 3:44 PM
Product Features (continued) •
EMERG
USA 6W MEM
41° 54.523N
087° 47.192W
DATE:06/01
TIME:10:00
WXMENU CALL MORE
16
A3 English
Introduction
Backlit Screen •
Built-In GPS Receiver
Shows GPS coordinates on screen and
automatically sends GPS location with
DSC calls.
Digital Selective Calling (DSC Class-D)
Allows the ability to maintain a listening
watch on VHF Channel 16 while
simultaneously monitoring Channel 70
for DSC calls. Allows sending a distress
message at the touch of a button as well
as specific station-to-station calls. Radio
utilizes two (2) built-in encoders (receivers).
MicroBlue TM
Bluetooth® Wireless Technology in a unique
noise canceling design. Widely compatible
for all mobile phones with Bluetooth®
wireless technology.
Easy Redial Operation
Redial of last phone number dialed.
Voice Dialing
Supports standard mobile phone
voice dialing when paired to a
compatible mobile phone.
Floating
This radio will float if dropped overboard.
It has an orange stripe so it’s easy to
retrieve.
Must use included battery to float.
Rewind-Say-Again®
Replays missed VHF calls.
6 Watt VHF
Select between 1, 3 or 6 watts for short and
long range communication.
Flashlight/S.O.S. Light
The radio can be used as a flashlight, strobe
light or S.O.S. signal.The light flashes when
dropped in the water.
Submersible to IPX8 Standards
Waterproof to 3.3 ft (1 m) of water
for 30 minutes.
All NOAA Weather Channels
Instant access to all National Weather
Channels, 24 hours a day.
Emergency Weather Alert
Receive NOAA alerts when threatening
weather is nearby.
Product Features •
Backlit Screen
and Product Features Product Features
Introduction
MOB (Man Over Board)
The radio dedicated MOB button marks and
memorizes the position information if a crew
member falls overboard.
Noise Canceling Microphone
Reduces effect of environmental
noise when speaking.
Basic Navigation
Basic navigation features include digital
compass, waypoint navigation, course,
speed, distance, etc.
USA/International/Canada Channels
Allows operation on any of the three (3)
different channel maps established for
these areas.
BURP
The Cobra exclusive BURP feature expels
water from the speaker grill if the unit is
dropped in the water or is subjected to
extreme rain and weather.
Speaker/Mic Jack
Allows connecting optional Cobra
Lapel Speaker/Mic and other Cobra
accessories.
Instant Channel 16/9
Provides instant access to priority Channel
16 and calling Channel 9.
NMEA Out
NMEA 0183 output to display other vesels
and their information transmitted by DSC
or your chartplotter.
Unlimited Memory Channels
Allows programming of unlimited
VHF memory channels.
Tri-Watch
Use to monitor three (3) channels
at once — Channel 16, Channel 9 and one
other selected channel.
Channel Names
Friendly VHF channel names under the
channel number.
Channel Scan/Memory Scan
Use to scan through unlimited
channels or memory locations to find
conversations in progress.
Signal Strength Meter
Shows the strength of incoming or outgoing
signals.
Button/Key Lock
Prevents accidental setting changes
when button lock is set.
Illuminated Buttons
Allows high visibility of all function buttons.
AA Battery Compatible
Good for emergency backup.
Includes AA battery tray (P/N CM 110-035).
120V/12V Charger Included
Use to charge battery pack, at home,
in a car or in a boat.
Locking Desktop Charger
Holds the radio or battery in place while
charging. Vertical or horizontal mounting.
A4 English
Introduction
Notes
Signal Level Icon
Battery Power Icon
Weather Icon
Active Channel
Transmit and
Receive Icons
Left blank intentionally for your notes
Rewind-Say-Again® Icon
Bluetooth VOX Icon GPS Icon
MENU Soft Key
WEATHER
Soft Key CALL
Soft Key
MORE Soft Key
Channel Description
MRHH600_ENG_CVR.indd 4-6 4/27/18 3:44 PM
Introduction
1
Nothing Comes Close to a Cobra
®
Table of Contents
Introduction
Our Thanks to You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Customer Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Radio Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A2
Backlit Screen ................................................. A3
Product Features ............................................... A3
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General Precautions 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommendations for Marine Communication . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FCC Licensing Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation
Included in this Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Install/Remove Antenna 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrist Strap and Belt Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Batteries and Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operating Your Radio
Getting Started ................................................. 12
Setup Mode Programming 17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Standby/Receive and Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
NOAA Weather Mode Programming 28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Advanced Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Rewind Operation 38 ...............................................
Bluetooth® Mode Pairing and Programming 40 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mobile Phone Operation With Bluetooth
® .............................42
Floating Feature/BURP 46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
VHF Marine Radio Protocols
VHF Marine Radio Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Voice Calling ................................................... 50
Routine DSC Calling 52 .............................................
Radiotelephone Calls 69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency Messages and Distress Procedure . . . . . . . . . . . . . . . . . . . . . . . . . 70
Warranty and Trademark
Limited 3-Year Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Trademark Acknowledgement 73 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Service
Product Service ................................................ 74
Specications (Typical) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Appendix
VHF Marine Channel Assignments 76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weather Channel Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Accessories ................................................... 94
MRHH600_ENG_MANL.indd 1 4/27/18 3:44 PM
Produktspezifikationen
| Marke: | Cobra |
| Kategorie: | Walkie-talkies |
| Modell: | Marine HH600 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Cobra Marine HH600 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Walkie-talkies Cobra
27 September 2024
17 September 2024
2 September 2024
30 August 2024
11 August 2024
8 August 2024
2 August 2024
30 Juli 2024
30 Juli 2024
28 Juli 2024
Bedienungsanleitung Walkie-talkies
- Walkie-talkies Tristar
- Walkie-talkies Exibel
- Walkie-talkies Nedis
- Walkie-talkies SilverCrest
- Walkie-talkies Brennenstuhl
- Walkie-talkies AEG
- Walkie-talkies Alecto
- Walkie-talkies Denver
- Walkie-talkies MarQuant
- Walkie-talkies Kenwood
- Walkie-talkies Rocktrail
- Walkie-talkies Esscom
- Walkie-talkies Topcom
- Walkie-talkies Motorola
- Walkie-talkies Elro
- Walkie-talkies Olympia
- Walkie-talkies Switel
- Walkie-talkies Akai
- Walkie-talkies GoGEN
- Walkie-talkies MT Logic
- Walkie-talkies Sencor
- Walkie-talkies Reer
- Walkie-talkies Furuno
- Walkie-talkies Simrad
- Walkie-talkies Flamingo
- Walkie-talkies Alinco
- Walkie-talkies Icom
- Walkie-talkies Midland
- Walkie-talkies President
- Walkie-talkies Audioline
- Walkie-talkies Binatone
- Walkie-talkies Brondi
- Walkie-talkies Doro
- Walkie-talkies Vtech
- Walkie-talkies Oricom
- Walkie-talkies Albrecht
- Walkie-talkies Uniden
- Walkie-talkies Dickie Toys
- Walkie-talkies Stabo
- Walkie-talkies Yaesu
- Walkie-talkies IMC Toys
- Walkie-talkies Oregon Scientific
- Walkie-talkies Logicom
- Walkie-talkies Vertex Standard
- Walkie-talkies Wintec
- Walkie-talkies Dickie
- Walkie-talkies MAAS
- Walkie-talkies GME
- Walkie-talkies Hoffer
- Walkie-talkies Baofeng
Neueste Bedienungsanleitung für -Kategorien-
14 Oktober 2024
14 Oktober 2024
5 Oktober 2024
1 Oktober 2024
25 September 2024
22 September 2024
18 September 2024
14 September 2024
13 September 2024
13 September 2024
