I N S T A L L A T I O N I N S T R U C T I O N S
Confidence Carts
MFM, PFM, MFQ, PFQ
MFM, PFM, MFQ, PFQ Installation Instructions
2
DISCLAIMER
CSAV, Inc., and its affiliated corporations and subsidiaries
(collectively, "CSAV"), intend to make this manual accurate and
complete. However, CSAV makes no claim that the information
contained herein covers all details, conditions or variations, nor
does it provide for every possible contingency in connection
with the installation or use of this product. The information
contained in this document is subject to change without notice
or obligation of any kind. CSAV makes no representation of
warranty, expressed or implied, regarding the information
contained herein. CSAV assumes no responsibility for
accuracy, completeness or sufficiency of the information
contained in this document.
IMPORTANT WARNINGS AND
CAUTIONS!
WARNING:
A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION:
A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING:
Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING:
Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
WARNING:
Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components on the cart does not exceed 125 lbs (56.70
kg) for the MFM and MFQ, and 200 lbs (90.72 kg) for the
PFM and PFQ.
Installation Instructions MFM, PFM, MFQ, PFQ
3
[918]
36-1/8”
[640]
25-1/4”
[755]
29-3/4”
[100]
4”
[253]
10”
[1146]
45-1/8” [39]
1-1/2”
[65]
2-1/2”
[955]
37-5/8”
[177]
7”
[157]
6-1/4”
[1455]
57-1/4”
[810]
31-7/8”
[1261]
49-5/8”
15°
45°
NOTE: CUSTOM INTERFACE BRACKET
NOT SHOWN. THE CUSTOM INTERFACE
BRACKET NEEDED FOR YOUR DISPLAY
WILL ADD BETWEEN ½”AND 2” IN DEPTH
AND MAY AFFECT LOCATION OF DISPLAY
ON THE MOUNT. SEE PSBU DRAWING ALSO.
WEIGHT CAPACITY: 200 LBS
HEIGHT ADJUSTMENT: 37-5/8” TO 49-5/8” IN 2” INCREMENTS
(GROUND TO MIDDLE
OF SCREEN)
TILT/ROLL/YAW: +15° TO +45°/ 0°/
+ 0°
ALL MEASUREMENTS IN: [MILLIMETERS]
INCHES
+
PFM
[918]
36-1/8”
[640]
25-1/4”
[755]
29-3/4”
[100]
4”
[254]
10”
[1088]
42-7/8”
[157]
6-1/4”
[39]
1-1/2” [65]
2-1/2”
[177]
7”
[955]
37-5/8”
[1393]
54-7/8”
[810]
31-7/8”
[1259]
49-5/8”
15°
45°
NOTE: CUSTOM INTERFACE BRACKET
NOT SHOWN. THE CUSTOM INTERFACE
BRACKET NEEDED FOR YOUR DISPLAY
WILL ADD BETWEEN ½”AND 2” IN DEPTH
AND MAY AFFECT LOCATION OF DISPLAY
ON THE MOUNT. SEE PSBU DRAWING ALSO.
WEIGHT CAPACITY: 125 LBS
HEIGHT ADJUSTMENT: 37-5/8” TO 49-5/8” IN 2” INCREMENTS
(GROUND TO MIDDLE
OF SCREEN)
TILT/ROLL/YAW: +15° TO +45°/ 0°/ 0°
ALL MEASUREMENTS IN: [MILLIMETERS]
INCHES
+ +
MFM
DIMENSIONS
