Seite 1/6

www.chasing.com

support@chasing-innovation.com

User Manual

V1.0

Disclaimer

Any user, before using the GLADIUS MINI S underwater drone, must read this statement carefully.

Once this product is used, it shall be deemed that the user has recognized and accepted the entirety of this

statement.

When using this product, if personal injury or property damage (including direct or indirect loss) occurs due to the following reasons,

CHASING will not be liable for compensation:

1. Damage caused by an operator in poor physical or mental condition when using the machine.

2. The operator's subjective intention to deliberately cause personal injury, property damage, etc.

3. Compensation for any further related damage caused by an accident.

4. The product is not properly assembled or operated according to the guidance in this manual.

5. Other damages caused by self-modification or replacement using non-CHASING accessories or parts, resulting in poor operation of

the entire ROV.

6. Damage caused by using non-CHASING products or imitating CHASING products.

7. Compensation for damage caused by operation error or subjective judgment error.

8. Problems such as natural wear and tear, corrosion, and circuit aging that cause the ROV to operate poorly.

9. The ROV issues a low-battery warning and the operator still does not recall the ROV, causing the ROV to lose contact.

10. Knowing that the ROV is in an abnormal state (such as obvious failure of main components, obvious defects, or missing parts), and

the operator still puts it in water, thereby resulting in damage.

11. Damage caused by the ROV being in sensitive waters such as military management zones and open ocean areas without official

permission.

12. Operating the ROV in adverse water conditions (such as strong winds, large waves, mud and sand).

13. The ROV encounters uncontrollable situations such as intense collisions, tsunamis, or being swallowed by animals.

14. Damage due to any image data obtained by the operator using the ROV that infringes on intellectual property rights.

15. Other damages that are not within the scope of CHASING's responsibility.

ROV

1. SD card slot

2. LED light

3. Camera

4. Thruster

5. Drain hole/Exhaust hole

6. Tether cable socket/charging port

7. Accessory installation area

8. Peripheral port ( Note: When an external device is not connected,

screw in the plug before allowing contact with water.)

The GLADIUS MINI S is an underwater drone designed for underwater photography, scientific exploration, and safety inspection. Compared with the previous

generation GLADIUS MINI, the MINI S supports the mounting of grabber claws, sports cameras, etc. Battery capacity is upgraded and the battery life is

increased by 70%. With CHASING's patented motor technology, the chance of sand jamming can be effectively reduced. The ROV has a built-in 4K/12 million

pixel EIS camera, 1200 × 2 lumens LED lights, and a 64G pluggable Micro SD memory card. A professional wired direct-connect remote controller ensures stable

operation and a continuous connection. The aluminum alloy compact fuselage (weight less than 3kg) and optional E-Reel allow one person to quickly deploy the

drone in 3 minutes. It is a lightweight, easy-to-use, and reliable underwater drone.

131

1. Power switch: turn on/off remote controller.

2. Power indicator: green light (high battery level); blue light (medium

battery level); red light (low battery level).

3. Wi-Fi switch button: switch between 2.4G/5G Wi-Fi

4. Remote controller connection indicator: ROV/2.4G/5G

5. One-key reset: in any posture, the ROV can be reset to the horizontal

state.

Long press to switch the control mode.

6. Unlock: lock/unlock the motor, the current state of the motor can be

confirmed in the App.

7. Fill light control button: fill light [off/medium brightness/high

brightness] control.

8. Safety buckle: can be used with a safety rope to prevent the remote

controller from falling.

9. Control stick: used to control the navigation of the ROV. Refer to the

navigation posture for specific operations.

10. Grabber claw control: short press to close and stop, long press to

open.

11. Video/Photo: short press to take photo/start or end video recording;

long press to switch between photo and video mode.

12. Right scroll wheel: none

13. Left scroll wheel: adjust the pitch angle

14. Type-C port: direct communication between the controller and the

mobile phone/tablet

15. HDMI port: 1080P high-definition real-time image output

16. Tether cable socket/charging port

17. Mobile phone/tablet bracket: used to attach the mobile phone/tablet.

Open both ends to insert the device, then press the button on the back

to tighten the device.

Note: Damage caused by immersion in liquid is not covered by the

warranty. To avoid damage, do not put the remote controller in water.

Remote controller indicator light

Battery: The battery indicator light has three color states. Red: the red light stays on without flashing when the battery level is between 10% and 30%; the red

light flashes when the battery level is between 0% and 10%. Blue: the blue light stays on without flashing when the battery level is between 30% and

70%.

Green: the green light stays on without flashing when the battery level is between 70% and 100%.

2.4G: Wi-Fi indicator light, always on when the 2.4G frequency band is working.

5G: Wi-Fi indicator light, always on when the 5G frequency band is working.

ROV: communication between the remote controller and the ROV (flashing: not connected, steady: connected).

One-key reset button: when the machine is in a non-horizontal state, the blue light under the button is always on.

Unlock button: after unlocking, the blue light under the button is always on.

Fill light button: when the fill light is bright, the blue light under the button is always on. when the fill light is low, the blue light under the button flashes. when the

fill light is turned off, the blue light under the button is off.

100/200m tether cable & winder

The winder is used to store the tether cable, and the tether cable is used to connect the ROV

and the controller.

1. Tether cable socket 2. Winder shell

3. Tether cable 4. Hanging buckle

Note: Do not put the unconnected tether cable socket into the water or allow liquid to

splash into it. Check whether the O-ring on the tether cable socket is missing or damaged.

If so, please replace it before use.

Install the CHASING GO1 App

Installation and connection

CHASING GO1 App: (For iOS 9.0/Android 4.4 and above) Scan the QR code below to
