Introduction
Disclaimer Installation of the Power System Advanced Parameters Daily Use
Maintenance & Repair
Explanations for Protections
Troubleshooting & Warning Tones
Installation of the Power System
Attentions
Composition of the Power System
Voltage
(V)
4 V6
(12S LiPo)
30 Inch
Foldable
Propeller
207 . 3
347 . 4
390.2
484.7
536.7
653.3
787.8
862.9
1031.0
1225.0
1563.2
2169.4
2486.9
12.3
10.9
10.6
10.0
9.7
9.1
8.7
8.4
8.0
7.5
6.9
6.2
5.9
Propeller ThrustThrottle
(%) (g)
Ampere
(A)
Power
(W)
Efficiency
(g/W)
The ESC was unable to start the motor.
The ESC was unable to start the motor.
The power-on voltage was 18V.
The power-on voltage was above 55V.
Possible CauseWarning ToneTrouble
“BBB...” a single beep that repeats rapidly. The throttle stick wasnot moved to the bottom position.
There was no throttle signal output from the TH
channel on the receiver.
The battery voltage was too low.
The battery voltage was too high.
Solution
Move the throttle stick to the bottom position.
Check if the transmitter & receiver are well bound; check if the throttle
control cable has been properly plugged into the TH channel.
Change a suitable and fully charged battery.
Change a suitable and fully charged battery.
“B, B, B...” a single beep that repeats
(the time interval is 1 second).
“BB, BB, ...” a double beep that repeats
( the time interval is 1 second.)
“BBB, BBB, ...” a triple beep that repeats
(the time interval is 1 second).
DIP Switch 1
ON
ON
ON
ON
OFF
OFF
OFF
OFF
DIP Switch 2
ON
OFF
ON
OFF
ON
OFF
ON
OFF
DIP Switch 3
ON
ON
OFF
OFF
ON
ON
OFF
OFF
Color of the LED
White
Light Blue
Purple
Blue
Yellow
Green
Red
LED Disabled
Thank you for purchasing this HOBBYWING product! Brushless power systems can be very
dangerous. Any improper use may cause personal injury and damage to the product and
related devices. We strongly recommend reading through this user manual before use.
Because we have no control over the use, installation, or maintenance of this product, no
liability may be assumed for any damage or losses resulting from the use of the product. We
do not assume responsibility for any losses caused by unauthorized modifications to our
product. We, HOBBYWING, are only responsible for our product cost and nothing else as
result of using our product.
• Always keep your drone away from crowd, high-voltage power lines and obstacles, fly your
The X8 brushless power system is a power system capable of carrying a load of 5~7kg (per
rotor) for agricultural drones. It can provide the thrust of up to 15kg and match 30/35mm
carbon fiber tube arms. It’s waterproof an dustproof to IPX standard and resistant to 6
rainwater, pesticides, salt spray, sand, dust, mud, sandy soil, high temperature and impact. It
also features the algorithm used for optimizing the FOC ESC & Motor system and making
the system more balanced, multiple protections like power-on self detection, power-on
abnormal voltage, over-current and motor lock-up, and the real-time data output function.
drone in accordance with relevant safety regulations.
• Never get close to the high-speed rotating propeller & motor, otherwise you may get hurt.
• Check if all the parts are in good condition before use. If there exists any damaged part,
please contact the factory for replacement.
• Check if any screw for connecting the parts is loose and the motors are horizontal before
each flight.
• The bore diameter of the arm for the X8 power system is 40mm.
• The whole power system has been assembled before leaving the factory, it’s ready-to-use
and you can directly mount it on your agricultural drone as per the rotation direction
• You can change the light color of the LED set. In that case, you need to disassemble the
light cover and slide the DIP switches accordingly.
• You can rinse the motor with fresh water after each flight to keep it clean.
(CW/CCW) marked on the motor.
• Motor Lock-up Protection:
The ESC will cut off its output to the motor immediately and won’t try to restart the motor
when it detects the motor is locked up. In this condition, you need to pull the throttle stick
to the bottom position first and then push it upward to clear the error and restart the ESC
• Start-up Protection:
The ESC will shut down the motor if it fails to start the motor normally within 2 seconds
by increasing the throttle input. In this case, you need to move the throttle stick back to
the bottom position and restart the motor. (Possible causes of this problem: poor
connection/ disconnection between the ESC and motor wires, propellers are blocked,
• The (Black/Red/White) tri-color cable is for outputting data & updating ESC firmware,
the (White/Black) bi-color cable is the throttle signal cable, and the yellow wire is the RPM
signal output wire.
• The data signal wire is for outputting throttle input, throttle output, motor RPM, input
current, output current, input voltage, capacitor temperature, MOS temperature, and etc.
• The throttle range of the ESC is fixed at 1100~1940µs.
and etc.)
to resume the output.
• Over-current Protection:
The ESC will cut off its output immediately when the peak current gets close to 300A.
It only restarts after you power it off and then back on.
• Throttle Signal Loss Protection:
when the ESC detects loss of signal for over 0.25 second, it will cut off the output
immediately to avoid an even greater loss which may be caused by the continuous
high-speed rotation of propellers. The ESC will resume the corresponding output after
normal signals are received.
1. How to Change the Light Color
Unscrew the two M3*8 screws for fastening the light cover with a screw driver, slide the DIP
switches accordingly (as shown below) to change the light color (it’s Green by default),
mount the cover back after setting.
2. How to Replace a Propeller
• Unscrew the two M6 *22 screws for fastening the blades with a screw driver and change
the blade(s). If you also want to change the propeller adapter, then you need to unscrew
the four M3*10 screws for fixing the adapter with another screw driver and change the
whole set of propeller.
• When mounting the propeller, you need to mount the bottom cover (of the propeller
adapter) on the motor first, then blades, spacers and the top cover (of the propeller
adapter), and then fix them with screws. Please note that the blades can rotate freely
after fastening them with M6 screws, and ensure that you will also apply some glue to
the screws after fastening the propeller adapter to the motor with M3 screws.
Please contact Hobbywing for after-sales service timely when the power system is damaged.
You can replace the damaged part(s) with the replacements (included in the product box) on
condition that the coming operation won’t affect the performance of the power system,
you’ve contacted and confirmed with the customer service representative; it’s forbidden to
replace the damaged part(s) with other parts you configure. Please contact Hobbywing for
repair timely when serious damage occurs.
• Motor x 1
• ESC x 1
• Propeller x 1
• Motor Mount x 1
• Screws x (several)
• LED Set x 1
• Tube Adapter x 1 (from 35mm to 30mm)
• Max. Thrust:
• Recommended Load (/Rotor): 5-7kg/rotor
15kg
• Operating Temperature: -20℃~50
• Recommended LiPo Battery: 12S (Up to 52.2V)
℃
• Total/Combo Weight:
• Recommended Carbon Fiber Tube: 40mm
1150g
• Waterproof & Dustproof Standard: IPX6
Arm Screw Holes M4（ ）
Propeller
Mounting Hole 35mm
Powertrain Arm
Motor
Built-in ESC
CW or CCW Mark
ESC Status Indicator
Motor
• Model: 8120
• Outer Diameter: 90.2mm
• KV Rating: 100KV
Propeller: 30* 11
ESC
• Cont. Current: 80A ( Non-hermetic Ambient
Temperature 60 ) ≤℃
• Recommended Input Voltage: 6-12S LiPo
• Fixed Throttle Range:
• Peak Current: 100A ( Non-hermetic Ambient
Temperature 60 ) ≤℃
1100-1940µs
Inch
2001
3009
3999
5012
5999
7013
7988
9019
9990
11017
12005
13991
15289
4.5
7.5
8.5
10.5
11.7
14.2
17.1
18.7
22. 4
26.6
33. 9
47.1
54.0
40%
48%
50%
54%
56%
60%
64%
66%
70%
74%
80%
90%
100%
