CLOUDFAN DC INSTALLATION & USER MANUAL
ATTENTION ELECTRICIANS:
ANY PROBLEMS FOUND DURING INSTALLATION OF THE FAN PLEASE CONTACT THE
NATIONAL WARRANTY NUMBER PRIOR TO LEAVING SITE.
DO NOT REMOVE THE FAN FROM THE CEILING UNLESS INSTRUCTED TO DO SO.
National Warranty Number | 1300 116 305
Monday to Friday 9am to 5pm AEST
g
NOTE: THIS FAN MUST BE INSTALLED BY A LICENSED AND QUALIFIED
ELECTRICIAN IN ACCORDANCE WITH LOCAL AUTHORITY REGULATIONS
Australian Edition Version 2.3 September 2020
PLEASE NOTE: THE REMOTE CONTROL COMES PRE-PROGRAMMED TO THE FAN
REPROGRAMMING IS ONLY REQUIRED WHEN REPLACING THE REMOTE CONTROL
PAGE 2 OF 20 Ver. 1.0 2022
NOTE: THIS FAN MUST BE INSTALLED BY A LICENSED AND QUALIFIED
ELECTRICIAN IN ACCORDANCE WITH LOCAL AUTHORITY REGULATIONS
IMPORTANT INFORMATION - PLEASE READ BEFORE ATTEMPTING INSTALLATION
Please Note: Nothing in this manual is intended to instruct or assist untrained or
unqualied persons to install this product. Additionally, it is the responsibility of the
installer and user to apply common sense and care at all times.
Please note: Minor design changes may result in slight variations between the product illustrations and the fan contained within the packaging.
1. Please read these instructions carefully, be mindful of all warnings and safety information shown throughout this
manual. Should you have any questions, please contact 1300 116 305.
2. Please review the accompanying assembly diagrams before attempting installation.
3. This fan MUST be installed by a licensed & qualied electrician according to local authority regulations and in
accordance with current wiring rules AS/NZS3000. Therefore, to protect our repair personnel, on-site warranty claims
will not be accepted if products have been installed by unlicensed persons.
4. A copy of the purchasing receipt and proof of installation by a licensed and qualied electrician according to local
authority regulations is required for all warranty claims.
5. Where special access equipment is required in accordance with local authority regulations all associated costs are
the responsibility of the owner.
6. We reserve the right to charge a $175 service fee for all call outs where the fan is found not to be defective and / or
where access is not provided.
7. An isolation switch providing full disconnection of both fan and light must be tted in accordance with the wiring rules
(AS/NZS 60335.1 C1.7.12.2). In addition to all pole disconnection an isolation switch must be installed for each
individual fan located in the same room to allow for programming and ongoing maintenance.
8. The Fan and Light (if supplied) must be earthed.
9. Your warranty will be void if a solid state dimmer or any other brand of wall or remote controller is used.
10. Installation using steel beams, grid ceilings and exible structures are not recommended due to their inability to
absorb vibration from normal operation. Timber is the recommended material to support the fan.
11. To avoid possible electric shock during installation, be sure electricity is turned off at the main power box before
commencing work. Disconnect power by removing fuse or turning off circuit breaker before installing the fan. Ensure
all spliced connections are adequately insulated.
12. Warning! Do not allow the rotating fan blades to come into contact with any object, this can cause serious injury or
death.
13. Damage caused by; incorrect installation, Force-majeure, lightning, electrical surges & spikes, exposure to water,
pests or moisture is not covered under warranty.
14. In accordance with AS/NZS60355-1 & ASNZS60355-2-80: “This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.”
15. Cleaning and user maintenance shall not be made by children.
16. Blades must be replaced only as a complete set. Blades are supplied only as a pre-balanced set and the replacement
of individual blades may void the warranty by causing mechanical damage to the motor, excessive noise or premature
wear.
17. Do not use outdoors where the fans could be directly exposed to water or moisture. Incorrect installation can be
dangerous and will void the warranty.
18. No more than eight (8) DC fans per lighting circuit as this may cause intermittent tripping.
19. This fan is set up for optimum airow. The blade to ceiling is 350mm which may require simple modication to the
downrod to meet Australian Standards on some ceilings.
PAGE 3 OF 20Ver. 1.0 2022 National Warranty Hotline: 1300 116 305
Monday to Friday 9am to 5pm AEST
Please Note: The fan is set up for optimum airow. To achieve the 2.1 metre oor
clearance as per Australian Standards, the down rod can be cut and modied to the
required length if necessary without voiding the warranty.
LOCATION AND INSTALLATION REQUIREMENTS
Provide adequate clearance from the oor. The lowest point on the fan
blades must be at least 2.1m (7 feet) from oor level in Australia and at
least 2.3m from oor level in the European Union and afliated countries.
Make sure that the chosen location of the fan will not allow the rotating
fan blades to come into contact with any objects. Ensure ceiling joists are
sound and of adequate size and strength to support a 25Kg (55lb) load.
To reduce the risk of re, electrical shock or personal injury, ensure that the
fan mounting bracket is supported directly from the building structure. DO
NOT mount to an outlet box.
The mounting bracket must be rmly screwed to a load bearing structure e.g. a concrete ceiling, steel structure or timber
frame. If a timber frame is to be added it must be securely nailed or screwed between two beams.
After the fan is completely installed, check to make sure that all connections are secure to prevent the fan from falling
and/or causing damage or injury.
To reduce the risk of personal injury, do not bend or damage the motor or Fan Assembly when handling or during
installation.
Please ensure special care is taken when assembling the fan. Each screw must be sufciently tightened.
FAN ASSEMBLY & PARTS LIST - WITHOUT LIGHT KIT ................................. 4
FAN ASSEMBLY & PARTS LIST - WITH LED LIGHT KIT ................................. 5
INSTALLING EXTENSION ROD (OPTIONAL ACCESSORY) 6-7 .......................
INSTALLING FAN - WITHOUT LIGHT ........................................................... 8-9
INSTALLING FAN - WITH LIGHT 10-11 ...............................................................
FAN REMOTE CONTROL PROGRAMMING 12 ..................................................
OPERATING THE FAN FROM THE REMOTE CONTROL ............................. 12
REPLACING THE LED LIGHT PANEL ............................................................ 13
SUMMER AND WINTER MODE EXPLAINED 14 ................................................
GENERAL INFORMATION 15 ..............................................................................
MAINTENANCE & CLEANING ........................................................................ 15
TROUBLESHOOTING .................................................................................... 16
CEILING FAN WARRANTY INFORMATION 17-18 .............................................
ELECTRICIAN CHECKLIST ............................................................................ 19
TABLE OF CONTENTS
minimum
2100mm
Floor Level
Ceiling
