Bulimba
ATTENTION ELECTRICIANS:
ANY PROBLEMS FOUND DURING INSTALLATION OF THE FAN PLEASE CONTACT THE NATIONAL
WARRANTY NUMBER PRIOR TO LEAVING SITE.
DO NOT REMOVE THE FAN FROM THE CEILING
UNLESS INSTRUCTED TO DO SO.
National Warranty Number | 1300 116 305 Monday to Friday 9am to 5pm AEST
NOTE: THIS FAN MUST BE INSTALLED BY A LICENSED AND QUALIFIED
ELECTRICIAN IN ACCORDANCE WITH LOCAL AUTHORITY REGULATIONS
Australian Edition Version 1.1 September 2016
Four Blade 48”
NOTE: THIS FAN MUST BE INSTALLED BY A LICENSED AND QUALIFIED
ELECTRICIAN IN ACCORDANCE WITH LOCAL AUTHORITY REGULATIONS
1
IMPORTANT INFORMATION - PLEASE READ BEFORE ATTEMPTING INSTALLATION
1. Please read these instructions carefully, be mindful of all warnings and safety information shown throughout this
manual. Should you have any questions please call .1300 116 305
2. Please review the accompanying assembly diagrams before attempting installation.
3. This fan MUST be installed by a licensed & qualiîšżed electrician according to local authority regulations and in
accordance with current wiring rules AS/NZS3000.
4. A copy of the purchasing receipt and proof of installation by a licensed and qualiîšżed electrician according to local
authority regulations is required for all warranty claims.
5. Where special access equipment is required in accordance with local authority regulations all associated costs are
the responsibility of the owner.
6. We reserve the right to charge a $175 service fee for all call outs where the fan is found not to be defective and
/ or where access is not provided.
7. The fan and light (if supplied) MUST be earthed.
8. Do not mix blades between fans. The blades are provided as a complete matching set.
9. The fan is designed to function only using the wall controller provided in the box. Your warranty will be void if any
non approved (by Aeroblade) wall controllers or remote units are used with the fan.
10. The means for mains power disconnection must be incorporated in the îšżxed wiring in accordance with national
wiring rules.
11. It is the responsibility of the owner to have their electrician check the installation of the fan if any unexpected
noises are found.
12. Installations using steel beams, grid ceilings and exible structures are not recommended due to their inability to
absorb vibration caused through the normal operation. Timber is the recommended to mount the fan.
13. To avoid possible electric shock during installation, be sure electricity is turned off at the main power box before
commencing work. Disconnect power by removing fuse or turning off circuit breaker before installing the fan.
Ensure all spliced connections are adequately insulated.
14. Warning! Do not allow the rotating fan blades to come into contact with any object, this can cause serious
injury or death.
15. Damage caused by; incorrect installation, force-majeure, lightning, electrical surges & spikes, exposure to water,
pests or moisture is not covered under warranty.
16. In accordance with AS/NZS60355-1 & ASNZS60355-2-80: “This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance by a person responsible
for their safety.”
17. Children should be supervised to ensure that they do not play with the appliance.
18. Children shall not play with the appliance.
19. Cleaning and user maintenance shall not be made by children without supervision.
20. Do not use outdoors where the fan could be exposed to water or moisture. Incorrect installation can be dangerous
and will void the warranty.
Please Note: Nothing in this manual is intended to instruct or assist untrained or
unqualiîšżed persons to install this product. Additionally, it is the responsibility of the
installer and user to apply common sense and care at all times.
Please note: Minor design changes may result in slight variations between the product illustrations and the fan contained within the packaging.
National Warranty Hotline|1300 116 305 Monday to Friday 9am to 5pm AEST
2
LOCATION AND INSTALLATION REQUIREMENTS
Provide adequate clearance from the oor. The lowest point on the fan
blades must be at least 2.1m (7 feet) from oor level in Australia.
Note: For a fan mounted directly to the ceiling, the lowest point of the fan
blade is approximately 300mm (1 foot) below the ceiling.
Make sure that the chosen location of the fan will not allow the rotating
fan blades to come into contact with any objects.
Ensure ceiling joists are sound and of adequate size and strength to
support a 25Kg (55lb) load.
To reduce the risk of îšżre, electrical shock or personal injury, ensure
that the fan mounting bracket is supported directly from the building
structure. After the fan is completely installed, check to make sure that
all connections are secure to prevent the fan from falling and/or causing
damage or injury.
To reduce the risk of personal injury, do not bend or damage the motor or
Fan Assembly when handling or during installation. Please ensure special care is taken when assembling the fan. Each
screw must be sufîšżciently tightened.
minimum
2100mm
Floor Level
FAN ASSEMBLY
Secure the hanger bracket to ceiling beam or a suitable piece of timber inserted between the ceiling beams. Install the
mounting bracket using two (2) long screws as supplied within the package.
In accordance with Australian Standards, the fan blades must be at least 2.1 metres above oor level and
the blades require at least 300mm clearance to the nearest object.
Support Rod
Hanger Ball
Ball Joint Slot
Mounting Bracket
Place fan into hanger bracket and align ball joint slot with hanger bracket as illustrated below.
