Unpack the machine and check the components
Toner Cartridge and Drum Unit
Assembly
Toner Cartridge Replacement
(MFC-L2820DWXL /
MFC-L2900DWXL only.
Save for later use.)
AC Power Cord Quick Setup Guide Product Safety Guide
1Remove the packing materials and install the toner cartridge and drum unit assembly
2Load paper in the paper tray
3Connect the power cord and
turn the machine on
Back Front
NOTE:
Before connecting the power cord, locate the Serial Number
label on the back or side of the machine. Record this number
for product registration and warranty support.
NOTE:
â˘îManuals in Spanish for this model are available at support.brother.com.
Manuales en EspaĂąol para este modelo estĂĄn disponibles en
support.brother.com.
â˘îThe components included in the box may differ depending on your country.
â˘îThe available connection interfaces vary depending on the model.
If you use a wired connection, you must purchase the correct cable for the
interface you want to use.
â˘î USB cable
We recommend using a USB 2.0 cable (Type A/B) that is no more than
6 feet (2 meters) long.
â˘î Network cable (for wired network models only)
Use a straight-through Category 5 (or greater) twisted-pair cable.
â˘îThe screens and images in this show the MFC-L2820DW.Quick Setup Guide
â˘îSave all packing materials and the box in case you must ship your machine.
4Select your language (if needed)
îFor touchscreen models:
1. On the machineâs touchscreen,
press [Settings] >
[All Settings] >
[Initial Setup] >
[Local Language].
2. Select your language.
3. Press .
Remove the orange part.
1
1
2
Push firmly.
Adjust the paper
guides.
Do not exceed this mark.
îFor LCD models:
1. Press .Menu
2. Pressîâ˛îorîâźîtoîdisplayî
[Initial Setup], and then
press .OK
3. Pressîâ˛îorîâźîtoîdisplayî
[Local Language], and then
press .OK
4. Pressîâ˛îorîâźîtoîselectîyourî
language, and then press .OK
5. Press .Stop/Exit
Remove the protective tape or film covering the machine and the supplies.
Quick Setup Guide
Read the for the correct installation procedure.Product Safety Guide Quick Setup GuideîďŹrst,îthenîreadîthisî
Not all models are available in all countries.
The latest manuals are available at the Brother support website:
support.brother.com/manuals
EN
HL-L2465DW / DCP-L2640DW / DCP-L2647DW / DCP-L2660DW /
HL-L2480DW / MFC-L2760DW / MFC-L2807DW / MFC-L2820DW / MFC-L2820DWXL /
MFC-L2880DW / MFC-L2900DW / MFC-L2900DWXL / MFC-L2980DW
D0346C001-00
USA/CAN
Version C
7Connect your computer or mobile device to your machine
Follow these steps to complete the setup using one of the connection types available on your machine.
Visit setup.brother.com to download and install
Brother software.
Follow the on-screen
instructions and
prompts.
setup.brother.com
Setup Finished
You can now print and scan
using your machine.
Canât Connect? Check the following:
Restart your wireless access point
or router. If this is not possible, go
to the next step.
Disconnect the cable.
Wired network
USB connection
If still unsuccessful, go to .
If still unsuccessful, visit support.brother.com
for FAQs and Troubleshooting.
Restart your machine and
computer, and then go to .
8Manual wireless setup (Wireless models)
Find your SSID (Network Name) and Network
Key (Password) on your wireless access
point or router and write them in the table
provided below.
SSID (Network Name)
Network Key (Password)
If you cannot find this information, ask your
network administrator or wireless access
point or router manufacturer.
SSID: XXXXXXX
Network Key: XXXX
îFor touchscreen models:
Press >
[Find Wi-Fi Network].
Follow the touchscreen
instructions.
Go to to
install software.
If the setup is unsuccessful, restart your
Brother machine and your wireless access
point or router, and repeat .
If still unsuccessful, visit
support.brother.com.
â˘îFor LCD HL/DCP models:
Press and hold (or press repeatedly)
â˛îorîâźîtoîselectîoneîofîtheîfollowingî
characters:
0123456789abcdefghijklmnopqrstuvwxyz
ABCDEFGHIJKLMNOPQRSTUVWXYZ
(space)!"#$%&'()*+,-./:;<=>?@[\]^_â{|}~
When the wireless setup is successful, the
touchscreen/LCD displays .[Connected]
Important Notice for Network Security:
The default password to manage this
machineâs settings is located on the back of
the machine and marked â â. Pwd
We recommend immediately changing the
default password to protect your machine from
unauthorized access.
If the wireless setup is unsuccessful, set up the connection manually.
NOTE:
â˘îFor more information on using the fax feature, see the .Online Userâs Guide
â˘îYour machine is programmed to automatically receive faxes. To change this default mode, see the Online Userâs Guide.
îFor LCD models:
A. Set the date and time
Date
1. Press , , , .Menu 0 1 1
2. Enter the date using the dial
pad, and then press to OK
confirm.
1. Last two digits for the year.
2. Two digits for the month.
3. Two digits for the day.
Clock Type
1. Pressîâ˛îorîâźîtoîselectî[12h
Clock] [24h Clock] or , and
then press .OK
6
Configure the machine for faxing
(For MFC models only)
Time
1. Enter the time using the dial
pad, and then press .OK
(12h Clock only)
Pressîâ˛îorîâźîtoîselectî[AM] or
[PM], and then press .OK
2. Press .Stop/Exit
B. Set the Station ID
1. Press , , .Menu 0 2
2. Set your fax or telephone
number and your name.
If you do not plan to use the fax feature on this machine, go to step .
Wireless network
5
Connect the telephone line cord
(For MFC models)
If you do not plan to use the fax feature on this
machine, go to step .
Before connecting your machine to a 5 GHz Wi-FiÂŽ network,
confirm the channels that your machine supports.
Go to support.brother.com/g/d/a5m6/, select your product,
and then click for more information.Download
îFor touchscreen models:
A. Set the date and time
Press > [Settings]
[All Settings] >
[Initial Setup] >
[Date & Time], and then set
the date and time you want.
B. Set the Station ID
Press > [Settings]
[All Settings] >
[Initial Setup] >
[Station ID], and then set
your fax or telephone number
and your name.
îFor LCD models:
Press , and then select Menu
[Network] >
[WLAN(Wi-Fi)] >
[Find Network].
Follow the LCD instructions.
Select the SSID (Network Name) for your
access point or router and enter the Network
Key (Password).
For detailed machine information and product specifications, see the at support.brother.com/manuals. Š 2023 Brother Industries, Ltd. All rights reserved.Online User's Guide
D0346C001-00
