USER GUIDE

CUBE Carts

TVC16PAC-CK CUBE Charging Cart AC for up to 16 devices w/Back Panel … 1.4”W Slots | Charcoal ﬁnish ! !

TVC32PAC-CK CUBE Charging Cart AC for up to 32 devices w/Back Panel … 1.4”W Slots | Charcoal ﬁnish ! !

TVC16PAC-RED CUBE Charging Cart AC for up to 16 devices w/Back Panel … 1.4”W Slots | Red ﬁnish ! !

TVC32PAC-RED CUBE Charging Cart AC for up to 32 devices w/Back Panel … 1.4”W Slots | Red ﬁnish ! !

TVC16PAC-SKY CUBE Charging Cart AC for up to 16 devices w/Back Panel … 1.4”W Slots | Sky Blue ﬁnish ! !

TVC32PAC-SKY CUBE Charging Cart AC for up to 32 devices w/Back Panel … 1.4”W Slots | Sky Blue ﬁnish! !

CAPACITY! !slot width = 1.4”

TVC16PAC-XXX 1 shelf 16 devices ! !

TVC32PAC-XXX 2 shelves 32 devices ! !

COMPATIBILITY Designed for various sized laptops & chromebooks, yet versatile enough to

support most tablets. Uses the device manufacturer supplied AC power cord and adapter.

! "OUTSIDE DIMENSIONS 30” W x 26.5”D x 37.5”H

! ! "SLOT DIMENSIONS 1.4”W x 17”D x 12”H (ﬁxed)

!WEIGHT!TVC16PAC-XXX 134 pounds empty! "

! ! ! "259 pounds with 16 ea 5 lb devices

! ! ! "+ an allowable 45 lbs in the bottom shelf area

! ! TVC32PAC-XXX 143 pounds empty! "

! ! ! "303 pounds with 32 ea 5 lb devices

! "POWER MANAGER!Digital

!POWER REQUIREMENTS!120Vac, 50/60Hz, 12A

!SHIPPING Ships fully assembled, ready to load devices

!WARRANTY For product speciﬁc warranty information,

! ! please visit: bretford.com/warranty

Part # 080-1016 rev February 10, 2017

MADE IN USA

with globally

sourced products

www.bretford.com

Technical Speciﬁcations

POWER SWITCH

Located on the

top of the cart,

directly in front of

the Push Bar

POWER CORD WINDER

Located on the left side

of the cabinet, provides a

cord winder for the 7-

foot power cord

LOCKING 5” CASTERS

Allow the cart to be easily

maneuvered into small

spaces. When engaged,

lock the cart into position.

Front View

Rear View

REAR ACCESS SECURITY PANEL

Held securely in place with a key

lock. Once unlocked, the panel

easily lifts off to expose the back of

the cart, where the adapters and

cord sets are kept in cable bins.

DOOR LOCK SHROUD

Protects the padlock

during transport

WARNING:

This cart is not intended

to hold items on the top

surface. Do not place

any item weighing more

than 1 pound on the top

surface of the cart to

avoid damage.

INTEGRATED HANDLE

Handle integrated into

the top of the cart for

pushing and moving

the cart.

USER GUIDE | CUBE CARTS

SETTING THE COMBINATION LOCK

Your new CUBE Cart comes equipped with a resettable Combination Padlock. You can program the

lock with your own combination. The lock starts with 0-0-0-0. Follow the directions with the look for

changing the combination. Remember to depress the shackle before disengaging it from the lock.

General Use

STEEL CONSTRUCTION

Designed to store,

secure, transport &

charge up to 32

devices. All-steel

construction is sturdy

and provides strength

to support 32

devices.

USER GUIDE | CUBE CARTS

Device Storage & Cable Management

1. At the back of the cart, use the key from the hardware

pack to unlock the rear access panel.

2. The two keys included in the hardware pack are for the

person(s) responsible for managing the computer

adapters and cable sets, through the rear access panel.

3. Lift the rear access panel off of the chassis.

This exposes the power outlet modules for the shelves.

4. Starting in the rear of the cart with the rear access panel

panel removed, insert a power adapter in the storage bin

for the associated device storage shelf (top or bottom).

5. Measure the amount of cable necessary to reach from

the power adapter located in the bin to the front of the

cart (over the AC outlet box, from the back to the front

of the cart, through the cable management slots that are

integrated into the plastic dividers.)

6. Leave sufﬁcient slack for the power connector to plug

into the device.

7. Plug the device AC adapter plug into one of the outlets

nearest to where the power adapter is located in the bin.

8. Repeat the above process for the total number of

devices’ power adapters & cable sets.

9. In the front of the cart, insert a device into each of the

slots, and plug in the power connector to each device.

10. Replace the Rear Access Panel and lock the panel using

the key from the Hardware Pack.

11. Place the cart near a wall outlet and plug the cart in.

12. Turn on the power switch - located in front of the push

handle

13. In the TVC32PAC-XXX CUBE Cart for 32 devices, once

the cart is turned on, the power manager begins rotating

power to the power strips every 5 minutes. This allows

efﬁcient charging of the devices in the cart from one

single 15 amp circuit.

PLASTIC DIVIDERS

features slots for routing the computer plug cable to the

plug-in spot on the computer - high or low, left or right.

NOTE: Plastic dividers are not removable or resettable.

TVC32PAC-XXX

TVC16PAC-XXX

REAR ACCESS PANEL

Locks in position

with the keys from

the hardware pack

POWER OUTLET MODULES

16 AC outlets per shelf,

matches the quantity of

slots in the front of the cart
