1
HS-200M HEALTH SCALE
The Health Scale is designed to both weigh the body and measure the heightHS-200M
and meets the OIML nternational Recommendation R76. The scale has the I advantage
of a large weighing range, accuracy and high sensitivity. It is ideal for school nurse’s
offices or for doctor’s screening rooms where height and patient weight measuring is
necessary. It is also can be used for other weighing needs.
Specification:
1. : 160kg/350lb 180kg/400lb 200kg/450lb Maximum capacity , , ï¼›
2. Graduation 100g/0.25lb :
3. Height ange: 60 210cm R -
4. : Minimum value of height per division 5mm
5. 375 275 : Platform size x cm cm
6. Overall dimension (L x W x x x H) 530mm 275mm 1485mm
Installation Instruction:
Weighing Ruler
Height Rod
Pillar
Platform
Frame
Moving Wheel
2
Pillar Installation (Fig.2):
1. I u nsert the pillar pright to the bracket on frame
2. Use the screws and washer to fix the pillar in a vertical position
Main poise weight
Measuring rule
Zero balance weight
Zero adjusting screw
Force lever Pole Steelyard rod
Pillar head
Eye loop
Bolt Pillar
Platform
Frame
Accessory poise weight
3
II. Connect the steelyard rod to long lever (Fig.3):
1. Lay the pillar on a table (Fig.3)
2. Disassemble the wires on the levers.
3. Insert the wrench to the small hole in front of the steelyard rod, and pull the in
hook of steelyard rod with the hook of wrench (Fig. 3.the 1)
4. Push the long lever forward, then hook the bearing of the steelyard rod on the
pivot of the long lever (Fig. 3-2)
5. Take away the wrench form the draft rod (Fig.3-3)
6. Put the scale on ground gentlythe
Zoom
Disassemble
the wires
Connect the steelyard to the long lever
Wrench
Steelyard rod hook
Fig 3.1
