Squarodox™ 3D Manual Rev. B © 2020 Blizzard Lighting, LLC
TABLE OF CONTENTS
Squarodoxâ„¢ 3D 1
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4
2. Meet The Squarodoxâ„¢ 3D 5
Main Features 5
DMX Quick Reference 5
The Squarodoxâ„¢ 3D Pin-up Picture 6
3. Setup 7
Fuse Replacement 7
Connecting A Bunch Of Squarodoxâ„¢ 3D Fixtures 7
Data/DMX Cables 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh? 8
Take It To The Next Level: Setting up DMX Control 8
Fixture Linking (Master/Slave Mode) 9
Mounting/Rigging 9
4. Operating Adjustments 10
The Control Panel 10
Control Panel Menu Structure 11
DMX Mode 11
Select The DMX Starting Address 11
Select The Channel Mode 11
Master/Slave Mode Settings 11
Auto and Sound Active Modes 11
Manual Adjustments 11
DMX Channel Values In-Depth 12
Troubleshooting 13
5. Appendix 17
A Quick Lesson On DMX 17
Keeping Your Squarodoxâ„¢ 3D As Good As New 18
Returns (Gasp!) 18
Shipping Issues 18
Tech Specs 19
Troubleshooting 19
Page 3
Squarodox™ 3D Manual Rev. B © 2020 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• 1 x Squarodox™ 3D
• An Ever-So-Handy Power Cord
• 3 x Mounting Brackets
• This Lovely User Manual
Getting It Out Of The Box
Congratulations on purchasing the Squarodox™ 3D. Now that you’ve got your Squarodox™
3D, you should carefully unpack the box and check the contents to ensure that all parts
are present and in good condition. If anything looks as if it has been damaged in transit,
notify the shipper immediately and keep the packing material for inspection. Again, please
save the carton and all packing materials. If a îš¿xture must be returned to the factory, it is
important that the îš¿xture be returned in the original factory box and packing.
Powering Up!
All xtures must be powered directly o a switched circuit and cannot be run o a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch - Not all îš¿xtures have a voltage select switch, so please verify that the
îš¿xture you receive is suitable for your local power supply. See the label on the îš¿xture or
refer to the xture’s specications chart for more information. A xture’s listed current
rating is its average current draw under normal conditions. Check the îš¿xture or device
carefully to make sure that if a voltage selection switch exists that it is set to the correct
line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your îš¿xture may result if the line voltage applied does
not match the voltage indicated on the voltage selector switch. All îš¿xtures must
be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something happens goes wrong, please visit www.blizzardpro.com/support and open a
support ticket. We’ll be happy to help, honest.
Disclaimer: The information and speciîš¿cations contained in this document are subject
to change without notice. Blizzard Lightingâ„¢ assumes no responsibility or liability for any
errors or omissions that may appear in this user manual. Blizzard Lightingâ„¢ reserves the
right to update the existing document or to create a new document to correct any errors
or omissions at any time. You can download the latest version of this document from www.
blizzardpro.com.
Author: Date: Last Edited: Date:
J. Thomas 9/18/2019 J. Thomas 2/18/2020
