Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
BLH7300
BLH7360
BLH7380
2
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage
to the product or other property. This product is not intended for use by children without direct adult supervision. Do
not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid
damage or serious injury.
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no
possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a
possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage,
and serious injury OR create a high probability of superfi cial injury.
Always keep a safe distance in all directions around
your model to avoid collisions or injury. This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.
Always operate your model in open spaces away from
full-size vehicles, traf c and people.
Always carefully follow the directions and warnings for
this and any optional support equipment
(chargers, rechargeable battery packs, etc.).
Always keep all chemicals, small parts and anything
electrical out of the reach of children.
Always avoid water exposure to all equipment not
specifi cally designed and protected for this purpose.
Moisture causes damage to electronics.
Never place any portion of the model in your mouth as it
could cause serious injury or even death.
Never operate your model with low transmitter batteries.
Always keep aircraft in sight and under control.
Always move the throttle fully down at rotor strike.
Always use fully charged batteries.
Always keep transmitter powered on while aircraft is
powered.
Always remove batteries before disassembly.
Always keep moving parts clean.
Always keep parts dry.
Always let parts cool after use before touching.
Always remove batteries after use.
Never operate aircraft with damaged wiring.
Never touch moving parts.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon
Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.
Meaning of Special Language
Safety Precautions and Warnings
Age Recommendation: Not for children under 14 years. This is not a toy.
3EN
EFLC1014
SOL ID RED LED
–Charging
DC Input :5.0V 750mA
DC Output:4.2V 700mA
USB Li-Po
Charger
LED OFF
–Charge
Complete
Box Contents
Blade® Zeyrok Quadcopter
750mAh 1S 3.7V 25C Li-Po Battery
700mA 1S Li-Po USB Charger
720p/1.3MP Digital Camera (RTF w/camera Only)
4GB Micro SD Card and SD Adapter
(RTF w/camera Only)
MLP6 DSMX® SAFE® Transmitter
(RTF and RTF w/camera Only)
4 AA Batteries (RTF and RTF w/camera Only)
Table of Contents
Length 7.8 in (200mm)
Width 8.6 in (220mm)
Height 1.8 in (45mm)
Propeller Diameter 5.3 in (135mm)
Flying Weight 4.3 oz (122 g)
Specifications
Box Contents ...................................................................3
First Flight Preparation .....................................................4
Flying Checklist ...............................................................4
Charging Warnings...........................................................4
Battery Charging ..............................................................4
Installing the Transmitter Batteries (RTF) ..........................5
BNF Transmitter Setup .....................................................5
Installing the Flight Battery ..............................................8
Transmitter and Receiver Binding .....................................8
RTF Transmitter Controls .................................................9
SAFE® Technology ...........................................................9
Understanding the Primary Flight Controls .....................10
Installing the Optional Camera (BNF) ..............................10
Camera Controls ............................................................11
Flight Mode Selection ....................................................11
Flying the Zeyrok™ Quadcopter ....................................11
LED Codes .....................................................................12
Post-Flight Inspection and Maintenance Checklist ..........12
Replacing the Propellers ................................................13
Drift Calibration..............................................................13
Troubleshooting Guide ...................................................14
Exploded View ...............................................................15
Parts Listings .................................................................15
Optional Parts ................................................................15
Limited Warranty ...........................................................16
Warranty and Service Contact Information .....................17
FCC Statement...............................................................17
IC Information ................................................................17
Compliance Information for the European Union .............17
To receive product updates, special offers and more, register your product at www.bladehelis.com
