INSTALLATION AND OPERATING INSTRUCTIONS
for all
DP and DPD Models
3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105
Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: beverage-air.com
809-140A Rev. A 04/11/2022 SEE BACK COVER FOR
WARRANTY REGISTRATION
User Manual for DP & DPD Beverage-Air
Rev. 04/22Beverage-Air2
WELCOME
Important Information
• PLEASE READ THESE INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR USING, IF RECOMMENDED
PROCEDURES ARE NOT FOLLOWED, WARRANTY
CLAIMS MAY BE DENIED.
• Your warranty registration information is located with
this manual. Please complete the card and submit it to
Beverage-Air within TEN days of installation. Failure
to properly register equipment may limit or void the
warranty.
• Beverage-Air reserves the right to change
specications and product design without
notice. Such revisions do not entitle the buyer to
corresponding changes, improvements, additions, or
replacements for previously purchased equipment.
Thank you for purchasing a Beverage-Air cabinet. This
series has passed our strict quality control inspection
and meets the high standards set by Beverage-Air
Refrigeration! You have made a quality investment that
with proper maintenance will give you many years of
reliable service!
Please read the following installation and maintenance
instructions before installing or using your unit. If you
have any questions, Please call our Technical Service
Department at (800) 684-1195. 8:00 AM to 5:00 PM EST.
Contents
Welcome 2 ...................................................................................................................................................................
Safety 3 ........................................................................................................................................................................
Important Information 4 ..........................................................................................................................................
Product Information 5 ..............................................................................................................................................
Clearance and Placement 6 .....................................................................................................................................
Unpacking and Set Up 7 ............................................................................................................................................
Shelf Installation 8 .....................................................................................................................................................
Drawer Maintenance 9 .............................................................................................................................................
Electrical 10 ..................................................................................................................................................................
Using The Unit - Danfoss Controller 11 ..................................................................................................................
Sequence of Operations Refrigerator......................................................................................................12
Using The Unit - Eliwell Controller 16 ....................................................................................................................
Sequence of Operations Refrigerator......................................................................................................17
Cleaning and Maintenance 20 ................................................................................................................................
Condenser Cleaning 21 ...............................................................................................................................................
Methods For Cleaning Stainless Steel.............................................................................................................22
Help 23 ..........................................................................................................................................................................
For The Service Tech ............................................................................................................................................24
For The Service Tech - Wiring Diagrams 25 .........................................................................................................
Limited Warranty 27 .................................................................................................................................................
Limited Warranty (continued) 28 ...........................................................................................................................
User Manual for DP & DPD Beverage-Air
Rev. 04/22 Beverage-Air 3
SAFETY
This appliance has been designed with your safety in mind. It has many features to keep you from being harmed. However,
safe operation and maintenance are your responsibilities.
Use: When using this unit, please:
• Move it carefully. If on casters be sure the casters
do NOT run over the power cord.
• Lock the casters when in use.
• Seek help. This machine is heavy! Be sure to move
with enough help to avoid tipping or dropping the
cabinet.
• Prevent children from playing in or on the cabinet.
Persons unable to use this product must be
prevented access.
• Follow all instructions. There are many safety
labels and directions on the unit. Heed them.
• Watch your ngers. There may be pinch points near
the door hinges.
Maintenance
Do NOT:
• Clean a frozen evaporator with a sharp object
• Clean a dirty condenser with a sharp object.
• Store gasoline, kerosene or any other ammable
material near the cabinet.
Do ALWAYS
• Use a Beverage-Air recommended technician certied
to repair R290 equipment.
• Use ONLY Beverage-Air factory service parts. Use of
non OEM parts can be dangerous because of the design
changes needed to safely use R290.
Observe the and Caution Warning notices. They are indicators of
important safety information. Keep this manual for future reference.
Important Information to Add
Record the model number, serial number and the date of installation here for future reference. The model and serial
numbers are on the unit's serial number dataplate, which is located on the left inside wall.
Model Number
Serial Number
Date of Installation
Purchased From
CAUTION
WARNING
CAUTION
CAUTION
