BENNING PV Link
05/ 2017 - - 1
Operating Manual
“BENNING PV Link” App
==========================================================
Table of contents
1. Registration
2. Start screen
2.1 Functional elements
3. Reading new measurement data
3.1 Measurements tab
3.2 Curve tab
3 Module Parameters tab 3.
3.4 Additional Information tab
3.5 Storing measurement data
4. NFC data transfer
4.1 Enabling NFC and GPS for Android devices
4.2 Reading measurement data from the BENNING 2 PV
5. Creating a PDF test report
6. Settings
BENNING PV Link
05/ 2017 - - 2
1. Registration
After having started the “BENNING Link” app for the first time, you can create a user name. Please PV
observe that the user name used will be stated in the PDF test report as the test person and will be shown in
the “Tested by:” field. You can change the user name in the settings at any time.
Use the “Register Product” button to register your BENNING 2 on the BENNING homepage. Register your PV
BENNING 2 and benefit from our information service and our 24/7 service hotline. PV
Phone: +49 (0) 2871/93 - 555
2. Start screen
To familiarize with the functions of the app, the start screen includes two example measurements. All
measurement data that have been read and stored are displayed in this list of measurement data.
Via the start screen, you can read new measurement data from the BENNING 2, filter or sort measurement PV
data, delete all existing measurement data and make various settings.
Tap an individual measurement data record to open the measurement data and view the curves. If you want to
select or delete a measurement data record, tap and hold an individual measurement data record and a pop-up
window appears.
Add to Bookmarks
Delete
BENNING PV Link
05/ 2017 - - 3
2.1 Functional elements
Read new measurement data Reading new measurement data from the BENNING 2 –PV
Possible criteria: All, Passed, Failed and Bookmarks Filter measurement data –
Sorting measurement data by string ID or site name Sort measurement data –
All existing measurement data will be deleted Delete existing measurement data –
(operating manual), settingsHelp
3. Reading new measurement data
Tap the icon on the start screen to read a new measurement data record (I-V curve). A new view with the
following tabs opens:
ď‚· Measurements
ď‚· Curve
ď‚· Module Parameters
ď‚· Additional Information
Chapter 4 explains how to transfer data via NFC between the BENNING 2 and your Android device. In the PV
following, the functions of the individual tabs are described.
